Kubota L3560LE vs Kubota L3901
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 9 measurable specs, the Kubota L3560LE leads 7 categories to 2. Machine pages: Kubota L3560LE and Kubota L3901.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | Kubota L3560LE | Kubota L3901 |
|---|---|---|
| Engine HP (hp) | 37 hp | ▲ 37.5 hp |
| PTO HP (hp) | 28 hp | ▲ 32.1 hp |
| Weight (lb) | ▲ 3,649 lb | 2,778 lb |
| Loader Lift (lb) | ▲ 1,715 lb | 1,131 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 2,646 lb | 1,433 lb |
| Lift Height (in) | ▲ 104.7 in | 94.3 in |
| Breakout Force (lbf) | ▲ 2,549 lbf | 2,462 lbf |
| Hydraulic Flow (gpm) | ▲ 12.8 gpm | 10.1 gpm |
| Travel Speed (mph) | ▲ 16.5 mph | 13.2 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | KubotaL3560LE | KubotaL3901 |
|---|
| Engine Manufacturer | Kubota | Kubota |
|---|---|---|
| Engine Model | D1803-CR-E4-GL2 | F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 |
| Engine Type | Naturally aspirated, multi-valve, liquid-cooled diesel | 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 111.4 in³ | 111.4 in³ |
| Rated Engine Speed | 2600 rpm | 2700 rpm |
| Engine Power (Gross) | 37 hp | 37.5 hp |
| PTO Power | 28 hp | F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Liquid-cooled | Liquid-cooled, water with pressurized radiator |
| Air Cleaner | Dry paper, dual element | Dry paper single element |
| Fuel System | Electronic CRS (Common Rail System) | Common-rail, direct injection, electronic control |
| Alternator | ROPS: 40 A, 12 V; Cab: 60 A, 12 V | 40 A |
Kubota L3560LE vs Kubota L3901: Quick Answers
- Which has more horsepower, the Kubota L3560LE or the Kubota L3901?
- The Kubota L3901 leads on engine hp at 37.5 hp hp, compared to 37 hp hp for the Kubota L3560LE.
- Which has more PTO horsepower, the Kubota L3560LE or the Kubota L3901?
- The Kubota L3901 leads on pto hp at 32.1 hp hp, compared to 28 hp hp for the Kubota L3560LE.
- Which is heavier, the Kubota L3560LE or the Kubota L3901?
- The Kubota L3560LE leads on weight at 3,649 lb lb, compared to 2,778 lb lb for the Kubota L3901.
- Which has more loader lift capacity, the Kubota L3560LE or the Kubota L3901?
- The Kubota L3560LE leads on loader lift at 1,715 lb lb, compared to 1,131 lb lb for the Kubota L3901.
- Which has more three-point hitch lift capacity, the Kubota L3560LE or the Kubota L3901?
- The Kubota L3560LE leads on 3-pt lift (24 in) at 2,646 lb lb, compared to 1,433 lb lb for the Kubota L3901.
