Rear: 3 or 4 mechanical, or 3 or 4 electro-hydraulic (Elite; 4 on Auto Command); mid-mount: 2 or 3, mechanical or electronic
Not Published
Fuel Tank Capacity
52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal
34.3 gal
Coolant Capacity
Not Published
Not Published
Crankcase Capacity
Not Published
Not Published
Transmission / Hydraulic System Capacity
Not Published
Not Published
Front Axle Fluid Capacity
Not Published
Not Published
PTO Type
Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft
Not Published
PTO Rear
540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm)
Not Published
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category II (Category III/II available)
Not Published
Hitch Lift Capacity
Not Published
Not Published
Hitch Lift Capacity (at 24”)
Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb
Not Published
Lift Control Type
Electronic draft control
Not Published
Transmission Type
Electro Command: 16x16 semi-powershift (standard), with 17x16 economy, 17x16 31 mph, 32x32 creeper and auto-shift options; Dynamic Command: 23x23 semi-powershift, with 24x24 economy, 31 mph and creeper options; Auto Command: continuously variable (CVT)
12x12 electronic power shuttle
No. of Speeds
Electro Command: 16F/16R, or 17F/16R economy or high-speed, 32F/32R with creeper; Dynamic Command: 23F/23R, or 24F/24R optional; Auto Command: continuously variable
12 forward / 12 reverse
Max Travel Speed (Forward)
25 mph (Electro Command 16x16, Dynamic Command 23x23 and Auto Command CVT standard); 31 mph (17x16 high-speed, Dynamic Command 24x24 31 mph and optional Auto Command 31 mph, FWD only); 19 mph (2WD)
Not Published
Max Travel Speed (Reverse)
Not Published
Not Published
Clutch
Not Published
Not Published
Differential Lock & Limited Slip Options
Terralock automatic traction management: automatic four-wheel drive engagement and front and rear differential locks
Not Published
Frame Type
Not Published
Not Published
Steering
Not Published
Not Published
Brakes
Wet disc
Not Published
Seat Suspension & Adjustability
Standard: low-frequency suspension seat; optional: heated low-frequency suspension seat, or heated and ventilated active-suspension seat; swiveling backrest; suspended cab optional
Air ride seat (standard); instructor seat available
Front Axle Type
Standard FWD axle (Class 3 and 4); optional: Terraglide suspended FWD axle or SuperSteer FWD axle; heavy-duty 2WD axle available on Electro Command
Class 1.0 HD heavy-duty front axle
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Width
89.8 in (minimum; 91 in with 650/65R38 tires)
Not Published
Wheelbase
Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in
Not Published
Ground Clearance
18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38)
Not Published
Min. Turn Radius without Brakes
15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle)
Not Published
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (suspended cab)
Not Published
Overall Length
204.3 in (front linkage to rear linkage)
Not Published
Tractor Weight (Base)
10,560 lb (minimum shipping weight, cab FWD, less ballast)
Not Published
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Tire Size & Options
Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (suspended cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires
