▶ EngineEngine Manufacturer Mahindra FPT Industrial Engine Model Not Published NEF Engine Type 4-cylinder, liquid-cooled inline diesel 4-cylinder diesel No. of Cylinders 4 4 Displacement 215.6 in³ 273.7 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 125 hp 130 hp PTO Power 106 hp 111 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail direct injection Not Published Alternator Not Published Standard: 120 A, 12 V; Optional: 200 A, 12 V ▶ HydraulicsPump Type Not Published Closed-center load-sensing (CCLS) main pump plus separate steering and services pump Implement Flow 21.2 gpm 21.1 gpm Steering Flow 9.25 gpm 9.6 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center with position & draft control, telescoping stabilizers & flex links Closed center load sensing (CCLS) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (9125 S); 3 (9125 P) Not Published No. of Optional Remote Valves 1 Up to 4 rear remote valves (deluxe, with diverter); up to 3 mid-mount valves ▶ Fluid CapacityFuel Tank Capacity Not Published 47.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Fully independent direct-drive PTO with electro-hydraulic wet clutch and Soft Start PTO Rear 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) 540/1000 rpm (540 at 1969, 540E at 1546, 1000 at 1893 engine rpm) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II with telescopic link ends Category II Hitch Lift Capacity Not Published 12,125 lb (at ball ends) Hitch Lift Capacity (at 24”) 5,787 lb (9125 S); 7,628 lb (9125 P) 10,228 lb Lift Control Type Electronic draft control with fender switches Electronic draft control (EDC) ▶ Transmission & DrivetrainTransmission Type Power shuttle with synchromesh Dynamic Command: 24x24 dual-clutch 8-step semi-powershift; Auto Command: continuously variable transmission (CVT) No. of Speeds 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Dynamic Command: 24F/24R; Auto Command: infinitely variable Max Travel Speed (Forward) Not Published Dynamic Command: 25 mph; Auto Command: 25 mph (31 mph optional) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Terralock Auto Diff and Auto 4WD (standard); electro-hydraulic front and rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability mComfort seat with adjustable air ride suspension, foldable adjustable armrest, recline and adjustable headrest Comfort seat, low-frequency suspension, cloth (standard); Dynamic Comfort or Auto Comfort seats with heating and active ventilation (optional); instructor seat optional Front Axle Type Not Published Class 1.75 heavy-duty 4WD front axle (standard); Terraglide front axle suspension (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 169.3 in 173 in (max, weight carrier to rear linkage) Overall Width 90.9 in 74 in (narrow); 90 in (standard) Wheelbase Not Published 98 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 182 in (4WD / Terraglide suspended front axle; brake use not stated) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 107 in 106 in (low-profile roof, 540/65R34 tires) ▶ WeightTractor Weight (Base) 9,385 lb 12,125 lb (minimum shipping weight, cab) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer style quick attach couplers Not Published Loader Model 9125L 800TL Series (wide frame) Loader Lift Height 9125L: 162 in Not Published Loader Lift Capacity (Full Height) 9125L: 5,415 lb Not Published Loader Breakout Force 9125L: 6,874 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
