| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V3307-CR-TE4 | V3800CR-TIEF4 |
|---|
| Engine Type | 4-cylinder, turbocharged, common-rail diesel | 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 203 in³ | 230 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2400 rpm |
|---|
| Engine Power (Gross) | 71.1 hp | 92.5 hp |
|---|
| PTO Power | 60 hp | 76 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Liquid-cooled |
|---|
| Air Cleaner | Not Published | Dry paper, dual element, 8 in diameter, with pre-cleaner |
|---|
| Fuel System | Common rail direct injection | Common rail direct injection |
|---|
| Alternator | 130 A | 60 A |
|---|
|
|---|
| Pump Type | Not Published | Gear pump |
|---|
| Implement Flow | 16.7 gpm | 15.9 gpm |
|---|
| Steering Flow | 6.3 gpm | 5.4 gpm |
|---|
| Total Hydraulic Flow | 23.0 gpm (16.7 + 6.3, computed) | 21.3 gpm |
|---|
| Overall Hydraulic Pump Flow | 23.0 gpm (16.7 + 6.3, computed) | 21.3 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | 15.7 gpm |
|---|
| No. of Standard Remote Valves | 1 (SCD) | 2 standard (3 maximum) |
|---|
| No. of Optional Remote Valves | Max. 3 | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 23.8 gal | 27.7 gal |
|---|
| Coolant Capacity | 10.6 qt | 11 qt |
|---|
| Crankcase Capacity | 12.7 qt | 11.3 qt |
|---|
| Transmission / Hydraulic System Capacity | 49.6 qt | 63.4 qt |
|---|
| Front Axle Fluid Capacity | Not Published | 6.3 qt (differential) plus 3.7 qt (each bevel gear case) |
|---|
|
|---|
| PTO Type | Live-independent PTO, electro-hydraulic clutch with brake | Live-independent PTO, electro-hydraulic clutch with brake |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540 rpm (540/540E on 12-speed models) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I / II | Category II |
|---|
| Hitch Lift Capacity | Not Published | 7,055 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3,307 lb | 4,630 lb (8-speed); 6,063 lb (12-speed) |
|---|
| Lift Control Type | Position, draft (top link sensing) and mixed control | Position, draft (top link sensing) and mixed control |
|---|
|
|---|
| Transmission Type | Fully synchronized 6-speed main gear shift with electro-hydraulic shuttle, 12F/12R (option: 18F/18R with creep) | Fully synchronized main gear shift with electro-hydraulic shuttle |
|---|
| No. of Speeds | F12 / R12 (option: F18 / R18 with creep) | 8 forward, 8 reverse (8-speed models); 12 forward, 12 reverse (12-speed models) |
|---|
| Max Travel Speed (Forward) | Not Published | 17.7 mph (8-speed); 22.6 mph (12-speed) |
|---|
| Max Travel Speed (Reverse) | Not Published | 8-speed: 18.4 mph; 12-speed: 23.5 mph |
|---|
| Clutch | Multiple wet disc | Multiple wet disc |
|---|
| Differential Lock & Limited Slip Options | Front: limited-slip differential; Rear: mechanical differential lock | Front: limited-slip differential; Rear: mechanical differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Hydraulic wet disc | Hydraulic wet disc |
|---|
| Seat Suspension & Adjustability | Not Published | Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest |
|---|
| Front Axle Type | Bevel gear type (4WD, mechanical on-the-go 4WD clutch) | Bevel gear type with 55 degree turning angle (4WD) |
|---|
| Front Axle Rating | Not Published | 5,730 lb |
|---|
| Drawbar Capacity | Not Published | 3,300 lb |
|---|
|
|---|
| Overall Width | 75.6 in | 78.3 in |
|---|
| Wheelbase | 84.1 in | 88.6 in |
|---|
| Ground Clearance | 18.1 in (front axle crop clearance) | 17.7 in (minimum, drawbar bracket) |
|---|
| Min. Turn Radius without Brakes | 11.8 ft | 13.8 ft |
|---|
| Height to Top of ROPS | Not Published | 98.9 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 101 in | Not Applicable |
|---|
| Overall Length | 144 in | 155.9 in |
|---|
|
|---|
| Tractor Weight (Base) | 5,952 lb | 6,151 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Standard: 320/70R24 front, 420/75R34 rear | Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 |
|---|
| R1 Agricultural - Front | 320/70R24 | 11.2-24 |
|---|
| R1 Agricultural - Rear | 420/75R34 | 18.4-30 |
|---|
| R3 Turf - Front | 9.50-24 | 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) |
|---|
| R3 Turf - Rear | 18.4-26 | 18.4-26 R3 or 19.5L-24 R3 |
|---|
| R4 Industrial - Front | 14-17.5 | 9.5L-15 F2 (rib front paired with the R4 rear) |
|---|
| R4 Industrial - Rear | 16.9-24 | 19.5L-24 R4 |
|---|
|
|---|
| Quick Attach Loader System | Not Published | Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional |
|---|
| Loader Model | LA1154A | LA1854 |
|---|
| Loader Lift Height | LA1154A: 133.0 in (height position); 117.6 in (power position) | 145.7 in (height position); 131.9 in (power position) |
|---|
| Loader Lift Capacity (Full Height) | LA1154A: 2,674 lb (height position); 2,928 lb (power position) | 3,990 lb (height position); 4,144 lb (power position) |
|---|
| Loader Breakout Force | LA1154A: 4,079 lbf (height position); 5,128 lbf (power position) | LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) |
|---|
|
|---|
| Warranty Length & Coverage | Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours, all usage | Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours |
|---|
