| Engine Manufacturer | Fiat Powertrain Technologies (FPT) | FPT |
|---|
| Engine Model | F36 | F36 |
|---|
| Engine Type | 4-cylinder diesel, turbocharged and aftercooled | 4-cylinder |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 220 in³ | Not Published |
|---|
| Rated Engine Speed | 2300 rpm | Not Published |
|---|
| Engine Power (Gross) | 108.6 hp | 101 hp |
|---|
| PTO Power | Not Published | 85 hp |
|---|
| Engine Emissions Constraints | Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR | Not Published |
|---|
| Cooling System Type | Not Published | Not Published |
|---|
| Air Cleaner | Not Published | Not Published |
|---|
| Fuel System | Common rail fuel injection | Not Published |
|---|
| Alternator | Not Published | Not Published |
|---|
|
|---|
| Pump Type | Open center, dual pumps: implement pump plus dedicated steering pump | Not Published |
|---|
| Implement Flow | 21.7 gpm | Not Published |
|---|
| Steering Flow | 9.7 gpm | Not Published |
|---|
| Total Hydraulic Flow | 31.4 gpm (21.7 + 9.7, computed) | 26.6 gpm |
|---|
| Overall Hydraulic Pump Flow | 31.4 gpm (21.7 + 9.7, computed) | Not Published |
|---|
| Hydraulic System Type | Open center | Not Published |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 rear remotes (four couplers) | Not Published |
|---|
| No. of Optional Remote Valves | 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 34.3 gal | 34.3 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Fully-independent, electrohydraulic, wet-clutch | Not Published |
|---|
| PTO Rear | 540/1000 rpm (interchangeable) | Not Published |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II | Not Published |
|---|
| Hitch Lift Capacity | Not Published | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) | Not Published |
|---|
| Lift Control Type | 12x12: mechanical draft control; Dual Command: electronic draft control | Not Published |
|---|
|
|---|
| Transmission Type | 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle | 12x12 electronic power shuttle |
|---|
| No. of Speeds | 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) | 12 forward / 12 reverse |
|---|
| Max Travel Speed (Forward) | 25 mph | Not Published |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Not Published | Not Published |
|---|
| Differential Lock & Limited Slip Options | Electrohydraulic differential lock | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Not Published | Not Published |
|---|
| Brakes | Not Published | Not Published |
|---|
| Seat Suspension & Adjustability | Air-suspension cloth seat | Air ride seat (standard); instructor seat available |
|---|
| Front Axle Type | 4WD heavy-duty, class 1.5 front axle (standard) | Class 1.0 HD heavy-duty front axle |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Width | 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) | Not Published |
|---|
| Wheelbase | 92.5 in | Not Published |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | Not Published |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | 103.6 in | Not Published |
|---|
| Overall Length | 158.2 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 10,240 lb | Not Published |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available | Not Published |
|---|
| R1 Agricultural - Front | Not Published | Not Published |
|---|
| R1 Agricultural - Rear | Not Published | Not Published |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | Not Published |
|---|
| R4 Industrial - Rear | Not Published | Not Published |
|---|
|
|---|
| Quick Attach Loader System | Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) | Not Published |
|---|
| Loader Model | 650LU (NSL); 655LU (MSL) | 630LU; 635LU |
|---|
| Loader Lift Height | 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) | 143.9 in (630LU and 635LU) |
|---|
| Loader Lift Capacity (Full Height) | 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) | 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, @ 31.5 in) |
|---|
| Loader Breakout Force | Not Published | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
