| Engine Manufacturer | Mahindra | FPT |
|---|
| Engine Model | NE 479 TCI | F36 |
|---|
| Engine Type | Turbocharged and intercooled, direct injection, liquid-cooled diesel | 4-cylinder diesel, turbocharged and aftercooled |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 203.2 in³ | 219.7 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 81.9 hp | 88.5 hp |
|---|
| PTO Power | 69 hp | Not Published |
|---|
| Engine Emissions Constraints | Tier 3 | Stage V (ECOBlue Compact HI-eSCR + Light CEGR) |
|---|
| Cooling System Type | Not Published | Not Published |
|---|
| Air Cleaner | Dry type with safety cartridge & dust unloader valve | Not Published |
|---|
| Fuel System | Rotary FIP with KSB Unit MICO (BOSCH) | Common rail fuel injection |
|---|
| Alternator | 55 A, 12 V | Not Published |
|---|
|
|---|
| Pump Type | Independent fully 'live' hydraulic pump | Open center, dual pumps: implement pump plus dedicated steering pump |
|---|
| Implement Flow | 17 gpm | 21.7 gpm |
|---|
| Steering Flow | 5.3 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 22.3 gpm | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Overall Hydraulic Pump Flow | Not Published | 31.4 gpm (21.7 + 9.7, computed) |
|---|
| Hydraulic System Type | Independent, fully live hydraulic pump with draft and position control | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | 2 rear remotes (four couplers) |
|---|
| No. of Optional Remote Valves | Not Published | 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) |
|---|
|
|---|
| Fuel Tank Capacity | 19.28 gal | 34.3 gal |
|---|
| Coolant Capacity | 2.58 gal | Not Published |
|---|
| Crankcase Capacity | 9.48 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 8.59 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 1.79 gal | Not Published |
|---|
|
|---|
| PTO Type | Rear independent PTO shaft | Fully independent electrohydraulic PTO, wet clutch |
|---|
| PTO Rear | Not Published | 540/1000 rpm (interchangeable, standard) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II ball joints with adjustable outside lateral stabilizer | Category II |
|---|
| Hitch Lift Capacity | 5,500 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 3,850 lb | 4,123 lb |
|---|
| Lift Control Type | Position and draft control | Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) |
|---|
|
|---|
| Transmission Type | Not Published | 24x24 Dual Command hi-lo power shuttle, column-mounted |
|---|
| No. of Speeds | 12F / 12R | 24F/24R (Dual Command) |
|---|
| Max Travel Speed (Forward) | Not Published | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Dry Dual Clutch (normally disengaged PTO clutch) | Not Published |
|---|
| Differential Lock & Limited Slip Options | Not Published | Electrohydraulic rear differential lock |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Hydrostatic (Power Steering) | Not Published |
|---|
| Brakes | Oil-immersed, independent foot pedals that lock together; hand brake for parking | Not Published |
|---|
| Seat Suspension & Adjustability | Not Published | Air-suspension cloth seat |
|---|
| Front Axle Type | Not Published | Heavy-duty class 1.5 4WD front axle |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Width | 77.3 in | 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) |
|---|
| Wheelbase | 2WD: 85.31 in; 4WD: 85.8 in | 92.5 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | 2WD: 157 in; 4WD: 180 in | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | 103.6 in |
|---|
| Overall Length | 162.04 in | 158.2 in |
|---|
|
|---|
| Tractor Weight (Base) | 2WD: 6,878 lb (operating weight); 4WD: 7,297 lb (operating weight) | 10,240 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Not Published | 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available |
|---|
| R1 Agricultural - Front | Not Published | Not Published |
|---|
| R1 Agricultural - Rear | Not Published | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Not Published | Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) |
|---|
| Loader Model | Not Published | 650LU (NSL); 655LU (MSL) |
|---|
| Loader Lift Height | Not Published | 650LU: 149.7 in; 655LU: 149.7 in |
|---|
| Loader Lift Capacity (Full Height) | Not Published | 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) |
|---|
| Loader Breakout Force | Not Published | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
