| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V2403-CR-E4-GL5 | V2403-CR-E5 |
|---|
| Engine Type | Naturally aspirated, multi-valve, liquid-cooled diesel | Direct injection, vertical, water-cooled 4-cycle, diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 148.5 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 49 hp | 48.4 hp |
|---|
| PTO Power | 39.5 hp | 40.5 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid-cooled | Water-cooled |
|---|
| Air Cleaner | Dry paper, dual element | Dry type, primary and secondary element |
|---|
| Fuel System | Electronic CRS (Common Rail System) | Direct injection |
|---|
| Alternator | 40 A, 12 V | 45 A, 12 V |
|---|
|
|---|
| Pump Type | Tandem pump - gear type | Not Published |
|---|
| Implement Flow | 9.4 gpm | 7.8 gpm |
|---|
| Steering Flow | 4.7 gpm | 4.7 gpm |
|---|
| Total Hydraulic Flow | 14.1 gpm | 12.5 gpm (7.8 + 4.7, computed) |
|---|
| Overall Hydraulic Pump Flow | 14.1 gpm | 12.5 gpm (7.8 + 4.7, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | None standard (up to 3 optional) | Not Published |
|---|
| No. of Optional Remote Valves | Optional, up to 3: double-acting valve or float detent valve, any position | Optional: double-acting valve, or double-acting valve with float position (float valve as second segment only) |
|---|
|
|---|
| Fuel Tank Capacity | 13.5 gal | 13.5 gal |
|---|
| Coolant Capacity | 8.7 qt | 6.9 qt |
|---|
| Crankcase Capacity | 8.7 qt | 8.7 qt |
|---|
| Transmission / Hydraulic System Capacity | 11.4 gal | 10.6 gal |
|---|
| Front Axle Fluid Capacity | 8.9 qt | 6.9 qt |
|---|
|
|---|
| PTO Type | Live independent (hydraulic clutch) | Live independent PTO with hydraulic clutch |
|---|
| PTO Rear | 540 rpm @ 2475 engine rpm | 540 rpm |
|---|
| Mid-PTO Availability | Optional | Not Published |
|---|
| Category, 3-Point Hitch | SAE Category I | SAE Category I |
|---|
| Hitch Lift Capacity | 3,858 lb | 2,870 lb |
|---|
| Hitch Lift Capacity (at 24”) | 2,756 lb | 2,320 lb |
|---|
| Lift Control Type | Position control | Position control |
|---|
|
|---|
| Transmission Type | Hydrostatic | Constant mesh with synchronized shuttle |
|---|
| No. of Speeds | 3-range, 6 speeds (H-DS), infinitely variable in each | 8 forward, 8 reverse |
|---|
| Max Travel Speed (Forward) | 16.8 mph | 12.9 mph |
|---|
| Max Travel Speed (Reverse) | 15.1 mph | 12.4 mph |
|---|
| Clutch | Not Published | Dry type single stage |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock, standard | Rear differential lock, pedal operated |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Wet disc type, mechanically activated | Mechanical, wet disc type |
|---|
| Seat Suspension & Adjustability | Deluxe suspension seat with swivel; Air-Ride seat (optional) | Suspension seat with fore/aft travel adjustment and suspension tension adjustment |
|---|
| Front Axle Type | 4WD: Bevel gear front axle, non-adjustable tread spacing | Cast-iron front axle |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | 1,433 lb | 1,430 lb |
|---|
|
|---|
| Overall Width | 66.5 in | 52.7 in |
|---|
| Wheelbase | 74.6 in | 72.6 in |
|---|
| Ground Clearance | 14.4 in | 11.5 in |
|---|
| Min. Turn Radius without Brakes | 8.9 ft (with brake applied) | 8.9 ft (with brake applied) |
|---|
| Height to Top of ROPS | 97.6 in | 94.9 in (61.2 in with ROPS folded) |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Applicable | Not Published |
|---|
| Overall Length | 129.5 in (with 3-point hitch) | 117.7 in (without 3-point hitch) |
|---|
|
|---|
| Tractor Weight (Base) | 3,847 lb | 3,362 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial | Agricultural |
|---|
| R1 Agricultural - Front | 8.3-16 | 7.2-16 |
|---|
| R1 Agricultural - Rear | 14.9-24 | 11.2-24 |
|---|
| R3 Turf - Front | 29x12.50-15 | Not Published |
|---|
| R3 Turf - Rear | 44x18-20 | Not Published |
|---|
| R4 Industrial - Front | 10-16.5 | Not Published |
|---|
| R4 Industrial - Rear | 17.5L-24 | Not Published |
|---|
|
|---|
| Quick Attach Loader System | 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) | Not Published |
|---|
| Loader Model | LA1105 | Not Published |
|---|
| Loader Lift Height | Not Published | Not Published |
|---|
| Loader Lift Capacity (Full Height) | Not Published | Not Published |
|---|
| Loader Breakout Force | LA555: 2,030 lb; LA805: 2,549 lb; LA1055: 3,171 lb | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours | Basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: powertrain 36 months or 2,000 hours |
|---|
|
|---|
