▶ EngineEngine Manufacturer Kubota Kubota Engine Model V2403-CR-E4-GL2 V2403-CR-E4-LB1 Engine Type Liquid-cooled, 4-cycle multi valve, diesel, Naturally Aspirated Liquid-cooled, 4-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection No. of Cylinders 4 4 Displacement 148.5 in³ 148.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 42 hp 47.3 hp PTO Power 32.5 hp F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled, water with pressurized radiator Air Cleaner Dry paper, dual element Dry paper dual element Fuel System Electronic CRS (Common Rail System) Common rail (CRS) direct injection, electronic fuel injection Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Tandem pump - gear type Open center tandem pump, gear type Implement Flow 9.4 gpm 7.8 gpm Steering Flow 4.7 gpm 4.7 gpm Total Hydraulic Flow 14.1 gpm 12.5 gpm Overall Hydraulic Pump Flow 14.1 gpm 12.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None standard (up to 3 optional) Not Published No. of Optional Remote Valves Optional, up to 3 (double-acting valve or float detent valve options, any position) Up to 3 (self canceling detent valve or float detent valve options) ▶ Fluid CapacityFuel Tank Capacity 13.5 gal 13.5 gal Coolant Capacity 7.9 qt 6.9 qt Crankcase Capacity 8.7 qt 8.7 qt Transmission / Hydraulic System Capacity 11.4 gal 10.6 gal Front Axle Fluid Capacity 6.9 qt 6.9 qt ▶ PTO & HitchPTO Type Live independent (hydraulic clutch) Live independent PTO with hydraulic clutch PTO Rear 540 rpm @ 2476 engine rpm 540 rpm Mid-PTO Availability Optional No mid-PTO offered Category, 3-Point Hitch SAE Category I Category I Hitch Lift Capacity 3,858 lb 2870 lb Hitch Lift Capacity (at 24”) 2,756 lb 2310 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Hydrostatic F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range No. of Speeds 3-Range, 6 speeds (H-DS), infinitely variable in each F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range Max Travel Speed (Forward) 16.8 mph F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph Max Travel Speed (Reverse) 15.1 mph F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph Clutch Not Published F (2WD gear), DT (4WD gear): Dry type single stage; HST (4WD): No transmission clutch Differential Lock & Limited Slip Options Rear differential lock, standard Rear differential lock standard ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post foldable ROPS (factory certified) with retractable seat belt Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc type, mechanically activated Mechanical wet disc type, pedals can be locked together Seat Suspension & Adjustability Deluxe suspension seat with swivel (standard); Air-Ride seat (optional) Not Published Front Axle Type 4WD: Bevel gear front axle, non-adjustable tread spacing F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing Front Axle Rating Not Published F (2WD gear): 3300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3300 lb (at 45.5 in tread) Drawbar Capacity 1,433 lb 1430 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.5 in F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in Overall Width 66.5 in 62.4 in Wheelbase 74.6 in F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in Ground Clearance 14.2 in 15.2 in Min. Turn Radius without Brakes 8.9 ft (with brake applied) F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft Height to Top of ROPS 97.6 in 91.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Applicable Not Published ▶ WeightTractor Weight (Base) 3759 lb F (2WD gear): 3219 lb; DT (4WD gear): 3296 lb; HST (4WD): 3307 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) R1 Agricultural - Front 8.3-16 F (2WD gear): 7.5L-15 (6-16 optional); DT (4WD gear), HST (4WD): 8.3-16 R1 Agricultural - Rear 14.9-24 14.9-24 R3 Turf - Front 27X10.50LL-15 27x8.5-15 (2WD and 4WD; 27x10.5-15 optional on 4WD) R3 Turf - Rear 41X18LL-16.1 44x18-20 R4 Industrial - Front 10-16.5 10-16.5 (4WD) R4 Industrial - Rear 17.5L-24 17.5L-24 (4WD) ▶ Loader & AttachmentsQuick Attach Loader System Mechanical 2-Lever Quick Coupler (standard); Hydraulic 2-Lever Quick Coupler (optional); Single Lever Hose Quick Coupler (optional) 2-Lever Quick Coupler, no tools required to attach and detach loader Loader Model LA805 LA765 Loader Lift Height 104.7 in LA765: 105.2 in Loader Lift Capacity (Full Height) 1715 lb LA765: 1684 lb Loader Breakout Force 2549 lb (19.7 in forward of pivot pin) LA765: 3153 lbf ▶ WarrantyWarranty Length & Coverage Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours. Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
