| Engine Manufacturer | FPT | FPT |
|---|
| Engine Model | NEF | F5 |
|---|
| Engine Type | 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail | Turbocharged 4-cylinder diesel |
|---|
| No. of Cylinders | 4 | 4 |
|---|
| Displacement | 274 in³ | 207 in³ |
|---|
| Rated Engine Speed | 2200 rpm | 2300 rpm |
|---|
| Engine Power (Gross) | 110 hp | 112 hp |
|---|
| PTO Power | 92 hp | 92 hp |
|---|
| Engine Emissions Constraints | Tier 4 | Tier 4 |
|---|
| Cooling System Type | Not Published | Liquid-cooled |
|---|
| Air Cleaner | Not Published | Not Published |
|---|
| Fuel System | High-pressure common rail fuel injection | Not Published |
|---|
| Alternator | 120 A | 120 A |
|---|
|
|---|
| Pump Type | Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve | Not Published |
|---|
| Implement Flow | 19 gpm (combined implement and auxiliary pump flow) | 16.9 gpm (21.6 gpm optional) |
|---|
| Steering Flow | 9 gpm | 9.7 gpm |
|---|
| Total Hydraulic Flow | 28 gpm | 26.6 gpm (16.9 + 9.7, computed) |
|---|
| Overall Hydraulic Pump Flow | 28 gpm | 26.6 gpm (16.9 + 9.7, computed) |
|---|
| Hydraulic System Type | Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control | Open center |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | 2 or 3 |
|---|
| No. of Optional Remote Valves | Not Published | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 57.5 gal | ROPS: 24 gal; Cab: 29 gal |
|---|
| Coolant Capacity | Not Published | Not Published |
|---|
| Crankcase Capacity | Not Published | Not Published |
|---|
| Transmission / Hydraulic System Capacity | Not Published | Not Published |
|---|
| Front Axle Fluid Capacity | Not Published | Not Published |
|---|
|
|---|
| PTO Type | Not Published | Wet clutch PTO with electro-hydraulic engagement |
|---|
| PTO Rear | 540/1000 rpm | 540 (base); 540/540E or 540/1000 (optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category II (flex link ends) | Category II/I |
|---|
| Hitch Lift Capacity | 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | Not Published | 3,200 lb (6,200 lb with optional ram) |
|---|
| Lift Control Type | Not Published | Lift-O-Matic 3-point quick raise system |
|---|
|
|---|
| Transmission Type | 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional | 12x12 power shuttle |
|---|
| No. of Speeds | 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) | 12F/12R |
|---|
| Max Travel Speed (Forward) | 19 mph or 25 mph (25 mph 4WD only) | Not Published |
|---|
| Max Travel Speed (Reverse) | Not Published | Not Published |
|---|
| Clutch | Not Published | Not Published |
|---|
| Differential Lock & Limited Slip Options | Not Published | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Not Published | Power steering |
|---|
| Brakes | Not Published | Wet disc |
|---|
| Seat Suspension & Adjustability | Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) | Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat |
|---|
| Front Axle Type | 4WD heavy-duty front axle, Standard Duty Class 3 (cab and 4WD only) | 4WD front axle, electro-hydraulic engagement (standard) |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 184.7 in (4WD, with front weights) | 161.1 in (4WD) |
|---|
| Overall Width | Not Published | Not Published |
|---|
| Wheelbase | 99.2 in (4WD, Standard Duty Class 3 axle) | Cab: 88.9 in; ROPS: 83.7 in |
|---|
| Ground Clearance | Not Published | Not Published |
|---|
| Min. Turn Radius without Brakes | Not Published | Not Published |
|---|
| Height to Top of ROPS | Not Published | 103.0 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) |
|---|
| Height to Top of Cab Model | 110.2 in | 105.4 in |
|---|
|
|---|
| Tractor Weight (Base) | 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) | Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | 18.4-38 R1 rear with 14.9-28 R1 front (4WD) | R1 agricultural, R3 turf or R4 industrial |
|---|
| R1 Agricultural - Front | 14.9-28 (4WD) | 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) |
|---|
| R1 Agricultural - Rear | 18.4-38 | 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | 12.5/80-18 |
|---|
| R4 Industrial - Rear | Not Published | 19.5L24 |
|---|
|
|---|
| Quick Attach Loader System | Skid steer (SSL) or Euro style attachment couplers | Skid-steer style (84 in bucket standard); Euro-style quick attach available |
|---|
| Loader Model | 830LA (NSL); 835LA (MSL) | 632TL (NSL); 637TL (MSL) |
|---|
| Loader Lift Height | 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) | 632TL: 134.5 in; 637TL: 134.5 in |
|---|
| Loader Lift Capacity (Full Height) | 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) | 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) |
|---|
| Loader Breakout Force | 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
