Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard)
Not Published
Transmission Type
12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional)
12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional)
No. of Speeds
12F/12R (standard); 20F/20R with creeper (optional)
12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional)
Max Travel Speed (Forward)
27 mph (4WD front axle); 20 mph (2WD front axle)
Not Published
Max Travel Speed (Reverse)
27.25 mph (12x12, 4WD front axle, 18R34 tires)
Not Published
Clutch
Not Published
Not Published
Differential Lock & Limited Slip Options
Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement
Mechanical rear differential lock (pedal)
Frame Type
Not Published
Not Published
Steering
Power steering
Not Published
Brakes
Hydraulic wet disc
Not Published
Seat Suspension & Adjustability
Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests
Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests
Front Axle Type
Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional)
Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional)
Front Axle Rating
9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle)
