3 or 4 mechanical; 3 or 4 electro-hydraulic (Elite, 4 on Auto Command); 2 or 3 mid-mount valves (mechanical or electronic)
Fuel Tank Capacity
37 gal
52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Front Axle Fluid Capacity
Not Published
Not Published
PTO Type
Independent, electro-hydraulic clutch
Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft
PTO Rear
540/1000
540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm)
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II
Category II (Category III/II available)
Hitch Lift Capacity
Not Published
Not Published
Hitch Lift Capacity (at 24”)
T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2)
Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb
Lift Control Type
Electronic draft control
Electronic draft control
Transmission Type
T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional)
Electro Command 16x16 semi-powershift (standard; AutoShift, 17x16 Economy, 17x16 Fast Mover 31 mph and 32x32 creeper options); Dynamic Command 23x23 semi-powershift (24x24 Economy, 31 mph and creeper options); Auto Command continuously variable transmission (CVT)
Electro Command: 16F/16R (17F/16R Economy or Fast Mover, 32F/32R creeper); Dynamic Command: 23F/23R (24F/24R options); Auto Command: continuously variable
Max Travel Speed (Forward)
Not Published
25 mph (Electro Command 16x16, Dynamic Command 23x23 and Auto Command CVT standard); 31 mph (Fast Mover 17x16, Dynamic Command 24x24 31 mph and optional Auto Command 31 mph, FWD only); 19 mph (2WD)
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Not Published
Not Published
Differential Lock & Limited Slip Options
Electro-hydraulic rear differential lock; limited slip front
Terralock automatic traction management: automatic 4WD engagement and front and rear differential locks
Frame Type
Not Published
Not Published
Steering
Hydrostatic power steering
Not Published
Brakes
Hydraulic wet disc
Wet disc
Seat Suspension & Adjustability
Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available
Comfort seat with low-frequency suspension standard; Dynamic Comfort seat (low-frequency suspension, heated) and Auto Comfort seat (active suspension, heated and ventilated) optional; swiveling backrest; Comfort Ride cab suspension optional
Front Axle Type
Heavy-duty 4WD front axle (standard)
Standard FWD axle (Class 3 and 4); Terraglide suspended FWD axle or SuperSteer FWD axle optional; heavy-duty 2WD axle available on Electro Command models
Front Axle Rating
4,500 lb (in-action capacity at 4 mph)
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
T5.115: 163.8 in; T5.115 Electro Command: 165.0 in
204.3 in (front linkage to rear linkage)
Overall Width
82.6 in
89.8 in (minimum; 91 in with 650/65R38 tires)
Wheelbase
92.5 in
Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in
Ground Clearance
Not Published
18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38)
Min. Turn Radius without Brakes
Not Published
15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle)
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab)
115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (Comfort Ride suspension cab)
