| Engine Manufacturer | Doosan | FPT |
|---|
| Engine Model | DL03-LEA07 | NEF |
|---|
| Engine Type | 4-cylinder, in-line vertical, water-cooled diesel | 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 208 in³ | 274 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2200 rpm |
|---|
| Engine Power (Gross) | 110 hp | 110 hp |
|---|
| PTO Power | 92.2 hp | 92 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Water-cooled | Not Published |
|---|
| Air Cleaner | Dual air cleaner | Not Published |
|---|
| Fuel System | Not Published | High-pressure common rail fuel injection |
|---|
| Alternator | Not Published | 120 A |
|---|
|
|---|
| Pump Type | Gear | Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve |
|---|
| Implement Flow | Not Published | 19 gpm (combined implement and auxiliary pump flow) |
|---|
| Steering Flow | Not Published | 9 gpm |
|---|
| Total Hydraulic Flow | 31.5 gpm | 28 gpm |
|---|
| Overall Hydraulic Pump Flow | 31.5 gpm | 28 gpm |
|---|
| Hydraulic System Type | Open center | Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | Not Published |
|---|
| No. of Optional Remote Valves | 1 (third valve) | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 34.3 gal | 57.5 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Independent | Not Published |
|---|
| PTO Rear | 540 / 1000 rpm | 540/1000 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II (flex link ends) |
|---|
| Hitch Lift Capacity | Not Published | 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two |
|---|
| Hitch Lift Capacity (at 24”) | 8,002 lb | Not Published |
|---|
| Lift Control Type | Position, draft, mixed control | Not Published |
|---|
|
|---|
| Transmission Type | Synchronized shuttle, power shuttle type | 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional |
|---|
| No. of Speeds | 32F/32R | 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) |
|---|
| Max Travel Speed (Forward) | 24.87 mph | 19 mph or 25 mph (25 mph 4WD only) |
|---|
| Max Travel Speed (Reverse) | 24.69 mph | Not Published |
|---|
| Clutch | Wet multi disc | Not Published |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock (standard) | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Power steering | Not Published |
|---|
| Brakes | Wet disc | Not Published |
|---|
| Seat Suspension & Adjustability | Fully adjustable suspension swivel seat (deluxe cab) | Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) |
|---|
| Front Axle Type | 4WD, electric/hydraulic engagement | 4WD heavy-duty front axle, Standard Duty Class 3 (cab and 4WD only) |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 168.9 in | 184.7 in (4WD, with front weights) |
|---|
| Overall Width | 88.6 in | Not Published |
|---|
| Wheelbase | 93.3 in | 99.2 in (4WD, Standard Duty Class 3 axle) |
|---|
| Ground Clearance | 19.5 in | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 109 in | 110.2 in |
|---|
|
|---|
| Tractor Weight (Base) | 9,064 lb (with cab and ag tires; cab is standard) | 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural: 13.6-24 front, 18.4-34 rear | 18.4-38 R1 rear with 14.9-28 R1 front (4WD) |
|---|
| R1 Agricultural - Front | 13.6-24 | 14.9-28 (4WD) |
|---|
| R1 Agricultural - Rear | 18.4-34 | 18.4-38 |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Quick attach (QA) bucket, 90 in; dual lever quick attach, built-in parking stand | Skid steer (SSL) or Euro style attachment couplers |
|---|
| Loader Model | KL1153 | 830LA (NSL); 835LA (MSL) |
|---|
| Loader Lift Height | KL1153: 143.3 in | 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | KL1153: 4,190 lb | 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) |
|---|
| Loader Breakout Force | KL1153: 8,310 lb | 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
