▶ EngineEngine Manufacturer FPT FPT Engine Model NEF F5 Engine Type 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail and electronic fuel delivery control Turbocharged 4-cylinder diesel No. of Cylinders 4 4 Displacement 274 in³ 207 in³ Rated Engine Speed 2100 rpm 2300 rpm Engine Power (Gross) 116 hp 112 hp PTO Power 95 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled (viscous fan) Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common rail with electronic fuel delivery control Not Published Alternator 150 A 120 A ▶ HydraulicsPump Type Value: fixed displacement implement pump; Plus, Elite, Dynamic Command, Auto Command: closed-center load-sensing (CCLS) pump Not Published Implement Flow Value: 21.1 gpm; Plus, Elite: 29.9 gpm; Auto Command: 33.5 gpm 16.9 gpm (21.6 gpm optional) Steering Flow 12.4 gpm (17.2 gpm optional pump with Class 4 front axle) 9.7 gpm Total Hydraulic Flow Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed); Auto Command: 45.9 gpm (33.5 + 12.4, computed) 26.6 gpm (16.9 + 9.7, computed) Overall Hydraulic Pump Flow Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed); Auto Command: 45.9 gpm (33.5 + 12.4, computed) 26.6 gpm (16.9 + 9.7, computed) Hydraulic System Type Value: fixed displacement (open) system; Plus, Elite, Dynamic Command, Auto Command: closed-center load-sensing (CCLS) Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 mechanical (Value, Plus, Elite); 3 electro-hydraulic (Auto Command) 2 or 3 No. of Optional Remote Valves 3 or 4 mechanical; 3 or 4 electro-hydraulic (Elite, 4 on Auto Command); 2 or 3 mid-mount valves (mechanical or electronic) Not Published ▶ Fluid CapacityFuel Tank Capacity 52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal ROPS: 24 gal; Cab: 29 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft Wet clutch PTO with electro-hydraulic engagement PTO Rear 540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm) 540 (base); 540/540E or 540/1000 (optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (Category III/II available) Category II/I Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb 3,200 lb (6,200 lb with optional ram) Lift Control Type Electronic draft control Lift-O-Matic 3-point quick raise system ▶ Transmission & DrivetrainTransmission Type Electro Command 16x16 semi-powershift (standard; AutoShift, 17x16 Economy, 17x16 Fast Mover 31 mph and 32x32 creeper options); Dynamic Command 23x23 semi-powershift (24x24 Economy, 31 mph and creeper options); Auto Command continuously variable transmission (CVT) 12x12 power shuttle No. of Speeds Electro Command: 16F/16R (17F/16R Economy or Fast Mover, 32F/32R creeper); Dynamic Command: 23F/23R (24F/24R options); Auto Command: continuously variable 12F/12R Max Travel Speed (Forward) 25 mph (Electro Command 16x16, Dynamic Command 23x23 and Auto Command CVT standard); 31 mph (Fast Mover 17x16, Dynamic Command 24x24 31 mph and optional Auto Command 31 mph, FWD only); 19 mph (2WD) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Terralock automatic traction management: automatic 4WD engagement and front and rear differential locks Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Comfort seat with low-frequency suspension standard; Dynamic Comfort seat (low-frequency suspension, heated) and Auto Comfort seat (active suspension, heated and ventilated) optional; swiveling backrest; Comfort Ride cab suspension optional Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Front Axle Type Standard FWD axle (Class 3 and 4); Terraglide suspended FWD axle or SuperSteer FWD axle optional; heavy-duty 2WD axle available on Electro Command models 4WD front axle, electro-hydraulic engagement (standard) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 204.3 in (front linkage to rear linkage) 161.1 in (4WD) Overall Width 89.8 in (minimum; 91 in with 650/65R38 tires) Not Published Wheelbase Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in Cab: 88.9 in; ROPS: 83.7 in Ground Clearance 18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38) Not Published Min. Turn Radius without Brakes 15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle) Not Published Height to Top of ROPS Not Published 103.0 in Height to Top of ROPS (folded) Not Published Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Height to Top of Cab Model 115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (Comfort Ride suspension cab) 105.4 in ▶ WeightTractor Weight (Base) 10,560 lb (minimum shipping weight, cab FWD, less ballast; average 11,376 lb, maximum 12,513 lb; 2WD is 1,234 lb less) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (Comfort Ride cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires R1 agricultural, R3 turf or R4 industrial R1 Agricultural - Front 380/85R28 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) R1 Agricultural - Rear 18.4R38 (reference tire; also 16.9R38, 520/70R38, 600/65R38, 650/65R38, 480/70R38, 540/65R38, 650/60R38) 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Euro style (850LA, 855LA, 857LA); Euro or skid steer style (810LA) Skid-steer style (84 in bucket standard); Euro-style quick attach available Loader Model FWD: 850LA (NSL), 855LA (MSL); SuperSteer FWD: 857LA (MSL); 2WD: 810LA (NSL) 632TL (NSL); 637TL (MSL) Loader Lift Height 850LA: 162.0 in; 855LA: 162.0 in; 857LA: 166.8 in; 810LA (2WD): 142.8 in (to pivot pin, base equipment tires) 632TL: 134.5 in; 637TL: 134.5 in Loader Lift Capacity (Full Height) 850LA: 2,932 lb; 855LA: 5,202 lb; 857LA: 4,365 lb; 810LA (2WD): 2,380 lb (to maximum height, measured 31.5 in forward of the pivot pin, with rear counterbalance) 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) Loader Breakout Force 850LA: 4,673 lb; 855LA: 5,974 lb; 857LA: 4,894 lb; 810LA (2WD): 3,439 lb (measured 31.5 in forward of the pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
