| Engine Manufacturer | AGCO Power | AGCO Power |
|---|
| Engine Model | Not Published | Not Published |
|---|
| Engine Type | 3-cylinder, intercooled turbocharged diesel | 4-cylinder, intercooled turbocharged, liquid-cooled diesel |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 201 in³ | 268.5 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2200 rpm |
|---|
| Engine Power (Gross) | 100 hp | 100 hp |
|---|
| PTO Power | 87 hp | Power Shuttle: 83 hp; Dyna-4: 76 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid cooled | Liquid cooled |
|---|
| Air Cleaner | Dual element (primary and secondary) | Not Published |
|---|
| Fuel System | High-pressure common rail direct fuel injection | High-pressure common-rail direct injection (HPCR) |
|---|
| Alternator | 80 A | 120 A, 12 V |
|---|
|
|---|
| Pump Type | Two-stage pump | Two high-pressure gear pumps |
|---|
| Implement Flow | Not Published | 15.1 gpm |
|---|
| Steering Flow | Not Published | Not Published |
|---|
| Total Hydraulic Flow | Not Published | 25.9 gpm |
|---|
| Overall Hydraulic Pump Flow | Not Published | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 17.2 gpm | 26 gpm |
|---|
| No. of Standard Remote Valves | 2 | 2 |
|---|
| No. of Optional Remote Valves | 1 | 1 |
|---|
|
|---|
| Fuel Tank Capacity | 33 gal | 38.3 gal |
|---|
| Coolant Capacity | 4.2 gal | Not Published |
|---|
| Crankcase Capacity | 3.3 gal | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal | Not Published |
|---|
| Front Axle Fluid Capacity | Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive | Not Published |
|---|
|
|---|
| PTO Type | Independent, electrohydraulic engagement | Independent, electro-hydraulic engagement via switch |
|---|
| PTO Rear | 540/540E standard; 540/1000 optional | 540 / 540E / 1000 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 4,850 lb | 7,710 lb |
|---|
| Lift Control Type | Not Published | Electronic linkage control (ELC) |
|---|
|
|---|
| Transmission Type | 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift | Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift |
|---|
| No. of Speeds | 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 | Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse |
|---|
| Max Travel Speed (Forward) | 25 mph | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever | Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever |
|---|
| Differential Lock & Limited Slip Options | Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock | Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Cab: tilt and telescopic steering column; Platform: tilt steering column | Power steering; cab: tilt and telescopic column, platform: tilt column |
|---|
| Brakes | Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals | Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals |
|---|
| Seat Suspension & Adjustability | Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests | Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests |
|---|
| Front Axle Type | Heavy-duty 2WD or 4WD front axle | Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | Not Published | Not Published |
|---|
| Overall Width | 60.3 in (minimum, with std. 420/85R30 rear tires) | 64.8 in |
|---|
| Wheelbase | 88.5 in | 95.7 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb | 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 2WD: 9.5L-15 front, 420/85R34 rear; 4WD: 340/85R24 front, 420/85R34 rear | Rear: 460/85R34 standard radial |
|---|
| R1 Agricultural - Front | 2WD: 9.5L-15; 4WD: 340/85R24 | Not Published |
|---|
| R1 Agricultural - Rear | 420/85R34 | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | 931X and 936X: universal skid steer type quick release | Not Published |
|---|
| Loader Model | FL.3522, FL.3615, 931X, 936X | 941X; 946X; FL.3723; FL.3819 |
|---|
| Loader Lift Height | FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) | 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in |
|---|
| Loader Lift Capacity (Full Height) | FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) | 941X: 3,650 lb; FL.3723: 4,519.5 lb |
|---|
| Loader Breakout Force | Not Published | FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
