| Engine Manufacturer | Kubota | Mahindra |
|---|
| Engine Model | V2403-CR-E4-GL5 | Not Published |
|---|
| Engine Type | Naturally aspirated, multi-valve, liquid-cooled diesel | Naturally aspirated, direct injection, liquid-cooled diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 166.7 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2800 rpm |
|---|
| Engine Power (Gross) | 49 hp | 49 hp |
|---|
| PTO Power | 39.5 hp | HST: 40.5 hp; HST CAB: 39.5 hp; PST, PST CAB: 40 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid-cooled | Not Published |
|---|
| Air Cleaner | Dry paper, dual element | Not Published |
|---|
| Fuel System | Electronic CRS (Common Rail System) | Direct injection |
|---|
| Alternator | 40 A, 12 V | ROPS: 45 A, 12 V; Cab: 90 A, 12 V |
|---|
|
|---|
| Pump Type | Tandem pump - gear type | Not Published |
|---|
| Implement Flow | 9.4 gpm | 11 gpm |
|---|
| Steering Flow | 4.7 gpm | Not Published |
|---|
| Total Hydraulic Flow | 14.1 gpm | 16 gpm |
|---|
| Overall Hydraulic Pump Flow | 14.1 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Open Center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | None standard (up to 3 optional) | 1 |
|---|
| No. of Optional Remote Valves | Optional, up to 3: double-acting valve or float detent valve, any position | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 13.5 gal | HST, PST (ROPS): 11.3 gal; HST CAB, PST CAB: 14.5 gal |
|---|
| Coolant Capacity | 8.7 qt | Not Published |
|---|
| Crankcase Capacity | 8.7 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 11.4 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 8.9 qt | Not Published |
|---|
|
|---|
| PTO Type | Live independent (hydraulic clutch) | Independent |
|---|
| PTO Rear | 540 rpm @ 2475 engine rpm | 540 rpm @ 2405 rpm |
|---|
| Mid-PTO Availability | Optional | Not Published |
|---|
| Category, 3-Point Hitch | SAE Category I | CAT I & II with Telescoping Stabilizers & Flex Links |
|---|
| Hitch Lift Capacity | 3,858 lb | 3,090 lb |
|---|
| Hitch Lift Capacity (at 24”) | 2,756 lb | Not Published |
|---|
| Lift Control Type | Position control | Not Published |
|---|
|
|---|
| Transmission Type | Hydrostatic | HST: HST, 3 ranges; PST: Power Shuttle with Full Synchromesh |
|---|
| No. of Speeds | 3-range, 6 speeds (H-DS), infinitely variable in each | HST: Infinite; PST: 12F / 12R |
|---|
| Max Travel Speed (Forward) | 16.8 mph | Not Published |
|---|
| Max Travel Speed (Reverse) | 15.1 mph | Not Published |
|---|
| Clutch | Not Published | Wet |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock, standard | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering, tilt |
|---|
| Brakes | Wet disc type, mechanically activated | Oil Immersed Wet Disc Brakes |
|---|
| Seat Suspension & Adjustability | Deluxe suspension seat with swivel; Air-Ride seat (optional) | Not Published |
|---|
| Front Axle Type | 4WD: Bevel gear front axle, non-adjustable tread spacing | Not Published |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | 1,433 lb | Not Published |
|---|
|
|---|
| Overall Width | 66.5 in | HST: 75.4 in; HST CAB: 75.5 in; PST: 75.4 in; PST CAB: 74 in |
|---|
| Wheelbase | 74.6 in | 75 in |
|---|
| Ground Clearance | 14.4 in | 13.6 in |
|---|
| Min. Turn Radius without Brakes | 8.9 ft (with brake applied) | 10.3 ft |
|---|
| Height to Top of ROPS | 97.6 in | HST: 99.2 in; PST: 99.2 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Applicable | HST CAB: 101 in; PST CAB: 100.5 in |
|---|
| Overall Length | 129.5 in (with 3-point hitch) | 129 in |
|---|
|
|---|
| Tractor Weight (Base) | 3,847 lb | HST, PST: 4,620 lb (operating weight); HST CAB, PST CAB: 5,447 lb (operating weight) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural; R3 Turf (Option 1) or R3 LSW Turf (Option 2); R4 Industrial | Not Published |
|---|
| R1 Agricultural - Front | 8.3-16 | HST, HST CAB: 9.5-20; PST, PST CAB: 9.5-16 |
|---|
| R1 Agricultural - Rear | 14.9-24 | HST, HST CAB: 16.9-24; PST, PST CAB: 14.9-24 |
|---|
| R3 Turf - Front | 29x12.50-15 | 31 x 13.5 - 15 |
|---|
| R3 Turf - Rear | 44x18-20 | 21.5L - 16.1 |
|---|
| R4 Industrial - Front | 10-16.5 | 14 x 17.5 |
|---|
| R4 Industrial - Rear | 17.5L-24 | 19.5L x 24 |
|---|
|
|---|
| Quick Attach Loader System | 2-lever mechanical quick coupler (standard); 2-lever hydraulic quick coupler (optional); single-lever hose coupler (optional) | Not Published |
|---|
| Loader Model | LA1105 | HST, HST CAB, PST, PST CAB: 3650L (open station); 3650CL (cab) |
|---|
| Loader Lift Height | Not Published | 3650L: 111.5 in; 3650CL: 111.5 in |
|---|
| Loader Lift Capacity (Full Height) | Not Published | 3650L: 2,700 lb; 3650CL: 2,700 lb |
|---|
| Loader Breakout Force | LA555: 2,030 lb; LA805: 2,549 lb; LA1055: 3,171 lb | 3650L: 5,100 lb; 3650CL: 5,100 lb |
|---|
|
|---|
| Warranty Length & Coverage | Residential: basic 24 months or 1,500 hours, powertrain 72 months or 2,000 hours; commercial: basic 24 months or 1,500 hours, powertrain 36 months or 2,000 hours | Not Published |
|---|
|
|---|
| Accessories that fit | | None tagged yet |
|---|
