Mahindra 1123 HST Cab vs Mahindra Max 25XL

Across 8 measurable specs, the Mahindra Max 25XL leads 6 categories to 2. Machine pages: Mahindra 1123 HST Cab and Mahindra Max 25XL.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Mahindra1123 HST Cab	MahindraMax 25XL

▶Engine
Engine Manufacturer	Mitsubishi	Mitsubishi
Engine Model	MVL3E3	S3L2
Engine Type	Four Stroke, Naturally Aspirated, Indirect Injection, Water-Cooled Diesel	Four-stroke, naturally aspirated, indirect injection, water-cooled diesel
No. of Cylinders	3	3
Displacement	67.2 in³	80.4 in³
Rated Engine Speed	3000 rpm	2500 rpm
Engine Power (Gross)	22.9 hp	24 hp
PTO Power	16.8 hp	20 hp
Engine Emissions Constraints	No DPF	Not Published
Cooling System Type	Water-Cooled	Water Cooled
Air Cleaner	Not Published	Not Published
Fuel System	Indirect Injection	Indirect Injection
Alternator	55 A, 12 V	50 A, 12 V
▶Hydraulics
Pump Type	Not Published	Not Published
Implement Flow	7.6 gpm	4.6 gpm
Steering Flow	3.8 gpm	Not Published
Total Hydraulic Flow	11.2 gpm	7.3 gpm
Overall Hydraulic Pump Flow	11.2 gpm	7.3 gpm
Hydraulic System Type	Open Center, full-live hydraulic with position control	Open Center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Single or dual	Not Published
▶Fluid Capacity
Fuel Tank Capacity	6.6 gal	6.1 gal
Coolant Capacity	Not Published	Not Published
Crankcase Capacity	Not Published	Not Published
Transmission / Hydraulic System Capacity	Not Published	Not Published
Front Axle Fluid Capacity	Not Published	Not Published
▶PTO & Hitch
PTO Type	Independent Wet Clutch	Live
PTO Rear	540 rpm @ 2837 rpm	540 @ 2376 rpm
Mid-PTO Availability	Optional; 2500 rpm @ 2837 rpm	Standard; 2000 @ 2556 rpm
Category, 3-Point Hitch	CAT I with check chains	CAT I
Hitch Lift Capacity	Not Published	1,354 lb
Hitch Lift Capacity (at 24”)	771 lb	Not Published
Lift Control Type	Position Control	Not Published
▶Transmission & Drivetrain
Transmission Type	HST - 2 Range	HST - 2 ranges
No. of Speeds	Infinite	Infinite
Max Travel Speed (Forward)	7.3 mph	Not Published
Max Travel Speed (Reverse)	Not Published	Not Published
Clutch	Not Published	Dry - Single
Differential Lock & Limited Slip Options	Not Published	Not Published
▶Chassis, Steering & Controls
Frame Type	Not Published	Not Published
Steering	Hydrostatic Power Steering	Not Published
Brakes	Single Pedal	Wet disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	46.3 in	50.7 in
Wheelbase	55.1 in	58.2 in
Ground Clearance	6.7 in	7.2 in
Min. Turn Radius without Brakes	7.2 ft (with brake applied)	7.2 ft
Height to Top of ROPS	Not Published	81.5 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	80.5 in	Not Published
Overall Length	100.4 in	106.1 in
▶Weight
Tractor Weight (Base)	1,962 lb (operating weight)	1,715 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	2,368 lb (1,962 operating weight + 406 loader shipping weight, computed)	Not Published
▶Tire Options
Tire Size & Options	Turf, Industrial	Not Published
R1 Agricultural - Front	Not Published	6x12
R1 Agricultural - Rear	Not Published	9.5x16
R3 Turf - Front	18x8.5-10	20x8-10
R3 Turf - Rear	26x12-12	29x12.5-15
R4 Industrial - Front	18x8.5-10	20x8-10
R4 Industrial - Rear	26x12-12	27x12.5-15
▶Loader & Attachments
Quick Attach Loader System	L11: Front loader skid-steer couplers for superfast hookups	Not Published
Loader Model	L11	MXL25L
Loader Lift Height	L11: 68 in	75 in
Loader Lift Capacity (Full Height)	L11: 794 lb (at pivot pin)	900 lb (at pivot pin)
Loader Breakout Force	L11: 1,433 lb	2,000 lb
▶Warranty
Warranty Length & Coverage	7-Year Limited Powertrain Warranty	Not Published
▶ITC Company Accessories
Accessories that fit	None tagged yet	TYM T254 / T2505 Rural King RK24 Mahindra EMAXX 25 Brush Screen Insert $249.99

Find a Mahindra dealer near you→

Mahindra 1123 HST Cab vs Mahindra Max 25XL: Quick Answers

Which has more horsepower, the Mahindra 1123 HST Cab or the Mahindra Max 25XL?

The Mahindra Max 25XL leads on engine hp at 24 hp hp, compared to 22.9 hp hp for the Mahindra 1123 HST Cab.

Which has more PTO horsepower, the Mahindra 1123 HST Cab or the Mahindra Max 25XL?

The Mahindra Max 25XL leads on pto hp at 20 hp hp, compared to 16.8 hp hp for the Mahindra 1123 HST Cab.

Which is heavier, the Mahindra 1123 HST Cab or the Mahindra Max 25XL?

The Mahindra 1123 HST Cab leads on weight at 1,962 lb lb, compared to 1,715 lb lb for the Mahindra Max 25XL.

Which has more loader lift capacity, the Mahindra 1123 HST Cab or the Mahindra Max 25XL?

The Mahindra Max 25XL leads on loader lift at 900 lb lb, compared to 794 lb lb for the Mahindra 1123 HST Cab.

Which has more three-point hitch lift capacity, the Mahindra 1123 HST Cab or the Mahindra Max 25XL?

The Mahindra Max 25XL leads on 3-pt lift (24 in) at 1,354 lb lb, compared to 771 lb lb for the Mahindra 1123 HST Cab.
