| Engine Manufacturer | Mahindra | FPT Industrial |
|---|
| Engine Model | Not Published | F5G |
|---|
| Engine Type | Four-stroke, turbocharged, direct injection, water cooled diesel | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 215.4 in³ | 207 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 91.5 hp | 86 hp |
|---|
| PTO Power | 75 hp | 73 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Water-cooled | Liquid-cooled |
|---|
| Air Cleaner | Not Published | Not Published |
|---|
| Fuel System | Common rail direct injection | Electronic high-pressure common rail fuel injection |
|---|
| Alternator | 140 A | ROPS: 120 A; Cab: 150 A |
|---|
|
|---|
| Pump Type | Not Published | Open-center; dual pumps (implement pump plus dedicated steering pump) |
|---|
| Implement Flow | 17 gpm | 16.9 gpm |
|---|
| Steering Flow | 5.2 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 22.2 gpm | 26.6 gpm |
|---|
| Overall Hydraulic Pump Flow | 22.2 gpm | 26.6 gpm |
|---|
| Hydraulic System Type | Open center with position and draft control | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | 2 rear remotes (open center with detent) |
|---|
| No. of Optional Remote Valves | 1 | 1 (third rear remote, DIA kit) |
|---|
|
|---|
| Fuel Tank Capacity | 25.9 gal | 30.3 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | 2-speed independent single lever PTO | Fully independent hydraulic PTO |
|---|
| PTO Rear | 540/1000 rpm | 540 rpm (standard); 540/1000 rpm with interchangeable shafts (optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | CAT II with telescoping stabilizers & flex links | Category II |
|---|
| Hitch Lift Capacity | 5500 lb (measuring point not stated by Mahindra) | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | Not Published | 5,620 lb |
|---|
| Lift Control Type | Position and draft control | Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) |
|---|
|
|---|
| Transmission Type | Full synchro mesh with forward/reverse power shuttle & constant mesh range | 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) |
|---|
| No. of Speeds | 12F / 12R | 12F/12R (standard); 20F/20R with creeper (optional) |
|---|
| Max Travel Speed (Forward) | Not Published | 27 mph (4WD front axle); 20 mph (2WD front axle) |
|---|
| Max Travel Speed (Reverse) | Not Published | 27.25 mph (12x12, 4WD front axle, 18R34 tires) |
|---|
| Clutch | Power shuttle with torsional damper (wet) | Not Published |
|---|
| Differential Lock & Limited Slip Options | Not Published | Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement |
|---|
|
|---|
| Frame Type | Steel frame | Not Published |
|---|
| Steering | Power steering | Power steering |
|---|
| Brakes | Oil immersed brakes, 7-in disc diameter, mechanically actuated | Hydraulic wet disc |
|---|
| Seat Suspension & Adjustability | mComfort seat with integrated foldable armrests, recline feature and standard air suspension | Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests |
|---|
| Front Axle Type | Not Published | Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) |
|---|
| Front Axle Rating | Not Published | 9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle) |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 176.6 in | 163.1 in (2WD); 160.9 in (4WD) |
|---|
| Overall Width | 83 in | 75.7 in |
|---|
| Wheelbase | 95.6 in | 92.2 in (2WD); 89.9 in (4WD) |
|---|
| Ground Clearance | 14.1 in | Not Published |
|---|
| Min. Turn Radius without Brakes | 15.5 ft | 134 in (optional 2WD front axle, w/o brakes) |
|---|
| Height to Top of ROPS | Not Published | 106.5 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 111.2 in | 102.1 in |
|---|
|
|---|
| Tractor Weight (Base) | 8587 lb | 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions |
|---|
| R1 Agricultural - Front | 12.4 x 24 | 2WD: 10.00-16; 4WD: 12.4-24 |
|---|
| R1 Agricultural - Rear | 18.4 x 30 | 18.4R34 (reference tire for OEM weights and dimensions) |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Skid steer style quick attach | Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) |
|---|
| Loader Model | 8100CL | 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) |
|---|
| Loader Lift Height | 8100CL: 139 in | 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in |
|---|
| Loader Lift Capacity (Full Height) | 8100CL: 4,200 lb | 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb |
|---|
| Loader Breakout Force | 8100CL: 6,050 lb | 710LU: 3,739 lb; 715LU: 3,860 lb; 720LU: 4,455 lb; 725LU: 5,661 lb (31.5 in forward of the bucket pivot point) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
