▶ EngineEngine Manufacturer FPT FPT Engine Model F5D F5G Engine Type 4-cylinder diesel Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder turbocharged diesel, high-pressure common rail, air-to-air intercooled No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed Not Published 2200 rpm Engine Power (Gross) 98 hp 107 hp PTO Power 82 hp 93 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Electro Command: high-pressure common rail with electronic fuel delivery control Alternator Not Published 120 A ▶ HydraulicsPump Type Not Published Fixed displacement, tandem pumps (implement and steering) Implement Flow 16.9 gpm Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Steering Flow 9.7 gpm Dual Command: 9.7 gpm; Electro Command: 11.4 gpm Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 with DIA option) Dual Command: 2 or 3; Electro Command: 2 No. of Optional Remote Valves Not Published Electro Command: 3 (plus 2 mid-mount) ▶ Fluid CapacityFuel Tank Capacity 30.3 gal Electro Command: 43.6 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent (hydraulic wet disc clutch) PTO Rear 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Dual Command: 5,620 lb (7,351 lb with optional ram); Electro Command: 8,084 lb Hitch Lift Capacity (at 24”) 5,620 lb (7,351 lb with optional ram) Dual Command: 5,620 lb (7,351 lb with optional ram) Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional) Dual Command: 24x24 Dual Command Hi-Lo with power shuttle (standard); Electro Command: 16x16 Electro Command semi-powershift (AutoShift or 32x32 creeper optional) No. of Speeds 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Max Travel Speed (Forward) Not Published 25 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Electro-hydraulic rear differential lock; TerraLock automatic 4WD and differential lock engagement optional on Electro Command ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Hydraulic wet disc Seat Suspension & Adjustability Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Not Published Front Axle Type Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional) 4WD front axle, class 1.5 HD (TerraGlide suspended 4WD front axle optional on Electro Command) Front Axle Rating 4,700 lb (standard-duty 4WD, in-action capacity); 5,100 lb (heavy-duty 4WD, in-action capacity) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 161 in; 4WD: 158 in Dual Command: 160.9 in; Electro Command: 165 in Overall Width 75.7 in Dual Command: 75.7 in Wheelbase 2WD: 90.2 in; 4WD: 87.9 in Dual Command: 89.9 in; Electro Command: 93.7 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 132 in (2WD front axle) Not Published Height to Top of ROPS 106.5 in Dual Command: 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.1 in Dual Command: 102.1 in; Electro Command: 107 in ▶ WeightTractor Weight (Base) ROPS/2WD: 6,768 lb; ROPS/4WD: 7,451 lb; Cab/2WD: 7,253 lb; Cab/4WD: 7,936 lb Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published 14.9R24 R1 Agricultural - Rear Not Published 18.4R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer or Euro-style quick attach faceplate Skid-steer style or Euro (European) style tool carrier Loader Model 655TL, 665TL (factory installed, NSL or MSL); 825TL, 835TL, 640TL (dealer installed, NSL or MSL) 825TL; 835TL (each NSL or MSL); 810LA (NSL); 815LA (MSL) Loader Lift Height 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 825TL: 135 in; 835TL: 143 in; 640TL: 137 in 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) Loader Lift Capacity (Full Height) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 825TL NSL: 2,755 lb; 825TL MSL: 2,888 lb; 835TL NSL: 3,395 lb; 835TL MSL: 3,571 lb; 640TL NSL: 2,226 lb; 640TL MSL: 2,733 lb (at max height) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) Loader Breakout Force 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 825TL NSL: 2,910 lb; 825TL MSL: 3,196 lb; 835TL NSL: 3,615 lb; 835TL MSL: 3,990 lb; 640TL NSL: 3,747 lb; 640TL MSL: 3,306 lb 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
