| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V2403-CR-E4-LB1 | V2403-CR-E5 |
|---|
| Engine Type | 4-cylinder, multi-valve, naturally aspirated, common-rail, liquid-cooled diesel | Direct injection, vertical, water-cooled 4-cycle, diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 148.5 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 47.3 hp | 48.4 hp |
|---|
| PTO Power | F (2WD gear), DT (4WD gear): 39.3 hp; HST (4WD): 37.8 hp | 40.5 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid-cooled, water with pressurized radiator | Water-cooled |
|---|
| Air Cleaner | Dry paper dual element | Dry type, primary and secondary element |
|---|
| Fuel System | Common-rail, direct injection, electronic control | Direct injection |
|---|
| Alternator | 40 A, 12 V | 45 A, 12 V |
|---|
|
|---|
| Pump Type | Open center tandem pump, gear type | Not Published |
|---|
| Implement Flow | 7.8 gpm | 7.8 gpm |
|---|
| Steering Flow | 4.7 gpm | 4.7 gpm |
|---|
| Total Hydraulic Flow | 12.5 gpm | 12.5 gpm (7.8 + 4.7, computed) |
|---|
| Overall Hydraulic Pump Flow | 12.5 gpm | 12.5 gpm (7.8 + 4.7, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | Not Published |
|---|
| No. of Optional Remote Valves | Up to 3: self-canceling detent valve or float detent valve | Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) |
|---|
|
|---|
| Fuel Tank Capacity | 13.5 gal | 13.5 gal |
|---|
| Coolant Capacity | 6.9 qt | 6.9 qt |
|---|
| Crankcase Capacity | 8.7 qt | 8.7 qt |
|---|
| Transmission / Hydraulic System Capacity | 10.6 gal | 10.6 gal |
|---|
| Front Axle Fluid Capacity | 6.9 qt | 6.9 qt |
|---|
|
|---|
| PTO Type | Live independent PTO with hydraulic clutch | Live independent PTO with hydraulic clutch |
|---|
| PTO Rear | 540 rpm | 540 rpm |
|---|
| Mid-PTO Availability | No mid-PTO offered | Not Published |
|---|
| Category, 3-Point Hitch | Category I | SAE Category I |
|---|
| Hitch Lift Capacity | 2,870 lb | 2,870 lb |
|---|
| Hitch Lift Capacity (at 24”) | 2,310 lb | 2,320 lb |
|---|
| Lift Control Type | Position control (draft control optional) | Position control |
|---|
|
|---|
| Transmission Type | F (2WD gear), DT (4WD gear): synchronized shuttle, 8F/8R; HST (4WD): hydrostatic, 3-range | Constant mesh with synchronized shuttle |
|---|
| No. of Speeds | F (2WD gear), DT (4WD gear): 8F/8R; HST (4WD): 3-range | 8 forward, 8 reverse |
|---|
| Max Travel Speed (Forward) | F (2WD gear), DT (4WD gear): 14.9 mph; HST (4WD): 15.8 mph | 12.9 mph |
|---|
| Max Travel Speed (Reverse) | F (2WD gear), DT (4WD gear): 14.3 mph; HST (4WD): 14.2 mph | 12.4 mph |
|---|
| Clutch | F (2WD gear), DT (4WD gear): dry type, single plate; HST (4WD): no transmission clutch | Dry type single stage |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard | Rear differential lock, pedal operated |
|---|
|
|---|
| Frame Type | Two-post foldable ROPS (factory certified) with retractable seat belt | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc type, pedals can be locked together | Mechanical, wet disc type |
|---|
| Seat Suspension & Adjustability | Not Published | Suspension seat with fore/aft travel adjustment and suspension tension adjustment |
|---|
| Front Axle Type | F (2WD gear): tubular steel, non-adjustable tread spacing; DT (4WD gear), HST (4WD): bevel-gear front axle, non-adjustable tread spacing | Cast-iron front axle |
|---|
| Front Axle Rating | F (2WD gear): 3,300 lb (at 50.4 in tread); DT (4WD gear), HST (4WD): 3,300 lb (at 45.5 in tread) | Not Published |
|---|
| Drawbar Capacity | 1,430 lb | 1,430 lb |
|---|
|
|---|
| Overall Width | 62.4 in | 52.7 in |
|---|
| Wheelbase | F (2WD gear): 72.8 in; DT (4WD gear), HST (4WD): 72.6 in | 72.6 in |
|---|
| Ground Clearance | 15.2 in | 11.5 in |
|---|
| Min. Turn Radius without Brakes | F (2WD gear): 10.2 ft; DT (4WD gear), HST (4WD): 11.5 ft | 8.9 ft (with brake applied) |
|---|
| Height to Top of ROPS | 91.7 in | 94.9 in (61.2 in with ROPS folded) |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
| Overall Length | F (2WD gear): 130.3 in; DT (4WD gear), HST (4WD): 127.4 in (with 3-point hitch) | 117.7 in (without 3-point hitch) |
|---|
|
|---|
| Tractor Weight (Base) | F (2WD gear): 3,219 lb; DT (4WD gear): 3,296 lb; HST (4WD): 3,307 lb | 3,362 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural (standard); R3 Turf; R4 Industrial (4WD) | Agricultural |
|---|
| R1 Agricultural - Front | F (2WD gear): 7.5L-15, 6-16; DT (4WD gear), HST (4WD): 8.3-16 | 7.2-16 |
|---|
| R1 Agricultural - Rear | 14.9-24 | 11.2-24 |
|---|
| R3 Turf - Front | 27x8.5-15 (2WD and 4WD); 27x10.5-15 (4WD) | Not Published |
|---|
| R3 Turf - Rear | 44x18-20 | Not Published |
|---|
| R4 Industrial - Front | 10-16.5 (4WD) | Not Published |
|---|
| R4 Industrial - Rear | 17.5L-24 (4WD) | Not Published |
|---|
|
|---|
| Quick Attach Loader System | 2-lever quick coupler, tool-free attach and detach | Not Published |
|---|
| Loader Model | LA765 | Not Published |
|---|
| Loader Lift Height | LA765: 105.2 in | Not Published |
|---|
| Loader Lift Capacity (Full Height) | LA765: 1,684 lb | Not Published |
|---|
| Loader Breakout Force | LA765: 3,153 lbf | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours |
|---|
|
|---|
