| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V3800CR-TIEF4 | V3800-TI-CRS |
|---|
| Engine Type | 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR | 4-cylinder, turbocharged and intercooled, common-rail, liquid-cooled diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 230 in³ | 230 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 92.5 hp | 114.1 hp |
|---|
| PTO Power | 76 hp | 92 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Liquid-cooled, pressurized radiator, recovery tank |
|---|
| Air Cleaner | Dry paper, dual element, 8 in diameter, with pre-cleaner | 8 in dry, dual element |
|---|
| Fuel System | Common rail direct injection | Common rail direct injection |
|---|
| Alternator | 80 A | 130 A, 12 V |
|---|
|
|---|
| Pump Type | Gear pump | Gear pumps |
|---|
| Implement Flow | 17.0 gpm | 18.7 gpm |
|---|
| Steering Flow | 6.1 gpm | 16.0 gpm |
|---|
| Total Hydraulic Flow | 23.1 gpm | 34.7 gpm (18.7 + 16.0, computed) |
|---|
| Overall Hydraulic Pump Flow | 23.1 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Pressure compensated, fixed displacement |
|---|
| Rear Remote Hydraulic Flow | 17.0 gpm | 18.7 gpm |
|---|
| No. of Standard Remote Valves | 2 standard (3 maximum) | 2 (with built-in flow control) |
|---|
| No. of Optional Remote Valves | Not Published | 3rd and 4th optional (4 max) |
|---|
|
|---|
| Fuel Tank Capacity | 27.7 gal | 50.2 gal |
|---|
| Coolant Capacity | 11 qt | 11.3 qt |
|---|
| Crankcase Capacity | 11.3 qt | 11.3 qt |
|---|
| Transmission / Hydraulic System Capacity | 63.4 qt | 17.2 gal |
|---|
| Front Axle Fluid Capacity | 6.3 qt (differential) plus 3.7 qt (each bevel gear case) | 7.2 qt (differential) plus 3.8 qt per bevel gear case |
|---|
|
|---|
| PTO Type | Live-independent PTO, electro-hydraulic clutch with brake | Live, independent PTO, hydraulically operated wet clutch with PTO brake |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540/1000 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II |
|---|
| Hitch Lift Capacity | 7,055 lb | 8,598 lb |
|---|
| Hitch Lift Capacity (at 24”) | 4,630 lb | 6,834 lb (optional 9,447 lb) |
|---|
| Lift Control Type | Position, draft (top link sensing) and mixed control | Electronic draft control, lower-link sensing; left fender-mounted hitch switch standard |
|---|
|
|---|
| Transmission Type | Fully synchronized main gear shift with electro-hydraulic shuttle | 24F/24R powershift (8-speed main, 3-speed mechanical range, clutch button, microprocessor-controlled electro-hydraulic shuttle); 32F/32R optional with creep |
|---|
| No. of Speeds | 8 forward, 8 reverse | 24F/24R (32F/32R with optional creep) |
|---|
| Max Travel Speed (Forward) | 19.2 mph | 23.4 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | 22.33 mph (with 18.4R38 tires, at rated rpm) |
|---|
| Clutch | Multiple wet disc | Multiple wet disc, electro-hydraulically operated, 5.2 in |
|---|
| Differential Lock & Limited Slip Options | Front: limited-slip differential; Rear: mechanical differential lock | Electro-hydraulic front differential lock; rear differential lock standard |
|---|
|
|---|
| Frame Type | Not Published | Certified ROPS cab standard |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Hydraulic wet disc | Hydraulically operated wet disc brakes with automatic front axle engagement (4WD) |
|---|
| Seat Suspension & Adjustability | Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest | Air-suspension seat, swivel, reclining, fully adjustable (height, weight, fore-aft), armrests, retractable seat belt |
|---|
| Front Axle Type | Bevel gear type with 55 degree turning angle (4WD) | 4WD, bevel-gear type, on-the-go electro-hydraulic engagement, electro-hydraulic front differential lock |
|---|
| Front Axle Rating | 5,730 lb | 6,610 lb at 62.2 in tread (9,700 lb with loader) |
|---|
| Drawbar Capacity | 3,300 lb | Not Published |
|---|
|
|---|
| Overall Width | 78.3 in | 82.7 in |
|---|
| Wheelbase | 88.6 in | 95.9 in |
|---|
| Ground Clearance | 17.7 in (minimum, drawbar bracket) | 19.5 in (crop clearance) |
|---|
| Min. Turn Radius without Brakes | 13.8 ft | 13.1 ft (with Bi-Speed turn, 4WD on) |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 100.2 in | 111.8 in |
|---|
| Overall Length | 155.9 in | 165.4 in |
|---|
|
|---|
| Tractor Weight (Base) | 6,900 lb | 9,788 lb (with standard tire) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 | Standard: 13.6 R24 front, 18.4 R34 rear (R1 options 12.4-24, 13.6-24 front; 16.9-34, 18.4R30, 18.4-34 rear) |
|---|
| R1 Agricultural - Front | 11.2-24 | 13.6 R24 |
|---|
| R1 Agricultural - Rear | 18.4-30 | 18.4 R34 |
|---|
| R3 Turf - Front | 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) | Not Published |
|---|
| R3 Turf - Rear | 18.4-26 R3 or 19.5L-24 R3 | Not Published |
|---|
| R4 Industrial - Front | 9.5L-15 F2 (rib front paired with the R4 rear) | Not Published |
|---|
| R4 Industrial - Rear | 19.5L-24 R4 | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional | LA1955: 2-lever quick coupler or Euro quick coupler; single-lever hydraulic quick coupler; quick attach/detach loader with boom stands, two mounting pins |
|---|
| Loader Model | LA1854 | LA1955 |
|---|
| Loader Lift Height | 145.7 in (height position); 131.9 in (power position) | LA1955 (height position): 145.7 in; LA1955 (power position): 132.7 in |
|---|
| Loader Lift Capacity (Full Height) | 3,990 lb (height position); 4,144 lb (power position) | LA1955 (height position): 4,178 lb at pivot pin; LA1955 (power position): 4,299 lb at pivot pin |
|---|
| Loader Breakout Force | LA1854: 5,501 lb at bucket pivot pin (height position); 6,470 lb at bucket pivot pin (power position) | LA1955 (height position): 5,589 lbf at pivot pin; LA1955 (power position): 6,576 lbf at pivot pin |
|---|
|
|---|
| Warranty Length & Coverage | Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours | Not Published |
|---|
