▶ EngineEngine Manufacturer FPT FPT Engine Model F36 F5D Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder diesel No. of Cylinders 4 4 Displacement 219.7 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 99.2 hp 106 hp PTO Power Not Published 91 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Tier 4A with Cooled Exhaust Gas Recirculation (CEGR) and a Diesel Particulate Filter (DPF) Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Not Published Alternator Not Published 120 A ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Gear pumps Implement Flow 21.7 gpm T5.105: 16.1 gpm (21.1 gpm optional); T5.105 Electro Command: 21.1 gpm (16.1 gpm optional) Steering Flow 9.7 gpm T5.105: 10.0 gpm (11.4 gpm optional); T5.105 Electro Command: 11.4 gpm (10.0 gpm optional) Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) T5.105: 26.1 gpm (16.1 + 10.0); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4) Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) T5.105: 26.1 gpm (16.1 + 10.0); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 (3 optional) No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) Not Published ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent, electro-hydraulic clutch PTO Rear 540/1000 rpm (interchangeable, standard) 540/1000 Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb T5.105: 6,393 lb (10,452 lb with 2 optional rams); T5.105 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) Lift Control Type 12x12 models: mechanical draft control; Dual Command models: electronic draft control; single-lever Lift-O-Matic PLUS (standard) Electronic draft control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (column-mounted) T5.105: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.105 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) No. of Speeds 12F/12R; 20F/20R with creeper; 24F/24R Dual Command T5.105: 12F/12R (20F/20R or 24F/24R optional); T5.105 Electro Command: 16F/16R (32F/32R optional) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Electro-hydraulic rear differential lock; limited slip front ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc Seat Suspension & Adjustability Air-suspension cloth seat Seat options include a low-frequency heated air-suspension seat; full-size instructor seat available Front Axle Type Heavy-duty class 1.5 4WD front axle Heavy-duty 4WD front axle (standard) Front Axle Rating Not Published 4,500 lb (in-action capacity at 4 mph) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 82.6 in Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in T5.105: 105.4 in; T5.105 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) Overall Length 158.2 in T5.105: 163.8 in; T5.105 Electro Command: 165.0 in ▶ WeightTractor Weight (Base) 10,240 lb T5.105: 9,370 lb; T5.105 Electro Command: 9,700 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) Skid-steer-style or European-style Loader Model 650LU (NSL); 655LU (MSL) 825TL; 835TL (each NSL or MSL) Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) 825TL: 138 in; 835TL: 146 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb Loader Breakout Force Not Published 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
