Live-independent PTO, electro-hydraulic clutch with brake
Live-independent PTO, electro-hydraulic clutch with brake
PTO Rear
540/540E rpm
540/540E rpm
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
I / II
I / II
Hitch Lift Capacity
4189 lb
4189 lb
Hitch Lift Capacity (at 24”)
3307 lb
3307 lb
Lift Control Type
Position, draft (top link sensing) & mixed control
Position, draft (top link sensing) & mixed control
Transmission Type
12-speed electro-hydraulic shuttle (option: 18-speed with creep)
12-speed electro-hydraulic shuttle (option: 18-speed with creep)
No. of Speeds
F12/R12 (option: F18/R18 with creep)
F12/R12 (option: F18/R18 with creep)
Max Travel Speed (Forward)
24.9 mph
24.9 mph
Max Travel Speed (Reverse)
24.7 mph
24.7 mph
Clutch
Multiple wet disc
Multiple wet disc
Differential Lock & Limited Slip Options
Front limited slip differential; Rear differential lock (mechanical)
Front limited slip differential; Rear differential lock (mechanical)
Frame Type
Ultra Grand Cab II
Ultra Grand Cab II
Steering
Hydrostatic power steering
Hydrostatic power steering
Brakes
Hydraulic wet disc
Hydraulic wet disc
Seat Suspension & Adjustability
Deluxe mechanical suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air ride seat
Deluxe mechanical suspension seat with adjustable armrest, seat height, weight (suspension) and backrest tilt; optional air ride seat
Front Axle Type
Bevel gear type (4WD)
Bevel gear type (4WD)
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
2200 lb
2200 lb
Overall Length with 3-Point Hitch
142 in
142 in
Overall Width
75.6 in
75.6 in
Wheelbase
84.1 in
84.1 in
Ground Clearance
18.1 in
18.1 in
Min. Turn Radius without Brakes
11.8 ft
11.8 ft
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
101 in
101 in
Tractor Weight (Base)
6008 lb
6008 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Standard: 320/70R24 front, 420/75R34 rear
Standard: 320/70R24 front, 420/75R34 rear
R1 Agricultural - Front
320/70R24
320/70R24
R1 Agricultural - Rear
420/75R34
420/75R34
R3 Turf - Front
9.50-24
9.50-24
R3 Turf - Rear
18.4-26
18.4-26
R4 Industrial - Front
14-17.5
14-17.5
R4 Industrial - Rear
16.9-24
16.9-24
Quick Attach Loader System
LA1154A: 2-Lever Quick Coupler
LA1154A: 2-Lever Quick Coupler
Loader Model
LA1154A
LA1154A
Loader Lift Height
LA1154A: Height position: 133.0 in; Power position: 117.6 in
LA1154A: Height position: 133.0 in; Power position: 117.6 in
Loader Lift Capacity (Full Height)
LA1154A: Height position: 2674 lb; Power position: 2928 lb
LA1154A: Height position: 2674 lb; Power position: 2928 lb
Loader Breakout Force
LA1154A: Height position: 4079 lbf; Power position: 5128 lbf
LA1154A: Height position: 4079 lbf; Power position: 5128 lbf
Warranty Length & Coverage
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 36 months or 2000 hours.
