▶ EnginePTO Power 540 rpm, 1st stage 18 hp Alternator 50 A, 12 V 50 A, 12 V Air Cleaner Present (standard equipment) Dry, Element Engine Type Vertical, water cooled 4-cycle, diesel engine 3 CYL, Water Cooled, Diesel Fuel System Diesel fuel system with fuel injection pump Diesel Displacement 104.6 in³ 71.7 in³ No. of Cylinders 3 3 Rated Engine Speed 2100 rpm 2600 rpm Cooling System Type Pressurized Radiator Water Cooled Engine Manufacturer A1700N6, A1700N5, A1700N4 TYM Engine Power (Gross) 24.5 hp 24 hp Engine Emissions Constraints Not Published Final Tier4 Engine Model — A1100N2 ▶ WeightTractor Weight (Base) 3,496.5 lb (3,497 lbs), 3,728 lb (3,728 lbs) 1,829.8 lb (1,829 lbs) for 2024H, 2,107.6 lb (2,107 lbs) for 3026H Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 2,106 lbs - base tractor with loader, no cab option confirmed for 3026 in available sources ▶ WarrantyWarranty Length & Coverage 6-year powertrain warranty 6-year powertrain warranty ▶ HydraulicsPump Type Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Gear type pump with primary and secondary pumps Steering Flow 4.0 gpm 3.1 gpm Implement Flow 7.5 gpm 4.3 gpm Total Hydraulic Flow 11.5 gpm (4.0 + 7.5) 7.4 gpm 28.0 lpm Hydraulic System Type Not Published Power Assisted Hydro-Static System Operating Pressure 463 lbf/cm² maximum 352.7 lbf/cm² (max operating pressure) Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 11.5 gpm 7.7 gal per min No. of Optional Remote Valves Optional (Up to 2) Optional (Up To 1) No. of Standard Remote Valves Not Published 0 ▶ PTO & HitchPTO Rear 540 rpm 540 / 960 rpm @ 2,600 rpm PTO Type Independent Live P.T.O. (6 Spline shaft) Lift Control Type Position control type Position control Hitch Lift Capacity 2,425 lb @ 24 in behind lift point 1,433 lbs Mid-PTO Availability Not Published Option: 2,500 rpm (Mid) Category, 3-Point Hitch Category 1 Cat 1 Hitch Lift Capacity (at 24”) 2,425 lb @ 24 in behind lift point 974 lb ▶ Tire OptionsR3 Turf - Rear Not Published Not Published R3 Turf - Front Not Published Not Published Tire Size & Options OEM website lists IND tires 25X8.50-14 / 15-19.5; Operator Manual spec based on 8.0-16 / 12.4-24 IND (Industrial) Front: 25×8.50-14; IND Rear: 14×17.5 R4 Industrial - Rear 15-19.5 14X17.5 R4 Industrial - Front 25X8.50-14 25X8.50-14 R1 Agricultural - Rear 12.4-24 6PR 11.2-20 8PR R1 Agricultural - Front 8.0-16 4PR 7-16 6PR ▶ Fluid CapacityCoolant Capacity 5.0 ℓ (1.32 u.s. gal) 1.21 gal Crankcase Capacity 4.3 ℓ (1.14 u.s. gal) 0.79 gal Fuel Tank Capacity 27 ℓ (7.13 u.s. gal) 6.08 gal Front Axle Fluid Capacity Not Published 0.79 gal Transmission / Hydraulic System Capacity HST: 9.77 gal 2.90 gal ▶ Loader & AttachmentsLoader Lift Height 104 in 86 in. Loader Breakout Force 3,660 lb 1,960 lbs. Quick Attach Loader System SSQA SSQA Loader Lift Capacity (Full Height) 2,200 lb (pivot pin) 1,314 lbs. ▶ Transmission & DrivetrainClutch None (HST) Dry Single Plate No. of Speeds 3 Range 3 Range Transmission Type HST (Hydrostatic Transmission) with shuttle type Hydrostatic (HST) Max Travel Speed (Forward) Not Published 14.8 mph Max Travel Speed (Reverse) Not Published 14.8 mph Differential Lock & Limited Slip Options Differential lock Differential Lock ▶ Chassis, Steering & ControlsBrakes Wet, Multi-Disc Wet, Multi-Disc Steering Hydrostatic power steering Hydrostatic Frame Type Not Published Steel frame with cast iron axles Front Axle Type Not Published 4 Wheel Drive Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Adjustable seat; flips up and back for rear backhoe operation ▶ Dimensions & ManeuverabilityWheelbase 65.8 in (65.79 in.) 65.7" Overall Width 57.1 in (57.13 in.) [ROPS Model], 55.6 in (55.63 in.) [Cabin Model] 53.8" Overall Length 134.9 in (134.88 in.) 120.7 in for 2024H, 122.9 in for 3026H Ground Clearance 13.2 in (13.19 in.) [ROPS Model], 13.5 in (13.50 in.) [Cabin Model] 16.4" Height to Top of ROPS 104.1 in (104.06 in.) [ROPS Model], 88.9 in (88.9 in.) [Cabin Model] 91.4" Height to Top of Cab Model Not Published Not Applicable Height to Top of ROPS (folded) Not Published 91.4 in - ROPS up (no folded dimension found in available sources) Min. Turn Radius without Brakes Not Published 46° Overall Length with 3-Point Hitch 134.88 in 110 in ▶ ITC Company AccessoriesAccessories that fit
