| Engine Manufacturer | Mahindra | Mahindra |
|---|
| Engine Model | VNEF4352 | NE457 |
|---|
| Engine Type | Four-stroke, direct injection, turbocharged and intercooled diesel | Not Published |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 161.5 in³ | 194.7 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2100 rpm |
|---|
| Engine Power (Gross) | 55 hp | 59 hp |
|---|
| PTO Power | 44.5 hp | 50 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Water-cooled, forced circulation | Liquid-cooled |
|---|
| Air Cleaner | Dry dual element | Not Published |
|---|
| Fuel System | Direct injection, turbocharged and intercooled (mCRD common rail) | Direct injection |
|---|
| Alternator | 90 A, 12 V | 36 A, 12 V |
|---|
|
|---|
| Pump Type | Gear pumps: main 1.2 in³/rev, power steering 0.5 in³/rev | Not Published |
|---|
| Implement Flow | 9.5 gpm (2655 Shuttle); 9.5 gpm (2655 Shuttle Cab); 9.7 gpm (2655 HST); 9.7 gpm (2655 HST Cab) | 11 gpm |
|---|
| Steering Flow | 5 gpm | Not Published |
|---|
| Total Hydraulic Flow | Not Published | Not Published |
|---|
| Overall Hydraulic Pump Flow | Not Published | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 1 | Not Published |
|---|
| No. of Optional Remote Valves | Not Published | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 16 gal | Not Published |
|---|
| Coolant Capacity | 2.35 gal (2655 HST); 2.35 gal (2655 HST Cab) | Not Published |
|---|
| Crankcase Capacity | 2.25 gal (2655 HST); 2.25 gal (2655 HST Cab) | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 9.25 gal (2655 HST); 9.25 gal (2655 HST Cab) | Not Published |
|---|
| Front Axle Fluid Capacity | 2.64 gal (2655 HST); 2.64 gal (2655 HST Cab) | Not Published |
|---|
|
|---|
| PTO Type | Independent | Live (6000 2WD); Independent (6000 4WD) |
|---|
| PTO Rear | 540 rpm @ 2300 rpm | 540 rpm (6000 2WD); 540/1000 rpm (6000 4WD) |
|---|
| Mid-PTO Availability | N/A (2655 Shuttle); N/A (2655 Shuttle Cab); Optional, 2000 rpm (2655 HST); Optional, 2000 rpm (2655 HST Cab) | Not Published |
|---|
| Category, 3-Point Hitch | CAT I | CAT II/I |
|---|
| Hitch Lift Capacity | 3314 lb | 3968 lb |
|---|
| Hitch Lift Capacity (at 24”) | 2945 lb | Not Published |
|---|
| Lift Control Type | Position control | Position and draft control |
|---|
|
|---|
| Transmission Type | Synchro mesh shuttle with partial synchromesh (2655 Shuttle); Synchro mesh shuttle with partial synchromesh (2655 Shuttle Cab); HST, 3 ranges (2655 HST); HST, 3 ranges (2655 HST Cab) | 8-speed gear (8F/2R) (6000 2WD); 8-speed shuttle (8F/8R) (6000 4WD) |
|---|
| No. of Speeds | 12F/12R (2655 Shuttle); 12F/12R (2655 Shuttle Cab); Infinite, 3 ranges (2655 HST); Infinite, 3 ranges (2655 HST Cab) | 8F/2R (6000 2WD); 8F/8R (6000 4WD) |
|---|
| Max Travel Speed (Forward) | 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) | Not Published |
|---|
| Max Travel Speed (Reverse) | 15.66 mph (2655 HST); 15.66 mph (2655 HST Cab) | Not Published |
|---|
| Clutch | Damper (HST) (2655 HST); Damper (HST) (2655 HST Cab) | Not Published |
|---|
| Differential Lock & Limited Slip Options | Rear differential lock | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic power steering | Power steering |
|---|
| Brakes | Wet disc | Dry disc (6000 2WD); Wet disc (6000 4WD) |
|---|
| Seat Suspension & Adjustability | mComfort seat with adjustable mechanical suspension, foldable armrests and retractable belt | Not Published |
|---|
| Front Axle Type | Center pin, MFWD (4WD) standard | Not Published |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 135 in | 137 in (6000 2WD); 150 in (6000 4WD) |
|---|
| Overall Width | 71.1 in | 77.4 in |
|---|
| Wheelbase | 74.0 in (2655 HST); 74.0 in (2655 HST Cab) | Not Published |
|---|
| Ground Clearance | 13.8 in | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | 102 in | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 102 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 4056 lb (2655 Shuttle); 4299 lb (2655 Shuttle Cab); 4056 lb (2655 HST); 4299 lb (2655 HST Cab) | 4966 lb (6000 2WD); 6250 lb (6000 4WD) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Ag, Industrial, Turf | Ag, Turf, Industrial |
|---|
| R1 Agricultural - Front | 9.5x16 | 9.5Lx15 (6000 2WD); 11.2x24 (6000 4WD) |
|---|
| R1 Agricultural - Rear | 14.9x24 | 16.9x28 |
|---|
| R3 Turf - Front | LSW305-521 | 27x12LL-15 (6000 2WD); LSW305x521 (6000 4WD) |
|---|
| R3 Turf - Rear | LSW570-648 | LSW570x648 |
|---|
| R4 Industrial - Front | 12x16.5 | 11Lx15 (6000 2WD); 12.5/80x18 (6000 4WD) |
|---|
| R4 Industrial - Rear | 16.9x24 | 19.5Lx24 |
|---|
|
|---|
| Quick Attach Loader System | Not Published | Not Published |
|---|
| Loader Model | 2655L (2655 Shuttle, 2655 HST); 2655CL (2655 Shuttle Cab, 2655 HST Cab) | ML260 (6000 2WD); ML264, ML265 (6000 4WD) |
|---|
| Loader Lift Height | 2655L: 115.4 in; 2655CL: 115.4 in | ML260: 107.5 in; ML264: 129.25 in; ML265: 129 in |
|---|
| Loader Lift Capacity (Full Height) | 2655L: 3,122 lb; 2655CL: 3,122 lb | ML260: 2,500 lb; ML264: 2,800 lb; ML265: 3,150 lb |
|---|
| Loader Breakout Force | 2655L: 5,225 lb; 2655CL: 5,225 lb | ML260: 5,000 lb; ML264: 4,900 lb; ML265: 5,050 lb |
|---|
|
|---|
| Warranty Length & Coverage | 7-year/3000-hour limited powertrain warranty, no deductible | Not Published |
|---|
