▶ EngineEngine Manufacturer FPT Industrial Deutz Engine Model F5C TCD2.9 L4 Engine Type 4-cylinder diesel, turbocharged Turbocharged No. of Cylinders 4 4 Displacement 207 in³ 177.0 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 65 hp 64.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry Not Published Fuel System Common rail fuel injection Common Rail Direct Injection Alternator 120 A 95 A, 12 V ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering and services pump Not Published Implement Flow 12.5 gpm 10.3 gpm Steering Flow 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) 5.8 gpm Total Hydraulic Flow 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) 16.1 gpm Overall Hydraulic Pump Flow 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 No. of Optional Remote Valves Up to 3 rear remotes 3 ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity Not Published 10.6 qt Crankcase Capacity Not Published 8.5 qt Transmission / Hydraulic System Capacity Not Published 18.0 gal Front Axle Fluid Capacity Not Published 17.4 qt ▶ PTO & HitchPTO Type Fully independent Independent PTO Rear 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) 540/750 rpm Mid-PTO Availability Not Published No mid-PTO offered Category, 3-Point Hitch Category II / I Category II Hitch Lift Capacity Not Published 5,115 lb Hitch Lift Capacity (at 24”) 3,664 lb 3,414 lb Lift Control Type Mechanical draft control; top link draft sensing Position / Draft / Mechanical ▶ Transmission & DrivetrainTransmission Type 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions 16F/16R Power Shuttle w/creeper No. of Speeds 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) 16 forward, 16 reverse (creeper interlock) Max Travel Speed (Forward) 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) 18.9 mph Max Travel Speed (Reverse) 20.1 mph Not Published Clutch Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options Mechanical rear differential lock 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Air-suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seat belt (cab) High-back suspension seat with extension Front Axle Type Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 151 in 157.5 in Overall Width Not Published 76.4 in Wheelbase 85.8 in (2WD); 83.9 in (4WD) 86.1 in Ground Clearance Not Published 18.3 in Min. Turn Radius without Brakes 134 in (2WD front axle) 162.8 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) 76 to 78.9 in Not Published Height to Top of Cab Model 94.8 to 97.8 in 103.3 in ▶ WeightTractor Weight (Base) 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) 6,052 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) R1 Agricultural - Front Not Published 11.2-24 R1 Agricultural - Rear Not Published 16.9-30 R3 Turf - Front Not Published 12.0-20.5 R3 Turf - Rear Not Published 22.4-25.5 R4 Industrial - Front Not Published 15-19.5 R4 Industrial - Rear Not Published 18.4-24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate L135SL: Skid-steer compatible quick coupler, self-leveling Loader Model Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) L135SL Loader Lift Height 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in L135SL: 135.5 in Loader Lift Capacity (Full Height) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) L135SL: 3,223 lb at pivot pin to full height Loader Breakout Force 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) L135SL: 5,335 lb at pivot pin ▶ WarrantyWarranty Length & Coverage Not Published Not Published
