Terralock automatic traction management: automatic 4WD engagement and front and rear differential locks
Not Published
Frame Type
Not Published
Not Published
Steering
Not Published
Not Published
Brakes
Not Published
Not Published
Seat Suspension & Adjustability
Comfort seat with low-frequency suspension standard; Dynamic Comfort seat (low-frequency suspension, heated) and Auto Comfort seat (active suspension, heated and ventilated) optional; swiveling backrest; Comfort Ride cab suspension optional
Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab)
Front Axle Type
Standard FWD axle (Class 3 and 4); Terraglide suspended FWD axle or SuperSteer FWD axle optional; heavy-duty 2WD axle available on Electro Command models
Heavy-duty front axle, 2WD or 4WD (both optional, cab only)
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
204.3 in (front linkage to rear linkage)
184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights)
Overall Width
89.8 in (minimum; 91 in with 650/65R38 tires)
Not Published
Wheelbase
Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in
Not Published
Ground Clearance
18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38)
Not Published
Min. Turn Radius without Brakes
15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle)
Not Published
Height to Top of ROPS
Not Published
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (Comfort Ride suspension cab)
110.2 in
Tractor Weight (Base)
10,560 lb (minimum shipping weight, cab FWD, less ballast; average 11,376 lb, maximum 12,513 lb; 2WD is 1,234 lb less)
