▶ EngineEngine Manufacturer FPT FPT Engine Model F5D F36 Engine Type 4-cylinder diesel 4-cylinder No. of Cylinders 4 4 Displacement 207 in³ Not Published Rated Engine Speed Not Published Not Published Engine Power (Gross) 98 hp 101 hp PTO Power 82 hp 85 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Not Published Not Published Implement Flow 16.9 gpm Not Published Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 21 gpm Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 with DIA option) Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Not Published PTO Rear 540 (12x12 base); 540/540E or 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb (7,351 lb with optional ram) Not Published Lift Control Type Not Published Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command or 40x40 Dual Command with creeper (optional) 12x12 electronic power shuttle No. of Speeds 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) 12 forward / 12 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Cab: fabric mechanical-suspension seat (standard) or fabric air-suspension seat with 15 degree swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Air ride seat (standard); instructor seat available Front Axle Type Standard-duty electronically engaged 4WD front axle (standard); mechanically engaged standard-duty 4WD, heavy-duty electronically engaged 4WD, or 2WD front axle (optional) Class 1.0 HD heavy-duty front axle Front Axle Rating 4,700 lb (standard-duty 4WD, in-action capacity); 5,100 lb (heavy-duty 4WD, in-action capacity) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 2WD: 161 in; 4WD: 158 in Not Published Overall Width 75.7 in Not Published Wheelbase 2WD: 90.2 in; 4WD: 87.9 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 132 in (2WD front axle) Not Published Height to Top of ROPS 106.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.1 in Not Published ▶ WeightTractor Weight (Base) ROPS/2WD: 6,768 lb; ROPS/4WD: 7,451 lb; Cab/2WD: 7,253 lb; Cab/4WD: 7,936 lb Not Published Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer or Euro-style quick attach faceplate Not Published Loader Model 655TL, 665TL (factory installed, NSL or MSL); 825TL, 835TL, 640TL (dealer installed, NSL or MSL) 630LU; 635LU Loader Lift Height 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 825TL: 135 in; 835TL: 143 in; 640TL: 137 in 143.9 in (630LU and 635LU) Loader Lift Capacity (Full Height) 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 825TL NSL: 2,755 lb; 825TL MSL: 2,888 lb; 835TL NSL: 3,395 lb; 835TL MSL: 3,571 lb; 640TL NSL: 2,226 lb; 640TL MSL: 2,733 lb (at max height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 825TL NSL: 2,910 lb; 825TL MSL: 3,196 lb; 835TL NSL: 3,615 lb; 835TL MSL: 3,990 lb; 640TL NSL: 3,747 lb; 640TL MSL: 3,306 lb Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
