New Holland T3.60F vs New Holland Workmaster 60
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 5 measurable specs, the New Holland Workmaster 60 leads 3 categories to 2. Machine pages: New Holland T3.60F and New Holland Workmaster 60.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | New Holland T3.60F | New Holland Workmaster 60 |
|---|---|---|
| Engine HP (hp) | 54 hp | ▲ 60 hp |
| PTO HP (hp) | 40 hp | ▲ 51 hp |
| Weight (lb) | 5,000 lb | ▲ 5,059 lb |
| Loader Lift (lb) | n/a | 3,549 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 4,000 lb | 2,701 lb |
| Lift Height (in) | n/a | 122 in |
| Breakout Force (lbf) | n/a | 3,527 lbf |
| Hydraulic Flow (gpm) | ▲ 20.2 gpm | 17.5 gpm |
| Travel Speed (mph) | n/a | 19.1 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | New HollandT3.60F | New HollandWorkmaster 60 |
|---|
| Engine Manufacturer | Not Published | FPT |
|---|---|---|
| Engine Model | S8000 | R753 |
| Engine Type | Turbocharged, intercooled 3-cylinder diesel | Turbocharged, intercooled 3-cylinder diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 179 in³ | 136 in³ |
| Rated Engine Speed | 2300 rpm | 2600 rpm |
| Engine Power (Gross) | 54 hp | 60 hp |
| PTO Power | 40 hp | 51 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Not Published | Pressurized liquid with recirculating bypass |
| Air Cleaner | Not Published | 2-stage |
| Fuel System | Common rail fuel injection | Common rail direct injection (CRDI) |
| Alternator | Not Published | 75 A |
New Holland T3.60F vs New Holland Workmaster 60: Quick Answers
- Which has more horsepower, the New Holland T3.60F or the New Holland Workmaster 60?
- The New Holland Workmaster 60 leads on engine hp at 60 hp hp, compared to 54 hp hp for the New Holland T3.60F.
- Which has more PTO horsepower, the New Holland T3.60F or the New Holland Workmaster 60?
- The New Holland Workmaster 60 leads on pto hp at 51 hp hp, compared to 40 hp hp for the New Holland T3.60F.
- Which is heavier, the New Holland T3.60F or the New Holland Workmaster 60?
- The New Holland Workmaster 60 leads on weight at 5,059 lb lb, compared to 5,000 lb lb for the New Holland T3.60F.
- Which has more three-point hitch lift capacity, the New Holland T3.60F or the New Holland Workmaster 60?
- The New Holland T3.60F leads on 3-pt lift (24 in) at 4,000 lb lb, compared to 2,701 lb lb for the New Holland Workmaster 60.
