| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | F (2WD gear), DT (4WD gear): D1803-CR-E4-LB3; HST (4WD): D1803-CR-E4-LB4 | V2403-CR-E4-GL2 |
|---|
| Engine Type | 3-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel | Naturally aspirated, multi-valve, liquid-cooled diesel |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 111.4 in³ | 148.5 in³ |
|---|
| Rated Engine Speed | 2700 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 37.5 hp | 42 hp |
|---|
| PTO Power | F (2WD gear), DT (4WD gear): 32.1 hp; HST (4WD): 30.6 hp | 32.5 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled, water with pressurized radiator | Liquid-cooled |
|---|
| Air Cleaner | Dry paper single element | Dry paper, dual element |
|---|
| Fuel System | Common-rail, direct injection, electronic control | Electronic CRS (Common Rail System) |
|---|
| Alternator | 40 A | 40 A, 12 V |
|---|
|
|---|
| Pump Type | Open center tandem pump, gear type | Tandem pump - gear type |
|---|
| Implement Flow | 6.3 gpm | 9.4 gpm |
|---|
| Steering Flow | 3.8 gpm | 4.7 gpm |
|---|
| Total Hydraulic Flow | 10.1 gpm | 14.1 gpm |
|---|
| Overall Hydraulic Pump Flow | 10.1 gpm | 14.1 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | None standard (up to 3 optional) |
|---|
| No. of Optional Remote Valves | Up to 3: self-canceling detent valve or float detent valve | Optional, up to 3: double-acting valve or float detent valve, any position |
|---|
|
|---|
| Fuel Tank Capacity | 11.1 gal | 13.5 gal |
|---|
| Coolant Capacity | 6.3 qt | 7.9 qt |
|---|
| Crankcase Capacity | 7.1 qt | 8.7 qt |
|---|
| Transmission / Hydraulic System Capacity | F (2WD gear): 7.4 gal; DT (4WD gear): 7.5 gal; HST (4WD): 6.2 gal | 11.4 gal |
|---|
| Front Axle Fluid Capacity | 4.8 qt | 6.9 qt |
|---|
|
|---|
| PTO Type | Live-continuous running | Live independent (hydraulic clutch) |
|---|
| PTO Rear | 540 rpm | 540 rpm @ 2476 engine rpm |
|---|
| Mid-PTO Availability | No mid-PTO offered | Optional |
|---|
| Category, 3-Point Hitch | Category I | SAE Category I |
|---|
| Hitch Lift Capacity | 1,874 lb (at lift points) | 3,858 lb |
|---|
| Hitch Lift Capacity (at 24”) | 1,433 lb | 2,760 lb |
|---|
| Lift Control Type | Position control | Position control |
|---|
|
|---|
| Transmission Type | F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range | Hydrostatic |
|---|
| No. of Speeds | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range | 3-Range, 6 speeds (H-DS), infinitely variable in each |
|---|
| Max Travel Speed (Forward) | F (2WD gear), DT (4WD gear): 13.2 mph; HST (4WD): 14.1 mph | 16.8 mph |
|---|
| Max Travel Speed (Reverse) | F (2WD gear), DT (4WD gear): 13.1 mph; HST (4WD): 12.7 mph | 15.1 mph |
|---|
| Clutch | F (2WD gear), DT (4WD gear), HST (4WD): dry type single stage | Not Published |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard | Rear differential lock, standard |
|---|
|
|---|
| Frame Type | Two-post foldable ROPS (factory certified) with retractable seat belt | Not Published |
|---|
| Steering | Integral power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc type, pedals can be locked together | Wet disc type, mechanically activated |
|---|
| Seat Suspension & Adjustability | Not Published | Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) |
|---|
| Front Axle Type | F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing | 4WD: Bevel gear front axle, non-adjustable tread spacing |
|---|
| Front Axle Rating | 2,865 lb (at 41.3 in tread, 2WD and 4WD models) | Not Published |
|---|
| Drawbar Capacity | 730 lb | 1,433 lb |
|---|
|
|---|
| Overall Width | 55.1 in | 66.5 in |
|---|
| Wheelbase | 63.3 in | 74.6 in |
|---|
| Ground Clearance | F (2WD gear): 13.6 in; DT (4WD gear), HST (4WD): 13.5 in | 14.2 in |
|---|
| Min. Turn Radius without Brakes | F (2WD gear): 8.9 ft; DT (4WD gear), HST (4WD): 10.5 ft | 8.9 ft (with brake applied) |
|---|
| Height to Top of ROPS | 97.1 in | 97.6 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | n/a (ROPS model) |
|---|
| Overall Length | F (2WD gear): 119.1 in; DT (4WD gear), HST (4WD): 116.3 in (with 3-point hitch) | 129.5 in (with 3-point hitch) |
|---|
|
|---|
| Tractor Weight (Base) | F (2WD gear): 2,557 lb; DT (4WD gear): 2,734 lb; HST (4WD): 2,778 lb | 3,759 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) | R1 Agricultural; R3 Turf; R4 Industrial |
|---|
| R1 Agricultural - Front | F (2WD gear): 5-15 (7.5L-15 optional); DT (4WD gear), HST (4WD): 7.2-16 | 8.3-16 |
|---|
| R1 Agricultural - Rear | 11.2-24 | 14.9-24 |
|---|
| R3 Turf - Front | F (2WD gear): 23x8.5-12; DT (4WD gear), HST (4WD): 25x8.5-14 | 27-10.50LL15 |
|---|
| R3 Turf - Rear | 13.6-16 | 41-18LLx16.1 |
|---|
| R4 Industrial - Front | 27x8.5-15 (4WD) | 10-16.5 |
|---|
| R4 Industrial - Rear | 15-19.5 (4WD) | 17.5L-24 |
|---|
|
|---|
| Quick Attach Loader System | LA525: 2-lever quick coupler, tool-free attach and detach | 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) |
|---|
| Loader Model | LA525 | LA805 |
|---|
| Loader Lift Height | LA525: 94.3 in (at pivot pin) | 104.7 in (at pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | LA525: 1,131 lb (at pivot pin) | 1,715 lb (at pivot pin) |
|---|
| Loader Breakout Force | LA525: 2,462 lbf (bucket pivot pin) | 2,549 lb |
|---|
|
|---|
| Warranty Length & Coverage | 24 months or 1500 hours (general) | Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours |
|---|
|
|---|
