▶ EngineEngine Manufacturer Not Published FPT Engine Model S8000 F5C Engine Type Turbocharged, intercooled 3-cylinder diesel 4-cylinder diesel, turbocharged No. of Cylinders 3 4 Displacement 179 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 60 hp 65 hp Engine Emissions Constraints Tier 4 US EPA Tier 4B Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry Fuel System Common rail fuel injection Common rail fuel injection Alternator Not Published 120 A ▶ HydraulicsPump Type Dual-pump Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 12.6 gpm 12.5 gpm Steering Flow 7.6 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 20.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 20.2 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 3 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity Not Published 23.8 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Fully independent PTO Rear 540/540E 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II / I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,000 lb 3,664 lb Lift Control Type Lift-O-Matic Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 Mechanical Shuttle 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 12F/12R 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) Not Published 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch Not Published Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Straddle-deck platform Not Published Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc Seat Suspension & Adjustability Vinyl suspension seat Optional deluxe air suspension seat with fully integrated armrest and 10° swivel to the right; full-size instructor seat with seatbelt Front Axle Type 4WD front axle, electronic engagement Heavy-duty 2WD front axle; electronic 4WD front axle (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 57 in Not Published Wheelbase 73 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD front axle) Height to Top of ROPS 97 in Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model Not Published 94.8 to 97.8 in Overall Length 143 in 151 in ▶ WeightTractor Weight (Base) 5,000 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear 320/70R20 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid-steer-style or Euro-style quick attach faceplate Loader Model Not Published Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height Not Published 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) Not Published 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (to max height, at 31.5 in from pivot point) Loader Breakout Force Not Published 655TL NSL: 3,739 lb; 655TL MSL: 4,665 lb; 622TL: 3,042 lb; 627TL: 3,307 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
