▶ EngineEngine Manufacturer FPT Industrial FPT Engine Model F5G F5D Engine Type In-line, water-cooled, 4 stroke, CRDI 4-cylinder diesel No. of Cylinders 4 4 Displacement 206.7 in³ 207 in³ Rated Engine Speed 2200 rpm Not Published Engine Power (Gross) 100.6 hp 98 hp PTO Power 85.5 hp 82 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System CRDI (Bosch CP4.11) Common rail fuel injection Alternator 120 A, 14 V Not Published ▶ HydraulicsPump Type Gear pump type, engine drive Not Published Implement Flow 15.7 gpm 16.9 gpm Steering Flow 6.5 gpm 9.7 gpm Total Hydraulic Flow 22.2 gpm 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow 22.2 gpm 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 3 Pairs (Front), 2 Pairs (Rear) 2 (3 with DIA option) No. of Optional Remote Valves 1 Pair (Rear) Not Published ▶ Fluid CapacityFuel Tank Capacity 30.4 gal 30.3 gal Coolant Capacity 3.2 gal Not Published Crankcase Capacity 1.7-2.1 gal (6.5-2.1 gal) Not Published Transmission / Hydraulic System Capacity 14.5 gal Not Published Front Axle Fluid Capacity 1.4 gal Not Published ▶ PTO & HitchPTO Type Independent Not Published PTO Rear 540 / 750 / 1,000 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity 8,378 lb Not Published Hitch Lift Capacity (at 24”) 5,952 lb 5,620 lb (7,351 lb with optional ram) Lift Control Type Position & Draft Not Published ▶ Transmission & DrivetrainTransmission Type Power shuttle with Hi-Lo and Hand clutch 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional) No. of Speeds 24 X 24 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) 23.1 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Wet clutch disks Not Published Differential Lock & Limited Slip Options Electro-Hydraulic Differential lock (EHD) Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Not Published Brakes Wet, Multi-disc Not Published Seat Suspension & Adjustability Air suspension seat Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type Not Published Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional) Front Axle Rating Not Published 4,700 lb (standard-duty 4WD, in-action capacity); 5,100 lb (heavy-duty 4WD, in-action capacity) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 152.2 in 2WD: 161 in; 4WD: 158 in Overall Width 78.7 in 75.7 in Wheelbase 90 in 2WD: 90.2 in; 4WD: 87.9 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 132 in (2WD front axle) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107 in 102.1 in ▶ WeightTractor Weight (Base) 7,985 lb ROPS/2WD: 6,768 lb; ROPS/4WD: 7,451 lb; Cab/2WD: 7,253 lb; Cab/4WD: 7,936 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 9,645 lb Not Published ▶ Tire OptionsTire Size & Options Ag 13.6-24 / 18.4-34; R14 340/70R28 / 460/75R38 Not Published R1 Agricultural - Front 13.6-24 Not Published R1 Agricultural - Rear 18.4-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System LL8100: ISO 24410 “Quick Attachment” (lever-lock with latch pins into the attachment latch groove) Skid-steer or Euro-style quick attach faceplate Loader Model LL8100 655TL, 665TL (factory installed, NSL or MSL); 825TL, 835TL, 640TL (dealer installed, NSL or MSL) Loader Lift Height LL8100: 139.9 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 825TL: 135 in; 835TL: 143 in; 640TL: 137 in Loader Lift Capacity (Full Height) LL8100: 5,139 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 825TL NSL: 2,755 lb; 825TL MSL: 2,888 lb; 835TL NSL: 3,395 lb; 835TL MSL: 3,571 lb; 640TL NSL: 2,226 lb; 640TL MSL: 2,733 lb (at max height) Loader Breakout Force LL8100: 5,313 lb 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 825TL NSL: 2,910 lb; 825TL MSL: 3,196 lb; 835TL NSL: 3,615 lb; 835TL MSL: 3,990 lb; 640TL NSL: 3,747 lb; 640TL MSL: 3,306 lb ▶ WarrantyWarranty Length & Coverage 5-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty Not Published
