| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V2403-CR-E4-LB1 | Not Published |
|---|
| Engine Type | Liquid-cooled, 4-cylinder, 4-cycle, multi-valve diesel, naturally aspirated, common rail direct injection | E-TVCS diesel, 4-cylinder, liquid-cooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 148.5 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 47.3 hp | 48 hp |
|---|
| PTO Power | F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp | 37.5 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid-cooled, water with pressurized radiator | Liquid-cooled |
|---|
| Air Cleaner | Dry paper dual element | Not Published |
|---|
| Fuel System | Common rail (CRS) direct injection, electronic fuel injection | Not Published |
|---|
| Alternator | 40 A, 12 V | Not Published |
|---|
|
|---|
| Pump Type | Open center tandem pump, gear type | Not Published |
|---|
| Implement Flow | 7.8 gpm | Not Published |
|---|
| Steering Flow | 4.7 gpm | Not Published |
|---|
| Total Hydraulic Flow | 12.5 gpm | 25.9 gpm |
|---|
| Overall Hydraulic Pump Flow | 12.5 gpm | 25.9 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | Not Published |
|---|
| No. of Optional Remote Valves | Up to 3 (self canceling detent valve or float detent valve options) | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 13.5 gal | 13.2 gal |
|---|
| Coolant Capacity | 6.9 qt | Not Published |
|---|
| Crankcase Capacity | 8.7 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 10.6 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 6.9 qt | Not Published |
|---|
|
|---|
| PTO Type | Live independent PTO with hydraulic clutch | Live-continuous running |
|---|
| PTO Rear | 540 rpm | 540 rpm |
|---|
| Mid-PTO Availability | No mid-PTO offered | Not Published |
|---|
| Category, 3-Point Hitch | Category I | Category I (standard) |
|---|
| Hitch Lift Capacity | 2870 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 2310 lb | 3310 lb |
|---|
| Lift Control Type | Position control (draft control optional) | Position control |
|---|
|
|---|
| Transmission Type | F (2WD gear), DT (4WD gear): Synchronized shuttle gear transmission, 8F/8R; HST (4WD): Hydrostatic transmission, 3-range | "Feather Step" hydrostatic transmission, 3-range |
|---|
| No. of Speeds | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range | 3-range (infinite) |
|---|
| Max Travel Speed (Forward) | F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph | 15.3 mph |
|---|
| Max Travel Speed (Reverse) | F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph | Not Published |
|---|
| Clutch | F (2WD gear), DT (4WD gear): Dry type single stage; HST (4WD): No transmission clutch | Dry, single |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard | Not Published |
|---|
|
|---|
| Frame Type | Two-post foldable ROPS (factory certified) with retractable seat belt | Four-post ROPS/FOPS standard |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc type, pedals can be locked together | Wet disc |
|---|
| Seat Suspension & Adjustability | Not Published | Movable seat, spins in place; tilt steering standard |
|---|
| Front Axle Type | F (2WD gear): Tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): Bevel gear front axle, non-adjustable tread spacing | Not Published |
|---|
| Front Axle Rating | F (2WD gear): 3300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3300 lb (at 45.5 in tread) | Not Published |
|---|
| Drawbar Capacity | 1430 lb | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in | Not Published |
|---|
| Overall Width | 62.4 in | 74.5 in |
|---|
| Wheelbase | F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in | 74.0 in |
|---|
| Ground Clearance | 15.2 in | Not Published |
|---|
| Min. Turn Radius without Brakes | F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft | 10.5 ft |
|---|
| Height to Top of ROPS | 91.7 in | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | F (2WD gear): 3219 lb; DT (4WD gear): 3296 lb; HST (4WD): 3307 lb | Not Published |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) | Industrial (R4): 10-16.5 R4 front, 17.5L-24 R4 rear |
|---|
| R1 Agricultural - Front | F (2WD gear): 7.5L-15 (6-16 optional); DT (4WD gear), HST (4WD): 8.3-16 | Not Published |
|---|
| R1 Agricultural - Rear | 14.9-24 | Not Published |
|---|
| R3 Turf - Front | 27x8.5-15 (2WD and 4WD; 27x10.5-15 optional on 4WD) | Not Published |
|---|
| R3 Turf - Rear | 44x18-20 | Not Published |
|---|
| R4 Industrial - Front | 10-16.5 (4WD) | 10-16.5 R4 |
|---|
| R4 Industrial - Rear | 17.5L-24 (4WD) | 17.5L-24 R4 |
|---|
|
|---|
| Quick Attach Loader System | 2-Lever Quick Coupler, no tools required to attach and detach loader | Not Published |
|---|
| Loader Model | LA765 | TL1150 |
|---|
| Loader Lift Height | LA765: 105.2 in | TL1150: 116.1 in |
|---|
| Loader Lift Capacity (Full Height) | LA765: 1684 lb | TL1150: 3000 lb |
|---|
| Loader Breakout Force | LA765: 3153 lbf | TL1150: 4375 lbf |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
