5,620 lb (7,351 lb with optional auxiliary lift ram)
T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2)
Lift Control Type
Mechanical draft and position control (12x12 models); Electronic Draft Control (EDC) with fender switches (Dual Command cab models); Lift-O-Matic Plus single-lever control (optional on 12x12, standard on Dual Command ROPS)
Electronic draft control
Transmission Type
12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional)
T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional)
No. of Speeds
12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional)
Electro-hydraulic rear differential lock; limited slip front
Frame Type
Not Published
Not Published
Steering
Power steering
Hydrostatic power steering
Brakes
Wet disc
Hydraulic wet disc
Seat Suspension & Adjustability
Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests
Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available
Front Axle Type
Heavy-duty electronically engaged 4WD front axle (standard); standard-duty electronically or mechanically engaged 4WD, or heavy-duty 2WD front axle (optional)
Heavy-duty 4WD front axle (standard)
Front Axle Rating
9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph)
4,500 lb (in-action capacity at 4 mph)
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
163.1 in (2WD); 160.9 in (4WD)
T5.115: 163.8 in; T5.115 Electro Command: 165.0 in
Overall Width
75.7 in
82.6 in
Wheelbase
92.2 in (2WD); 89.9 in (4WD)
92.5 in
Ground Clearance
Not Published
Not Published
Min. Turn Radius without Brakes
134 in (2WD heavy-duty front axle)
Not Published
Height to Top of ROPS
106.5 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
102.1 in
T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab)
Ag: 16.9-30 rear with 11.2-24 front; 16.9-34 rear with 13.6-24 front; 18.4-30 rear with 12.4-24 front; 18.4-34 rear with 14.9-24 front. Turf: 16.9-24 rear with 13.6-16.1 front. Industrial: 19.5L24 rear with 12.5/80-18 front
Not Published
R1 Agricultural - Front
4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears)
Not Published
R1 Agricultural - Rear
16.9-30, 16.9-34, 18.4-30 or 18.4-34
Not Published
R3 Turf - Front
13.6-16.1
Not Published
R3 Turf - Rear
16.9-24
Not Published
R4 Industrial - Front
12.5/80-18
Not Published
R4 Industrial - Rear
19.5L24
Not Published
Quick Attach Loader System
Skid-steer-style or Euro-style quick attach faceplate
Skid-steer-style or European-style
Loader Model
Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL)
