| Engine Manufacturer | AGCO Power | AGCO Power |
|---|
| Engine Model | 33 AWI HD | 44 AWFC |
|---|
| Engine Type | 3-cylinder turbocharged and intercooled diesel | 4-cylinder, intercooled turbocharged, liquid-cooled diesel |
|---|
| No. of Cylinders | 3 | 4 |
|---|
| Displacement | 201 in³ | 268.5 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2200 rpm |
|---|
| Engine Power (Gross) | 100 hp | 100 hp |
|---|
| PTO Power | 75 hp | Power Shuttle: 83 hp; Dyna-4: 76 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled (water-cooled) | Liquid cooled |
|---|
| Air Cleaner | 2-stage dry | Not Published |
|---|
| Fuel System | Common rail direct injection | High-pressure common-rail direct injection (HPCR) |
|---|
| Alternator | 95 A | 120 A, 12 V |
|---|
|
|---|
| Pump Type | Single gear-type pump (tandem gear-type pumps with optional Twin Flow) | Two high-pressure gear pumps |
|---|
| Implement Flow | 15 gpm standard; 26 gpm with optional Twin Flow | 15.1 gpm |
|---|
| Steering Flow | Not Published | Not Published |
|---|
| Total Hydraulic Flow | 26 gpm (Twin Flow: 15 gpm to 3-point hitch plus 11 gpm to remotes, combinable) | 25.9 gpm |
|---|
| Overall Hydraulic Pump Flow | Not Published | Not Published |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 15 gpm standard; 26 gpm with optional Twin Flow | 26 gpm |
|---|
| No. of Standard Remote Valves | 2 | 2 |
|---|
| No. of Optional Remote Valves | Up to 4 | 1 |
|---|
|
|---|
| Fuel Tank Capacity | 42 gal | 38.3 gal |
|---|
| Coolant Capacity | 15.3 qt | Not Published |
|---|
| Crankcase Capacity | 13.7 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 17.2 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 5.3 qt axle beam; 0.85 qt each final drive | Not Published |
|---|
|
|---|
| PTO Type | Independent, electro-hydraulic engagement and speed selection | Independent, electro-hydraulic engagement via switch |
|---|
| PTO Rear | 540/540E standard; 540/540E/1000 optional | 540 / 540E / 1000 rpm |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Category II |
|---|
| Hitch Lift Capacity | 9,480 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 7,100 lb | 7,710 lb |
|---|
| Lift Control Type | Electronic linkage control (ELC), position and draft control, lower link draft sensing | Electronic linkage control (ELC) |
|---|
|
|---|
| Transmission Type | Dyna-4 16x16 power shift and power shuttle (AUTO-DRIVE optional, 14:1 creeper optional) | Power Shuttle: 12F x 12R, 2-range with electrohydraulic shuttle lever; Dyna-4: 16F x 16R powershift |
|---|
| No. of Speeds | 16F / 16R | Power Shuttle: 12 forward, 12 reverse; Dyna-4: 16 forward, 16 reverse |
|---|
| Max Travel Speed (Forward) | 25 mph | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Wet multi-disc, foot pedal and electronic control | Single-plate wet clutch with easy shift knob and electrohydraulic power shuttle lever |
|---|
| Differential Lock & Limited Slip Options | Fully locking front and rear differentials, electro-hydraulically engaged | Rear differential lock engaged via electrohydraulic rocker switch; Hydra-Lock hydraulic front axle differential lock on 4WD |
|---|
|
|---|
| Frame Type | Rigid structural chassis, solid cast steel flanged rear axle with internal planetary reduction | Not Published |
|---|
| Steering | Hydrostatic power steering, adjustable steering wheel | Power steering; cab: tilt and telescopic column, platform: tilt column |
|---|
| Brakes | Internal wet disc, hydraulic power assist, individual left and right foot pedals | Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals |
|---|
| Seat Suspension & Adjustability | Mechanical suspended swivel seat standard; manual or automatic air suspension optional | Cab: air-ride swivel seat; platform: mechanical spring suspension seat with armrests |
|---|
| Front Axle Type | Adjustable 2WD or fixed cast steel 4WD, single piece with outboard planetary final drives | Heavy-duty 4WD front axle: cast steel, fixed, center drive line, planetary final drives |
|---|
| Front Axle Rating | 2WD: 6,085 lb; 4WD: 10,500 lb | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 167.5 in | Not Published |
|---|
| Overall Width | 79.3 in | 64.8 in |
|---|
| Wheelbase | 97.1 in | 95.7 in |
|---|
| Ground Clearance | 17.6 in | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 108.5 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 2WD: 8,426 lb; 4WD: 8,978 lb | 4WD ROPS: 9,195 lb; 4WD Cab: 10,011 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 radial agricultural tires only; 16.9R38 rear is the speed chart basis (16.9R34, 16.9R30, 18.4R30, 18.4R34, 13.6R38 listed) | Rear: 460/85R34 standard radial |
|---|
| R1 Agricultural - Front | Not Published | Not Published |
|---|
| R1 Agricultural - Rear | 16.9R38 | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | MF931, MF941, MF946: Euro quick attach, single lever locking | Not Published |
|---|
| Loader Model | MF931, MF941, MF946 | 941X; 946X; FL.3723; FL.3819 |
|---|
| Loader Lift Height | MF931: 138 in; MF941: 148 in; MF946: 148 in | 941X: 148 in; 946X: 148 in; FL.3723: 149 in; FL.3819: 149 in |
|---|
| Loader Lift Capacity (Full Height) | MF931: 3,880 lb; MF941: 4,735 lb; MF946: 3,965 lb | 941X: 3,650 lb; FL.3723: 4,519.5 lb |
|---|
| Loader Breakout Force | Not Published | FL.3723: 5,818.6 lb; FL.3819: 4,892.9 lb |
|---|
|
|---|
| Warranty Length & Coverage | 2-year/2,000-hour full coverage, all parts and labor | Not Published |
|---|
