▶ EnginePTO Power 30 hp 540 rpm, 1st stage Alternator 50 A, 12 V 50 A, 12 V Air Cleaner Not Published Present (standard equipment) Engine Type 3 Cylinder, Water-Cooled, Diesel Vertical, water cooled 4-cycle, diesel engine Fuel System Diesel fuel Diesel fuel system with fuel injection pump Displacement 104.7 in³ 104.6 in³ No. of Cylinders 3 3 Rated Engine Speed 2600 rpm 2100 rpm Cooling System Type Water cooled Pressurized Radiator Engine Manufacturer A1700N4-BUTC_4 A1700N6, A1700N5, A1700N4 Engine Power (Gross) 34.9 hp 24.5 hp Engine Emissions Constraints EPA Final Tier4 Not Published ▶ WeightTractor Weight (Base) 3,496.5 lb (3,497 lbs) for ROPS MODEL; 3,728 lb (3,728 lbs) for CABIN MODEL 3,496.5 lb (3,497 lbs), 3,728 lb (3,728 lbs) Weight with ROPS and Loader 3163 lbs Not Published Weight with Cab and Loader 3,728 lbs Not Published ▶ WarrantyWarranty Length & Coverage 6-year powertrain warranty 6-year powertrain warranty ▶ HydraulicsPump Type Not Published Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Steering Flow 4.4 gpm 4.0 gpm Implement Flow 8.2 gpm 7.5 gpm Total Hydraulic Flow 12.6 gpm (4.4+8.2) 11.5 gpm (4.0 + 7.5) Hydraulic System Type Open Center Not Published System Operating Pressure 180 - 407.9 lbf/cm² for control valve 463 lbf/cm² maximum Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 12.6 gpm 11.5 gpm No. of Optional Remote Valves Optional (up to 2) Optional (Up to 2) No. of Standard Remote Valves Not Published Not Published ▶ PTO & HitchPTO Rear 540 RPM 540 rpm PTO Type Independent Independent Lift Control Type Position Control Position control type Hitch Lift Capacity 3,306.9 lb 2,425 lb @ 24 in behind lift point Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Cat 1 Category 1 Hitch Lift Capacity (at 24”) 2,425 lb 2,425 lb @ 24 in behind lift point ▶ Tire OptionsR3 Turf - Rear Not Published Not Published R3 Turf - Front Not Published Not Published Tire Size & Options Std (manual): 8.0-16 / 12.4-24; IND (website): 28X8.50-15 / 43X16.00-20 OEM website lists IND tires 25X8.50-14 / 15-19.5; Operator Manual spec based on 8.0-16 / 12.4-24 R4 Industrial - Rear 43X16.00-20 15-19.5 R4 Industrial - Front 28X8.50-15 25X8.50-14 R1 Agricultural - Rear 12.4-24 6PR 12.4-24 6PR R1 Agricultural - Front 8.0-16 4PR 8.0-16 4PR ▶ Fluid CapacityCoolant Capacity 1.32 gal 5.0 ℓ (1.32 u.s. gal) Crankcase Capacity 1.14 gal 4.3 ℓ (1.14 u.s. gal) Fuel Tank Capacity 7.13 gal 27 ℓ (7.13 u.s. gal) Front Axle Fluid Capacity Not Published Not Published Transmission / Hydraulic System Capacity 9.77 u.s. gal (37 ℓ) HST HST: 9.77 gal ▶ Loader & AttachmentsLoader Lift Height 104 in 104 in Loader Breakout Force 3,660 lb 3,660 lb Quick Attach Loader System SSQA SSQA Loader Lift Capacity (Full Height) 2,200 lb (at pivot pin) 2,200 lb (pivot pin) ▶ Transmission & DrivetrainClutch None (HST) None (HST) No. of Speeds 3 Range 3 Range Transmission Type HST (3-range) HST (Hydrostatic Transmission) with shuttle type Max Travel Speed (Forward) 19.08 mph (range C) Not Published Max Travel Speed (Reverse) 19.08 mph (range C) Not Published Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsBrakes Wet multi-disc Wet, Multi-Disc Steering Fully hydraulic power steering Hydrostatic power steering Frame Type Not Published Not Published Front Axle Type Cast Iron Not Published Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 65.7 in 65.8 in (65.79 in.) Overall Width 56.7 in 57.1 in (57.13 in.) [ROPS Model], 55.6 in (55.63 in.) [Cabin Model] Overall Length 134.88 in. 134.9 in (134.88 in.) Ground Clearance 15 in 13.2 in (13.19 in.) [ROPS Model], 13.5 in (13.50 in.) [Cabin Model] Height to Top of ROPS 96.85 in 104.1 in (104.06 in.) [ROPS Model], 88.9 in (88.9 in.) [Cabin Model] Height to Top of Cab Model Not Applicable Not Published Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 134.88 in 134.88 in ▶ ITC Company AccessoriesAccessories that fit
