| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | F2803-ELA | V3307-DI |
|---|
| Engine Type | Vertical, water-cooled, 4-cycle diesel, 5-cylinder | 4-cylinder inline, direct injected diesel |
|---|
| No. of Cylinders | 5 | 4 |
|---|
| Displacement | 167.6 in³ | 203 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 54 hp | Not Published |
|---|
| PTO Power | 45 hp | 55 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 2 |
|---|
| Cooling System Type | Water-cooled | Liquid-cooled |
|---|
| Air Cleaner | Dual dry elements | 8 in dry, dual element |
|---|
| Fuel System | Not Published | Direct injection |
|---|
| Alternator | Not Published | ROPS: 45 A, 12 V; Cab: 60 A, 12 V |
|---|
|
|---|
| Pump Type | Not Published | Not Published |
|---|
| Implement Flow | Not Published | 11.0 gpm |
|---|
| Steering Flow | Not Published | 6.1 gpm |
|---|
| Total Hydraulic Flow | 17.1 gpm | 17.1 gpm (11.0 + 6.1, computed) |
|---|
| Overall Hydraulic Pump Flow | Not Published | 17.1 gpm (11.0 + 6.1, computed) |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | 11.0 gpm |
|---|
| No. of Standard Remote Valves | 1 | 1 |
|---|
| No. of Optional Remote Valves | Not Published | 2nd and 3rd optional |
|---|
|
|---|
| Fuel Tank Capacity | ROPS: 17.2 gal; Cab: 25.1 gal | ROPS: 18.5 gal; Cab: 29.1 gal |
|---|
| Coolant Capacity | 7.7 qt | 8.5 qt |
|---|
| Crankcase Capacity | 8.5 qt | 11.6 qt |
|---|
| Transmission / Hydraulic System Capacity | Not Published | 59.2 qt |
|---|
| Front Axle Fluid Capacity | Not Published | Front differential case: 5.8 qt; front axle gear case: 3.7 qt each side |
|---|
|
|---|
| PTO Type | Live | Live, independent PTO, hydraulically operated wet clutch with PTO brake |
|---|
| PTO Rear | 540 rpm | 540 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II/I | Category I and II |
|---|
| Hitch Lift Capacity | 4,200 lb | 4,189 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3,307 lb | 3,307 lb |
|---|
| Lift Control Type | Position, draft and mix control | Position, draft (top link sensing) and mix control |
|---|
|
|---|
| Transmission Type | Synchronized shuttle, 8F/8R (12F/12R with creeper) | Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models |
|---|
| No. of Speeds | 8F/8R (12F/12R with creeper) | 8F/8R (12F/12R with optional creep) |
|---|
| Max Travel Speed (Forward) | Not Published | 17.8 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | 18.0 mph |
|---|
| Clutch | Not Published | Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) |
|---|
| Differential Lock & Limited Slip Options | Not Published | Rear differential lock (bevel gears) |
|---|
|
|---|
| Frame Type | Not Published | Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc | Multiple wet disc, mechanical |
|---|
| Seat Suspension & Adjustability | Not Published | Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) |
|---|
| Front Axle Type | Not Published | 4WD: bevel-gear type, on-the-go engagement |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | 2,200 lb |
|---|
|
|---|
| Overall Width | 67.2 in (minimum) | 73.2 in |
|---|
| Wheelbase | ROPS: 78.7 in; Cab: 81.7 in | 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in |
|---|
| Ground Clearance | 16.9 in | 15.4 in |
|---|
| Min. Turn Radius without Brakes | Not Published | 2WD: 11.2 ft; 4WD: 11.8 ft |
|---|
| Height to Top of ROPS | 93.0 in | 96.9 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 98.1 in | 99.8 in |
|---|
| Overall Length | 2WD ROPS: 137.6 in; 4WD ROPS: 134.1 in; 2WD cab: 140.6 in; 4WD cab: 137.1 in | 2WD: 140.4 in; 4WD: 135.6 in |
|---|
|
|---|
| Tractor Weight (Base) | 2WD ROPS: 3,748 lb; 4WD ROPS: 3,968 lb | 2WD ROPS: 4,650 lb; 4WD ROPS: 4,785 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Standard: 6.5-16 front (2WD), 9.5-22 front (4WD), 14.9-28 rear | Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear |
|---|
| R1 Agricultural - Front | 8.3-24 | 2WD: 7.5-16; 4WD: 9.5-24 |
|---|
| R1 Agricultural - Rear | 14.9-28 | 16.9-28 |
|---|
| R3 Turf - Front | 2WD: 9.00-10; 4WD: 29x12.5-15 | 2WD: 29x12.5-15 or 27x9.5-15 |
|---|
| R3 Turf - Rear | 21.5L-16.1 R3 | 2WD: 21.5L-16.1 or 16.9-24 |
|---|
| R4 Industrial - Front | 12.5/80-18 R4 | 12.5/80-18 (4WD) |
|---|
| R4 Industrial - Rear | 16.9-24 R4 | 16.9-24 (4WD) |
|---|
|
|---|
| Quick Attach Loader System | Not Published | LA1153: two-lever quick coupler |
|---|
| Loader Model | LA1002 | LA1153 |
|---|
| Loader Lift Height | LA1002: 115.6 in | LA1153 height position: 132.7 in; LA1153 power position: 117.2 in |
|---|
| Loader Lift Capacity (Full Height) | LA1002: 2,579 lb (at pivot pin) | Not Published |
|---|
| Loader Breakout Force | LA1002: 3,330 lbf | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
