3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two
Hitch Lift Capacity (at 24”)
10,228 lb
Not Published
Lift Control Type
Electronic Draft Control (EDC)
Not Published
Transmission Type
Dynamic Command: 24x24 Dynamic Command dual-clutch 8-step semi-powershift; Auto Command: Auto Command continuously variable transmission (CVT)
8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional
No. of Speeds
Dynamic Command: 24F/24R; Auto Command: continuously variable
8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo)
Max Travel Speed (Forward)
25 mph
19 mph or 25 mph (25 mph 4WD only)
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Not Published
Not Published
Differential Lock & Limited Slip Options
Electro-hydraulic front and rear differential lock, Terralock automatic diff lock and 4WD management (standard)
Not Published
Frame Type
Not Published
Not Published
Steering
Power steering
Not Published
Brakes
Hydraulic wet disc
Not Published
Seat Suspension & Adjustability
Comfort seat with low-frequency suspension standard; Dynamic Comfort (dynamic damping, heated) and Auto Comfort (semi-active, heated and ventilated) seats optional
Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab)
Front Axle Type
Class 1.75 heavy-duty 4WD front axle (Terraglide front axle suspension optional)
Heavy-duty front axle, 2WD or 4WD (both optional, cab only)
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
173 in
184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights)
