| Engine Manufacturer | Kubota | Mahindra |
|---|
| Engine Model | V3307-DI | VNEM 363 |
|---|
| Engine Type | 4-cylinder inline, direct injected diesel | Turbocharged and intercooled, common-rail, liquid-cooled diesel (Tier 4 Final) |
|---|
| No. of Cylinders | 4 | 3 |
|---|
| Displacement | 203 in³ | 161.7 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2100 rpm |
|---|
| Engine Power (Gross) | Not Published | 62 hp |
|---|
| PTO Power | 62 hp | 53.5 hp |
|---|
| Engine Emissions Constraints | Tier 2 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Water-cooled |
|---|
| Air Cleaner | 8 in dry, dual element | Not Published |
|---|
| Fuel System | Direct injection | Common rail direct injection |
|---|
| Alternator | ROPS: 45 A, 12 V; Cab: 60 A, 12 V | Power Shuttle: 55 A; Power Shuttle Cab: 140 A; Shuttle: 55 A |
|---|
|
|---|
| Pump Type | Not Published | Not Published |
|---|
| Implement Flow | 11.0 gpm | 11.1 gpm |
|---|
| Steering Flow | 6.1 gpm | 4.6 gpm |
|---|
| Total Hydraulic Flow | 17.1 gpm (11.0 + 6.1, computed) | 15.7 gpm |
|---|
| Overall Hydraulic Pump Flow | 17.1 gpm (11.0 + 6.1, computed) | 15.7 gpm |
|---|
| Hydraulic System Type | Open center | Open center, position and draft control, telescoping stabilizers and flex links |
|---|
| Rear Remote Hydraulic Flow | 11.0 gpm | Not Published |
|---|
| No. of Standard Remote Valves | 1 | Shuttle: single auxiliary valve; Power Shuttle: double auxiliary valves |
|---|
| No. of Optional Remote Valves | 2nd and 3rd optional | Shuttle: 2nd and 3rd valves; Power Shuttle: 3rd valve |
|---|
|
|---|
| Fuel Tank Capacity | ROPS: 18.5 gal; Cab: 29.1 gal | 23.8 gal |
|---|
| Coolant Capacity | 8.5 qt | Not Published |
|---|
| Crankcase Capacity | 11.6 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 59.2 qt | Not Published |
|---|
| Front Axle Fluid Capacity | Front differential case: 5.8 qt; front axle gear case: 3.7 qt | Not Published |
|---|
|
|---|
| PTO Type | Live, independent PTO, hydraulically operated wet clutch with PTO brake | 2 speed independent push button type 1 PTO (wet clutch) |
|---|
| PTO Rear | 540 rpm | 540 @ 1993 rpm and 540E @ 1469 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I and II | CAT I & II |
|---|
| Hitch Lift Capacity | 4,189 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,307 lb | 5,952 lb |
|---|
| Lift Control Type | Position, draft (top link sensing) and mix control | Position and draft control |
|---|
|
|---|
| Transmission Type | Synchro shuttle, 8F/8R (4-speed synchronized main, 2-speed Hi/Lo range); hydraulic shuttle optional on cab models | Full synchro mesh speed and constant mesh range |
|---|
| No. of Speeds | 8F/8R (12F/12R with optional creep) | 15F / 15R |
|---|
| Max Travel Speed (Forward) | 18.5 mph | 21.4 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Dry single plate (synchro shuttle); multiple wet discs (hydraulic shuttle) | Shuttle: Mechanical shuttle with dry clutch; Power Shuttle: Power shuttle with wet clutch and torsional damper |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock (bevel gears) | Not Published |
|---|
|
|---|
| Frame Type | Two-post ROPS (canopy optional); Ultra Grand Cab optional | Not Published |
|---|
| Steering | Hydrostatic power steering | Hydrostatic power steering with tiltable steering column |
|---|
| Brakes | Mechanically operated wet disc brakes | Oil immersed brakes, lever actuated parking brake |
|---|
| Seat Suspension & Adjustability | Reclining, fully adjustable seat (height, weight, fore-aft, armrests) with retractable seat belt; optional air-suspension seat (cab) | mComfort seat with contoured cushions, armrests and adjustable legroom; air-ride suspension seat in cab |
|---|
| Front Axle Type | 4WD: bevel-gear type, on-the-go engagement | Not Published |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | 2,200 lb | Not Published |
|---|
|
|---|
| Overall Width | 73.2 in | 82 in |
|---|
| Wheelbase | 2WD ROPS: 82.1 in; 2WD cab: 84.4 in; 4WD ROPS: 80.7 in; 4WD cab: 83.1 in | 87.4 in |
|---|
| Ground Clearance | 16.3 in | 15.5 in |
|---|
| Min. Turn Radius without Brakes | 2WD: 11.2 ft; 4WD: 11.8 ft | 12.5 ft (3.8 m) |
|---|
| Height to Top of ROPS | 97.2 in | 106 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 100.2 in | 115 in |
|---|
| Overall Length | 2WD: 140.4 in; 4WD: 135.6 in | 152.7 in |
|---|
|
|---|
| Tractor Weight (Base) | 2WD: 4,475 lb; 4WD: 4,608 lb | 6,548 lb (6065 Power Shuttle); 7,495 lb (6065 Power Shuttle Cab); 6,416 lb (6065 Shuttle) |
|---|
| Weight with ROPS and Loader | Not Published | 8,428 lb (6,548 + 1,880, computed; 1,604.8 gal loader shipping weight) |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Standard: 7.5-16 (2WD) or 9.5-24 (4WD) front, 16.9-30 rear | Agricultural, Industrial |
|---|
| R1 Agricultural - Front | 2WD: 7.5-16; 4WD: 9.5-24 | 11.2 x 24 |
|---|
| R1 Agricultural - Rear | 16.9-30 | 16.9 x 30 |
|---|
| R3 Turf - Front | 29x12.5-15 or 27x9.5-15 | Not Published |
|---|
| R3 Turf - Rear | 18.4-26 or 21.5L-16.1 | Not Published |
|---|
| R4 Industrial - Front | 14-17.5L (4WD) | 43 x 16-20 |
|---|
| R4 Industrial - Rear | 16.9-24 (4WD) | 18.4-28 |
|---|
|
|---|
| Quick Attach Loader System | LA1153: two-lever quick coupler | Skid steer tool carrier system for ultra-fast attachments hookup |
|---|
| Loader Model | LA1153 | 6075L |
|---|
| Loader Lift Height | LA1153 height position: 132.7 in; LA1153 power position: 117.2 in | Loader 6075L: 133 in |
|---|
| Loader Lift Capacity (Full Height) | Not Published | Loader 6075L: 3,609 lb (at pivot pin) |
|---|
| Loader Breakout Force | Not Published | Loader 6075L: 5,000 lb |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | 5-year limited powertrain warranty |
|---|
