New Holland Workmaster 60 vs New Holland Workmaster 65
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 8 measurable specs, the New Holland Workmaster 65 leads 6 categories to 2. Machine pages: New Holland Workmaster 60 and New Holland Workmaster 65.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | New Holland Workmaster 60 | New Holland Workmaster 65 |
|---|---|---|
| Engine HP (hp) | 60 hp | ▲ 64 hp |
| PTO HP (hp) | ▲ 51 hp | 50 hp |
| Weight (lb) | 5,059 lb | ▲ 6,800 lb |
| Loader Lift (lb) | ▲ 3,549 lb | 3,153 lb |
| 3-Pt Lift (24 in) (lb) | 2,701 lb | ▲ 3,500 lb |
| Lift Height (in) | 122 in | ▲ 131.3 in |
| Breakout Force (lbf) | 3,527 lbf | n/a |
| Hydraulic Flow (gpm) | 17.5 gpm | ▲ 20.2 gpm |
| Travel Speed (mph) | 19.1 mph | ▲ 25 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | New HollandWorkmaster 60 | New HollandWorkmaster 65 |
|---|
| Engine Manufacturer | FPT | FPT |
|---|---|---|
| Engine Model | R753 | S8000 |
| Engine Type | Turbocharged, intercooled 3-cylinder diesel | Turbocharged 3-cylinder diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 136 in³ | 179 in³ |
| Rated Engine Speed | 2600 rpm | 2300 rpm |
| Engine Power (Gross) | 60 hp | 64 hp |
| PTO Power | 51 hp | 50 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Pressurized liquid with recirculating bypass | Not Published |
| Air Cleaner | 2-stage | PowerCore dry air cleaner |
| Fuel System | Common rail direct injection (CRDI) | Bosch electronic high-pressure common rail |
| Alternator | 75 A | 120 A |
New Holland Workmaster 60 vs New Holland Workmaster 65: Quick Answers
- Which has more horsepower, the New Holland Workmaster 60 or the New Holland Workmaster 65?
- The New Holland Workmaster 65 leads on engine hp at 64 hp hp, compared to 60 hp hp for the New Holland Workmaster 60.
- Which has more PTO horsepower, the New Holland Workmaster 60 or the New Holland Workmaster 65?
- The New Holland Workmaster 60 leads on pto hp at 51 hp hp, compared to 50 hp hp for the New Holland Workmaster 65.
- Which is heavier, the New Holland Workmaster 60 or the New Holland Workmaster 65?
- The New Holland Workmaster 65 leads on weight at 6,800 lb lb, compared to 5,059 lb lb for the New Holland Workmaster 60.
- Which has more loader lift capacity, the New Holland Workmaster 60 or the New Holland Workmaster 65?
- The New Holland Workmaster 60 leads on loader lift at 3,549 lb lb, compared to 3,153 lb lb for the New Holland Workmaster 65.
- Which has more three-point hitch lift capacity, the New Holland Workmaster 60 or the New Holland Workmaster 65?
- The New Holland Workmaster 65 leads on 3-pt lift (24 in) at 3,500 lb lb, compared to 2,701 lb lb for the New Holland Workmaster 60.
