| Engine Manufacturer | FPT Industrial | FPT |
|---|
| Engine Model | F34 | S8000 |
|---|
| Engine Type | 4-cylinder diesel, Smart Wastegate Turbo, intercooled | Turbocharged 3-cylinder diesel |
|---|
| No. of Cylinders | 4 | 3 |
|---|
| Displacement | 207 in³ | 179 in³ |
|---|
| Rated Engine Speed | 2300 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 74 hp | 74 hp |
|---|
| PTO Power | 61 hp | 60 hp |
|---|
| Engine Emissions Constraints | Tier 4B Final | Tier 4B Final |
|---|
| Cooling System Type | Liquid-cooled | Not Published |
|---|
| Air Cleaner | Not Published | PowerCore dry air cleaner |
|---|
| Fuel System | Common-rail fuel injection | Bosch electronic high-pressure common rail |
|---|
| Alternator | Not Published | 120 A |
|---|
|
|---|
| Pump Type | Dual-pump, open center | Dual gear pumps |
|---|
| Implement Flow | 16.9 gpm | 12.6 gpm |
|---|
| Steering Flow | 9.5 gpm | 7.6 gpm |
|---|
| Total Hydraulic Flow | 26.4 gpm (16.9 + 9.5, computed) | 20.2 gpm |
|---|
| Overall Hydraulic Pump Flow | 26.4 gpm (16.9 + 9.5, computed) | 20.2 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 2 | 2 |
|---|
| No. of Optional Remote Valves | ROPS: 3+2 (10 outlets); CAB: 4 (8 outlets) | 1 |
|---|
|
|---|
| Fuel Tank Capacity | ROPS: 21.4 gal; CAB: 27.5 gal | 21.7 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Electrohydraulic wet clutch (std on cab; opt on ROPS) | Fully independent, hydraulic wet clutch |
|---|
| PTO Rear | 540/540E (std); 540/540E/1000 and ground speed (opt) | 540 rpm (540/540E optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Not Published | Category I/II |
|---|
| Hitch Lift Capacity | 5,553 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | Not Published | 3,500 lb |
|---|
| Lift Control Type | Mechanical draft control with Lift-O-Matic system (standard); electronic draft control (optional, cab) | Mechanical draft control (upper-link draft sensing) |
|---|
|
|---|
| Transmission Type | ROPS: 16x16 Shuttle Command, 32x16 Dual Command; CAB: 16x16 Power Shuttle, 32x16 Dual Command | 12x12 hydraulic power shuttle |
|---|
| No. of Speeds | 16F/16R; 32F/16R | 12F/12R |
|---|
| Max Travel Speed (Forward) | 25 mph | 25 mph |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Wet clutch | 11 in single dry disc |
|---|
| Differential Lock & Limited Slip Options | Electro-hydraulic differential lock | Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Not Published | Hydrostatic power steering |
|---|
| Brakes | Oil-immersed brakes | Hydraulic-assist wet brakes |
|---|
| Seat Suspension & Adjustability | Not Published | Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: mechanical vinyl suspension seat |
|---|
| Front Axle Type | 4WD front axle | 4WD (MFD) limited-slip front axle, electro-hydraulic engagement |
|---|
| Front Axle Rating | Not Published | 6,500 lb dynamic capacity |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Width | 54.3 in | Not Published |
|---|
| Wheelbase | 85.8 in | 83.6 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | 95.0 in | 99.8 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | 100.2 in |
|---|
| Overall Length | Not Published | 154.1 in |
|---|
|
|---|
| Tractor Weight (Base) | Not Published | ROPS: 6,250 lb; Cab: 6,800 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Rear: 320/85R28 (T4F), 360/70R24 (T4F low-profile); other rear tires available | R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) |
|---|
| R1 Agricultural - Front | Not Published | 11.2x24 R1, 6 ply |
|---|
| R1 Agricultural - Rear | Not Published | 16.9x30 R1, 6 ply |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | 12.5/80-18 R4, 10 ply |
|---|
| R4 Industrial - Rear | Not Published | 19.5L-24 R4, 10 ply |
|---|
|
|---|
| Quick Attach Loader System | Not Published | 72 in bucket with SSL (skid steer) or Euro-style quick attach |
|---|
| Loader Model | Not Published | 550LU (non self-leveling); 555LU (mechanical self-leveling) |
|---|
| Loader Lift Height | Not Published | 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) |
|---|
| Loader Lift Capacity (Full Height) | Not Published | Not Published |
|---|
| Loader Breakout Force | Not Published | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
