▶ EngineEngine Manufacturer TYM TYM Engine Model A1700N4-BUTR_4 A1100N2 Engine Type Vertical, 4-stroke, water-cooled diesel 3 cylinder, water-cooled diesel, natural aspiration, swirl chamber No. of Cylinders 3 3 Displacement 104.5 in³ 71.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 25 hp PTO Power 29.5 hp 18 hp Engine Emissions Constraints EPA Final Tier4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry element Fuel System Not Published Indirect injection (swirl chamber) Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type pump with primary and secondary pumps Implement Flow 8.2 gpm 4.3 gpm Steering Flow 4.4 gpm 3.1 gpm Total Hydraulic Flow 12.6 gpm 7.4 gpm Overall Hydraulic Pump Flow 12.6 gpm 7.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Up to 2 1 ▶ Fluid CapacityFuel Tank Capacity 7.13 gal 6.08 gal Coolant Capacity 1.32 gal 1.21 gal Crankcase Capacity 1.14 gal 0.79 gal Transmission / Hydraulic System Capacity 9.77 gal 2.90 gal Front Axle Fluid Capacity 1.69 gal 0.79 gal ▶ PTO & HitchPTO Type Independent Live PTO (6 spline shaft) PTO Rear 540 rpm 540 / 960 rpm Mid-PTO Availability Not Published Optional, 2,500 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,307 lb 1,433 lb Hitch Lift Capacity (at 24”) 2,425 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST), 3-range Hydrostatic (HST) No. of Speeds 3 range (HST) 3 range (L/M/H) Max Travel Speed (Forward) 19.08 mph 14.8 mph Max Travel Speed (Reverse) 19.08 mph 14.8 mph Clutch None (HST) Dry, single plate Differential Lock & Limited Slip Options Rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame with cast iron axles Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Not Published Adjustable seat, flips up and back for rear backhoe operation Front Axle Type Selectable 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.7 in 53.8 in Wheelbase 65.7 in 65.7 in Ground Clearance 13.1 in 16.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 96.85 in 91.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 134.88 in 110 in ▶ WeightTractor Weight (Base) 3,164 lb 2,106 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R4 Industrial (25x8.50-14 front / 14x17.5 rear) R1 Agricultural - Front 8.0-16 7-16 6PR R1 Agricultural - Rear 12.4-24 11.2-20 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 28x8.50-15 25x8.50-14 R4 Industrial - Rear 43x16.00-20 14x17.5 ▶ Loader & AttachmentsQuick Attach Loader System SSQA Quick attach front loader Loader Model BBL400 BBL300 Loader Lift Height 104 in 86 in Loader Lift Capacity (Full Height) 2,200 lb (at pivot pin) 1,314 lb (at pivot pin) Loader Breakout Force 3,660 lb 1,960 lbf ▶ WarrantyWarranty Length & Coverage Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
