Kubota L2502 vs Kubota L4802

Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.

Across 0 measurable specs, this matchup is a dead heat: 0 categories to the Kubota L2502, 0 to the Kubota L4802. Machine pages: Kubota L2502 and Kubota L4802.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Spec	Kubota L2502	Kubota L4802
Engine HP (hp)	—	48.4 hp
PTO HP (hp)	—	40.5 hp
Loader Lift (lb)	—	1,675 lb
3-Pt Lift (24 in) (lb)	—	2,320 lb
Lift Height (in)	—	105.2 in
Hydraulic Flow (gpm)	—	12.5 gpm
Travel Speed (mph)	—	14.9 mph

The headline numbers at a glance.

Kubota L2502Kubota L4802

Engine HPhp

—

48.4 hp

PTO HPhp

—

40.5 hp

Weightlb

—

Loader Liftlb

—

1,675 lb

3-Pt Lift (24 in)lb

—

2,320 lb

Share↓ Image 𝕏 f ✉

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	KubotaL2502	KubotaL4802


PTO Power	—	40.5 hp
Alternator	—	Not Published
Air Cleaner	—	Not Published
Engine Type	—	Direct injection, vertical, water-cooled 4-cycle, diesel
Fuel System	—	Direct injection
Displacement	—	148.5 in³
No. of Cylinders	—	4
Rated Engine Speed	—	2600 rpm
Cooling System Type	—	Water-cooled
Engine Manufacturer	—	Kubota
Engine Power (Gross)	—	48.4 hp
Engine Emissions Constraints	—	Not Published

Weight with ROPS and Loader	—	Not Published
Weight with Cab and Loader	—	Not Applicable

Warranty Length & Coverage	—	Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.

Pump Type	—	Not Published
Steering Flow	—	4.7 gpm
Implement Flow	—	7.8 gpm
Total Hydraulic Flow	—	12.5 gpm
Hydraulic System Type	—	Not Published
Rear Remote Hydraulic Flow	—	Not Published
Overall Hydraulic Pump Flow	—	12.5 gpm
No. of Optional Remote Valves	—	Not Published
No. of Standard Remote Valves	—	Not Published

PTO Rear	—	540 rpm
PTO Type	—	Live independent PTO with hydraulic clutch
Lift Control Type	—	Position control
Hitch Lift Capacity	—	2870 lb
Mid-PTO Availability	—	Not Published
Category, 3-Point Hitch	—	SAE Category I
Hitch Lift Capacity (at 24”)	—	2320 lb

R3 Turf - Rear	—	DT (2WD/4WD), HST (4WD): 44X18-20; DTN (4WD): Not Applicable
R3 Turf - Front	—	DT (2WD): 27X8.50-15; DT (4WD), HST (4WD): 27X10.5-15; DTN (4WD): Not Applicable
Tire Size & Options	—	R1 Agricultural; R3 Turf; R4 Industrial
R4 Industrial - Rear	—	DT (2WD), DTN (4WD): Not Applicable; DT (4WD), HST (4WD): 4.6 gal-24
R4 Industrial - Front	—	DT (2WD), DTN (4WD): Not Applicable; DT (4WD), HST (4WD): 10.0-16.5
R1 Agricultural - Rear	—	DT (2WD/4WD), HST (4WD): 14.9-24; DTN (4WD): 11.2-24
R1 Agricultural - Front	—	DT (2WD): 2 gal-15; DT (4WD), HST (4WD): 8.3-16; DTN (4WD): 7.2-16

Coolant Capacity	—	Not Published
Crankcase Capacity	—	Not Published
Fuel Tank Capacity	—	13.5 gal
Front Axle Fluid Capacity	—	Not Published
Transmission / Hydraulic System Capacity	—	Not Published

Loader Lift Height	—	DT (2WD/4WD), HST (4WD): 105.2 in; DTN (4WD): Not Applicable
Loader Breakout Force	—	Not Published
Quick Attach Loader System	—	DT (2WD/4WD), HST (4WD): LA766 2-Lever Quick Coupler; DTN (4WD): Not Applicable
Loader Lift Capacity (Full Height)	—	DT (2WD/4WD), HST (4WD): 1675 lb; DTN (4WD): Not Applicable

Clutch	—	DT (2WD/4WD), DTN (4WD): Dry type single stage; HST (4WD): Not Applicable
No. of Speeds	—	DT (2WD/4WD), DTN (4WD): 8 forward, 8 reverse; HST (4WD): 3-range
Transmission Type	—	DT (2WD/4WD), DTN (4WD): Constant mesh with synchronized shuttle; HST (4WD): Hydrostatic transmission (3-range)
Max Travel Speed (Forward)	—	DT (2WD/4WD): 14.9 mph; DTN (4WD): 12.9 mph; HST (4WD): 15.8 mph
Max Travel Speed (Reverse)	—	DT (2WD/4WD): 14.3 mph; DTN (4WD): 12.4 mph; HST (4WD): 14.2 mph
Differential Lock & Limited Slip Options	—	Not Published

Brakes	—	Mechanical, wet disc type
Steering	—	Hydrostatic power steering
Frame Type	—	Not Published
Front Axle Type	—	Not Published
Drawbar Capacity	—	Not Published
Front Axle Rating	—	Not Published
Seat Suspension & Adjustability	—	Not Published

Wheelbase	—	72.6 in
Overall Width	—	DT (2WD/4WD), HST: 62.2 in; DTN (4WD): 53.7 in
Ground Clearance	—	DT (2WD/4WD), HST: 15.2 in; DTN (4WD): 11.6 in
Height to Top of ROPS	—	DTN (4WD): 94.9 in; DT (2WD/4WD), HST (4WD): 91.7 in
Height to Top of Cab Model	—	Not Applicable
Height to Top of ROPS (folded)	—	DTN (4WD): 61.2 in
Min. Turn Radius without Brakes	—	Not Published
Overall Length with 3-Point Hitch	—	DT (2WD): 122.8 in; DT (4WD), HST (4WD): 120.3 in; DTN (4WD): 117.7 in
