▶ EngineEngine Manufacturer FPT FPT Engine Model F5G NEF Engine Type Dual Command: 4-cylinder diesel; Electro Command: 4-cylinder turbocharged diesel, high-pressure common rail, air-to-air intercooled 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail and electronic fuel delivery control No. of Cylinders 4 4 Displacement 207 in³ 274 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 117 hp 125 hp PTO Power Dual Command: 100 hp; Electro Command: 99 hp 105 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Not Published Air Cleaner Not Published Not Published Fuel System Electro Command: high-pressure common rail with electronic fuel delivery control High-pressure common rail with electronic fuel delivery control Alternator 120 A 150 A ▶ HydraulicsPump Type Fixed displacement, tandem pumps (implement and steering) Value: fixed displacement implement pump; Plus, Elite, Dynamic Command: closed-center load-sensing (CCLS) pump Implement Flow Dual Command: 16.9 gpm; Electro Command: 21.1 gpm Value: 21.1 gpm; Plus, Elite: 29.9 gpm Steering Flow Dual Command: 9.7 gpm; Electro Command: 11.4 gpm 12.4 gpm (17.2 gpm optional pump with Class 4 front axle) Total Hydraulic Flow Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Overall Hydraulic Pump Flow Dual Command: 26.6 gpm (16.9 + 9.7, computed); Electro Command: 32.5 gpm (21.1 + 11.4, computed) Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Hydraulic System Type Open center Value: fixed displacement (open) system; Plus, Elite, Dynamic Command: closed-center load-sensing (CCLS) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Dual Command: 2 or 3; Electro Command: 2 2 mechanical (Value, Plus, Elite) No. of Optional Remote Valves Electro Command: 3 (plus 2 mid-mount) 3 or 4 mechanical; 3 or 4 electro-hydraulic (Elite); 2 or 3 mid-mount valves (mechanical or electronic) ▶ Fluid CapacityFuel Tank Capacity Electro Command: 43.6 gal 52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent (hydraulic wet disc clutch) Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft PTO Rear Dual Command: 540/1000 rpm (optional); Electro Command: 540/1000 rpm (540/540E/1000 optional) 540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Not Published Hitch Lift Capacity Dual Command: 5,620 lb (7,351 lb with optional ram); Electro Command: 8,084 lb Not Published Hitch Lift Capacity (at 24”) Dual Command: 5,620 lb (7,351 lb with optional ram) Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb Lift Control Type Not Published Electronic draft control ▶ Transmission & DrivetrainTransmission Type Dual Command: 24x24 Dual Command Hi-Lo with power shuttle (standard); Electro Command: 16x16 Electro Command semi-powershift (AutoShift or 32x32 creeper optional) Electro Command 16x16 semi-powershift (standard; AutoShift, 17x16 Economy, 17x16 Fast Mover 31 mph and 32x32 creeper options); Dynamic Command 23x23 semi-powershift (24x24 Economy, 31 mph and creeper options) No. of Speeds Dual Command: 24F/24R; Electro Command: 16F/16R (32F/32R with creeper) Electro Command: 16F/16R (17F/16R Economy or Fast Mover, 32F/32R creeper); Dynamic Command: 23F/23R (24F/24R options) Max Travel Speed (Forward) 25 mph 25 mph (Electro Command 16x16 and Dynamic Command 23x23 standard); 31 mph (Fast Mover 17x16 and Dynamic Command 24x24 31 mph options, FWD only); 19 mph (2WD) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; TerraLock automatic 4WD and differential lock engagement optional on Electro Command Terralock automatic traction management: automatic 4WD engagement and front and rear differential locks ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Hydraulic wet disc Not Published Seat Suspension & Adjustability Not Published Comfort seat with low-frequency suspension standard; Dynamic Comfort seat (low-frequency suspension, heated) and Auto Comfort seat (active suspension, heated and ventilated) optional; swiveling backrest; Comfort Ride cab suspension optional Front Axle Type 4WD front axle, class 1.5 HD (TerraGlide suspended 4WD front axle optional on Electro Command) Standard FWD axle (Class 3 and 4); Terraglide suspended FWD axle or SuperSteer FWD axle optional; heavy-duty 2WD axle available on Electro Command models Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Dual Command: 160.9 in; Electro Command: 165 in 204.3 in (front linkage to rear linkage) Overall Width Dual Command: 75.7 in 89.8 in (minimum; 91 in with 650/65R38 tires) Wheelbase Dual Command: 89.9 in; Electro Command: 93.7 in Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in Ground Clearance Not Published 18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38) Min. Turn Radius without Brakes Not Published 15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle) Height to Top of ROPS Dual Command: 106.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Dual Command: 102.1 in; Electro Command: 107 in 115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (Comfort Ride suspension cab) ▶ WeightTractor Weight (Base) Dual Command (ROPS): 7,672 lb; Dual Command (Cab): 8,157 lb; Electro Command (Cab): 10,031 lb 10,560 lb (minimum shipping weight, cab FWD, less ballast; average 11,376 lb, maximum 12,513 lb; 2WD is 1,234 lb less) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (Comfort Ride cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires R1 Agricultural - Front 14.9R24 Not Published R1 Agricultural - Rear 18.4R34 18.4R38 (reference tire; also 16.9R38, 520/70R38, 600/65R38, 650/65R38, 480/70R38, 540/65R38, 650/60R38) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style or Euro (European) style tool carrier Euro style (850LA, 855LA, 857LA); Euro or skid steer style (810LA) Loader Model 825TL; 835TL (each NSL or MSL); 810LA (NSL); 815LA (MSL) FWD: 850LA (NSL), 855LA (MSL); SuperSteer FWD: 857LA (MSL); 2WD: 810LA (NSL) Loader Lift Height 825TL: 139.0 in; 835TL: 146.9 in (to pivot pin) 850LA: 162.0 in; 855LA: 162.0 in; 857LA: 166.8 in; 810LA (2WD): 142.8 in (to pivot pin, base equipment tires) Loader Lift Capacity (Full Height) 825TL NSL: 2,954 lb; 825TL MSL: 3,086 lb; 835TL NSL: 3,638 lb; 835TL MSL: 3,836 lb (to max height, measured 31.5 in forward of pivot pin) 850LA: 2,932 lb; 855LA: 5,202 lb; 857LA: 4,365 lb; 810LA (2WD): 2,380 lb (to maximum height, measured 31.5 in forward of the pivot pin, with rear counterbalance) Loader Breakout Force 825TL NSL: 3,109 lb; 825TL MSL: 3,417 lb; 835TL NSL: 3,880 lb; 835TL MSL: 4,277 lb (measured 31.5 in forward of pivot pin) 850LA: 4,673 lb; 855LA: 5,974 lb; 857LA: 4,894 lb; 810LA (2WD): 3,439 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
