| Engine Manufacturer | Kubota | Kubota |
|---|
| Engine Model | V2403-CR-TE4 | V3307-DI |
|---|
| Engine Type | 4-cylinder in-line, common rail direct injection, turbocharged diesel | 4-cylinder inline, direct injected diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 148.5 in³ | 203 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 57.9 hp | Not Published |
|---|
| PTO Power | 50 hp | 55 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 2 |
|---|
| Cooling System Type | Liquid-cooled, pressurized radiator with recovery tank | Liquid-cooled |
|---|
| Air Cleaner | Dry paper dual element, 8 in diameter, pre-cleaner standard | 8 in dry, dual element |
|---|
| Fuel System | Common rail direct injection | Direct injection |
|---|
| Alternator | 45 A | ROPS: 45 A, 12 V; Cab: 60 A, 12 V |
|---|
|
|---|
| Pump Type | Gear pump | Not Published |
|---|
| Implement Flow | 10.6 gpm | 11.0 gpm |
|---|
| Steering Flow | 6.1 gpm | 6.1 gpm |
|---|
| Total Hydraulic Flow | 16.5 gpm | 17.1 gpm (11.0 + 6.1, computed) |
|---|
| Overall Hydraulic Pump Flow | 16.5 gpm | 17 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | 11.0 gpm |
|---|
| No. of Standard Remote Valves | 1 (SCD) | 1 |
|---|
| No. of Optional Remote Valves | 2 optional (3 maximum) | 2nd and 3rd optional |
|---|
|
|---|
| Fuel Tank Capacity | 17.7 gal | ROPS: 18.5 gal; Cab: 29.1 gal |
|---|
| Coolant Capacity | 8.5 qt | 8.5 qt |
|---|
| Crankcase Capacity | 7.6 qt | 11.6 qt |
|---|
| Transmission / Hydraulic System Capacity | 50.7 qt | 10.6 gal |
|---|
| Front Axle Fluid Capacity | No front axle oil, 2WD (M5660SUH); 6.9 qt front differential case plus 3.2 qt per bevel gear case (M5660SUHD) | 8.5 qt |
|---|
|
|---|
| PTO Type | Hydraulic independent PTO, self-modulating multi-plate wet clutch with brake | Live independent PTO, hydraulically operated wet clutch with PTO brake |
|---|
| PTO Rear | 540 rpm (540/540E optional) | 540 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I and II | Category II |
|---|
| Hitch Lift Capacity | 4189 lb | 4189 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3307 lb | 3307 lb |
|---|
| Lift Control Type | Position control | Position, draft (top link sensing) and mix control |
|---|
|
|---|
| Transmission Type | Fully synchronized 4-speed main gear shift with hi-lo range and hydraulic shuttle, 8F/8R | Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models |
|---|
| No. of Speeds | 8F/8R | 8F/8R (12F/12R with optional creep) |
|---|
| Max Travel Speed (Forward) | 18.2 mph | 18 mph |
|---|
| Max Travel Speed (Reverse) | 18.6 mph | 18.0 mph |
|---|
| Clutch | Multiple wet disc | Dry single plate (synchro shuttle) / multiple wet disks (hydraulic shuttle) |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock standard (mechanical) | Rear differential lock (bevel gears) |
|---|
|
|---|
| Frame Type | Not Published | Two-post foldable ROPS (canopy optional); Ultra Grand Cab optional |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering |
|---|
| Brakes | Mechanical wet disc | Multiple wet disc, mechanical |
|---|
| Seat Suspension & Adjustability | Fully adjustable suspension seat with retractable seat belt | Reclining, fully adjustable seat (height, weight, fore and aft, arm rests) with retractable seat belt; optional air ride seat suspension (cab) |
|---|
| Front Axle Type | Adjustable tubular steel, 2WD (M5660SUH); Cast iron bevel pinion drive with 55 degree turning angle, 4WD (M5660SUHD) | 4WD: Bevel gear type with Easy-To-Shift 4WD engagement while rolling |
|---|
| Front Axle Rating | 4410 lb at 55.9 in tread spacing (M5660SUH); 5290 lb at 55.9 in tread spacing (M5660SUHD) | Not Published |
|---|
| Drawbar Capacity | 2200 lb | 2200 lb |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 138.7 in (M5660SUH); 136 in (M5660SUHD) | 2WD: 140.4 in; 4WD: 135.6 in |
|---|
| Overall Width | 73.2 in | 73.2 in |
|---|
| Wheelbase | 82 in (M5660SUH); 80.7 in (M5660SUHD) | 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in |
|---|
| Ground Clearance | 16.3 in | 15.4 in |
|---|
| Min. Turn Radius without Brakes | 10.8 ft (M5660SUH); 12.8 ft (M5660SUHD) | 2WD: 11.2 ft; 4WD: 11.8 ft |
|---|
| Height to Top of ROPS | 95.3 in | 96.9 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | 99.8 in |
|---|
|
|---|
| Tractor Weight (Base) | 4189 lb (M5660SUH); 4387 lb (M5660SUHD) | 2WD ROPS: 4650 lb; 4WD ROPS: 4785 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 2WD: 6.50-16, 7.5-16, 9.5L-15 fronts with 14.9-28 or 16.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1 and LSW; 4WD: 9.5-22 or 280/85R20 fronts with 14.9-28 R1 rears; R3 29x12.50-15 / 21.5L-16.1; R4 12.5/80-18 / 16.9-24 | Standard: 7.50-16 (2WD) or 9.5-24 (4WD) front, 16.9-28 rear |
|---|
| R1 Agricultural - Front | 6.5-16 (M5660SUH); 8.3-24 (M5660SUHD) | 2WD: 7.50-16; 4WD: 9.5-24 |
|---|
| R1 Agricultural - Rear | 14.9-28 | 16.9-28 |
|---|
| R3 Turf - Front | 29x12.50-15 | 2WD: 29x12.5-15 or 27x9.5-15 |
|---|
| R3 Turf - Rear | 21.5L-16.1 | 2WD: 21.5L-16.1 or 16.9-24 |
|---|
| R4 Industrial - Front | 12.5/80-18 (M5660SUHD) | 12.5/80-18 (4WD) |
|---|
| R4 Industrial - Rear | 16.9-24 (M5660SUHD) | 16.9-24 (4WD) |
|---|
|
|---|
| Quick Attach Loader System | LA1154SU: 2-lever quick attach coupler standard | LA1153: two-lever quick coupler |
|---|
| Loader Model | LA1154SU (printed LA1154 in the 2014 brochure) | LA1153 |
|---|
| Loader Lift Height | LA1154: 130.9 in (height position); 115.7 in (power position) | LA1153 height position: 132.7 in; LA1153 power position: 117.2 in |
|---|
| Loader Lift Capacity (Full Height) | LA1154: 2469 lb (height position); 2928 lb (power position) | Not Published |
|---|
| Loader Breakout Force | LA1154SU: 4230 lbf (height position); 5354 lbf (power position) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | All usage - Basic Standard Limited: 24 months or 2000 hours; Limited Powertrain: 36 months or 3000 hours. | Not Published |
|---|
