| Engine Manufacturer | Kubota | FPT |
|---|
| Engine Model | V3800CR-TIEF4 | F5G |
|---|
| Engine Type | 4-cylinder, turbocharged and intercooled, common-rail diesel, DPF, DOC and SCR | Dual Command: 4-cylinder diesel; Electro Command: turbo diesel with high-pressure common rail and electronic fuel delivery control |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 230 in³ | 207 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2200 rpm |
|---|
| Engine Power (Gross) | 105.6 hp | 107 hp |
|---|
| PTO Power | 89 hp | 93 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4B Final |
|---|
| Cooling System Type | Liquid-cooled | Liquid cooled |
|---|
| Air Cleaner | Dry paper, dual element, 8 in diameter, with pre-cleaner | Not Published |
|---|
| Fuel System | Common rail direct injection | Electro Command: high-pressure common-rail, electronic fuel delivery control |
|---|
| Alternator | 60 A | 120 A |
|---|
|
|---|
| Pump Type | Gear pump | Fixed displacement, tandem pumps (implement and steering) |
|---|
| Implement Flow | 15.7 gpm | Dual Command: 16.9 gpm; Electro Command: 21.1 gpm |
|---|
| Steering Flow | 5.4 gpm | Dual Command: 9.7 gpm; Electro Command: 11.4 gpm |
|---|
| Total Hydraulic Flow | 21.3 gpm | Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) |
|---|
| Overall Hydraulic Pump Flow | 21.3 gpm | Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) |
|---|
| Hydraulic System Type | Open center | Not Published |
|---|
| Rear Remote Hydraulic Flow | 15.7 gpm | Not Published |
|---|
| No. of Standard Remote Valves | 2 (max 3) | Dual Command: 2 or 3; Electro Command: 2 |
|---|
| No. of Optional Remote Valves | 1 (3 maximum) | Electro Command: 3 rear remotes (mechanical, 2 with configurable detents) |
|---|
|
|---|
| Fuel Tank Capacity | 27.7 gal | Electro Command: 43.6 gal |
|---|
| Coolant Capacity | 11 qt | Not Published |
|---|
| Crankcase Capacity | 11.3 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 63.4 qt | Not Published |
|---|
| Front Axle Fluid Capacity | 6.3 qt (differential) plus 3.7 qt (each bevel gear case) | Not Published |
|---|
|
|---|
| PTO Type | Live-independent PTO, electro-hydraulic clutch with brake | Independent (hydraulic wet disc clutch) |
|---|
| PTO Rear | 540 rpm (540/540E optional) | Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II |
|---|
| Hitch Lift Capacity | 7,055 lb (8,600 lb optional) | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 5,181 lb | Dual Command: 5,620 lb (7,351 lb with optional ram) |
|---|
| Lift Control Type | Position, draft (top link sensing) and mixed control | Not Published |
|---|
|
|---|
| Transmission Type | Fully synchronized main gear shift with electro-hydraulic shuttle | Dual Command: 24x24 Hi-Lo with power shuttle (standard); Electro Command: 16x16 semi-powershift (auto-shift or 32x32 creeper optional) |
|---|
| No. of Speeds | 8 forward, 8 reverse | Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) |
|---|
| Max Travel Speed (Forward) | 18.6 mph | 25 mph |
|---|
| Max Travel Speed (Reverse) | 18.4 mph | Not Published |
|---|
| Clutch | Multiple wet disc | Not Published |
|---|
| Differential Lock & Limited Slip Options | Front: limited-slip differential; Rear: mechanical differential lock | Optional TerraLock automatic 4WD engagement and differential lock system (Electro Command) |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Power steering |
|---|
| Brakes | Hydraulic wet disc | Hydraulic wet disc |
|---|
| Seat Suspension & Adjustability | Suspension seat with fore and aft travel adjustment, suspension tension knob, backrest tilt adjustment and arm rest | Not Published |
|---|
| Front Axle Type | Bevel gear type with 55 degree turning angle (4WD) | Electro Command: 4WD front axle, Class 1.5 HD (TerraGlide suspended 4WD front axle optional) |
|---|
| Front Axle Rating | 5,730 lb | Not Published |
|---|
| Drawbar Capacity | 3,300 lb | Not Published |
|---|
|
|---|
| Overall Width | 79.1 in | Dual Command: 75.7 in |
|---|
| Wheelbase | 88.6 in | Dual Command: 89.9 in; Electro Command: 93.7 in |
|---|
| Ground Clearance | 17.7 in (drawbar bracket) | Not Published |
|---|
| Min. Turn Radius without Brakes | 13.8 ft | Not Published |
|---|
| Height to Top of ROPS | 99.8 in | Dual Command: 106.5 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Applicable | Dual Command: 102.1 in; Electro Command: 107 in |
|---|
| Overall Length | 155.9 in | Dual Command: 160.9 in; Electro Command: 165 in |
|---|
|
|---|
| Tractor Weight (Base) | 6,283 lb | Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb (shipping weight) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Front: 7.50-18, 9.5L-15, 9.5-22, 10.00-16, 11.2-24, 12.4-24; Rear: 16.9-30, 16.9-34, 18.4-30 | Not Published |
|---|
| R1 Agricultural - Front | 12.4-24 | 14.9R24 |
|---|
| R1 Agricultural - Rear | 18.4-30 | 18.4R34 |
|---|
| R3 Turf - Front | 9.5L-15 F2 or 27x9.50-15 HF-1 (rib fronts paired with the R3 rears) | Not Published |
|---|
| R3 Turf - Rear | 18.4-26 R3 or 19.5L-24 R3 | Not Published |
|---|
| R4 Industrial - Front | 9.5L-15 F2 (rib front paired with the R4 rear) | Not Published |
|---|
| R4 Industrial - Rear | 19.5L-24 R4 | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Quick coupler, standard; Euro-type quick coupler, optional; tool-free attach and detach; single-lever hydraulic hose coupler, optional | Skid-steer style or Euro (European) style tool carrier |
|---|
| Loader Model | LA1854 | 810LA (NSL); 815LA (MSL) |
|---|
| Loader Lift Height | 145.7 in (height position); 131.9 in (power position) | 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | 3,990 lb (height position); 4,144 lb (power position) | 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) |
|---|
| Loader Breakout Force | LA1854: 5,501 lbf (height position); 6,470 lbf (power position) | 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) |
|---|
|
|---|
| Warranty Length & Coverage | Basic 24 months or 2,000 hours, powertrain 36 months or 3,000 hours | Not Published |
|---|
