Bad Boy Tractors 4025 vs Bad Boy Tractors 4035

Across 8 measurable specs, the Bad Boy Tractors 4035 leads 4 categories to 0 (4 tied). Machine pages: Bad Boy Tractors 4025 and Bad Boy Tractors 4035.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4025	Bad Boy Tractors4035

▶Engine
Engine Manufacturer	TYM	TYM
Engine Model	A1700N6-BUTR_3	A1700N4-BUTR_4
Engine Type	Vertical, 4-stroke, water-cooled diesel	Vertical, 4-stroke, water-cooled diesel
No. of Cylinders	3	3
Displacement	104.5 in³	104.5 in³
Rated Engine Speed	2100 rpm	2600 rpm
Engine Power (Gross)	25 hp	35 hp
PTO Power	19.1 hp	29.5 hp
Engine Emissions Constraints	Not Published	EPA Final Tier4
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Dry	Not Published
Fuel System	Not Published	Not Published
Alternator	50 A, 12 V	50 A, 12 V
▶Hydraulics
Pump Type	Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev)	Not Published
Implement Flow	7.5 gpm	8.2 gpm
Steering Flow	4 gpm	4.4 gpm
Total Hydraulic Flow	11.5 gpm	12.6 gpm
Overall Hydraulic Pump Flow	11.5 gpm	12.6 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Up to 2	Up to 2
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	7.13 gal
Coolant Capacity	1.32 gal	1.32 gal
Crankcase Capacity	1.14 gal	1.14 gal
Transmission / Hydraulic System Capacity	9.77 gal	9.77 gal
Front Axle Fluid Capacity	Not Published	1.69 gal
▶PTO & Hitch
PTO Type	Independent	Independent
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,307 lb	3,307 lb
Hitch Lift Capacity (at 24”)	2,425 lb	2,425 lb
Lift Control Type	Position control	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST)	Hydrostatic (HST), 3-range
No. of Speeds	3 range (A/B/C)	3 range (HST)
Max Travel Speed (Forward)	Not Published	19.08 mph
Max Travel Speed (Reverse)	Not Published	19.08 mph
Clutch	None (HST)	None (HST)
Differential Lock & Limited Slip Options	Rear differential lock	Rear differential lock
▶Chassis, Steering & Controls
Frame Type	Heavy-duty steel frame with cast iron axles	Not Published
Steering	Fully hydraulic power steering	Hydrostatic power steering
Brakes	Wet multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Not Published	Not Published
Front Axle Type	Selectable 4WD	Selectable 4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	56.7 in	56.7 in
Wheelbase	65.7 in	65.7 in
Ground Clearance	13.1 in	13.1 in
Min. Turn Radius without Brakes	Not Published	Not Published
Height to Top of ROPS	104.06 in	96.85 in
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	Not Published
Overall Length	134.88 in	134.88 in
▶Weight
Tractor Weight (Base)	2,970 lb	3,164 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R4 Industrial (25x8.50-14 / 15-19.5)	R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20
R1 Agricultural - Front	8.0-16	8.0-16
R1 Agricultural - Rear	12.4-24	12.4-24
R3 Turf - Front	Not Published	Not Published
R3 Turf - Rear	Not Published	Not Published
R4 Industrial - Front	25x8.50-14	28x8.50-15
R4 Industrial - Rear	15-19.5	43x16.00-20
▶Loader & Attachments
Quick Attach Loader System	Quick attach front loader	SSQA
Loader Model	BBL400	BBL400
Loader Lift Height	104 in	104 in
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	2,200 lb (at pivot pin)
Loader Breakout Force	3,660 lbf	3,660 lb
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours; loader and backhoe 24 months from shipment, 12 months from sale, or 500 hours	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00

Find a Bad Boy dealer near you→

Bad Boy Tractors 4025 vs Bad Boy Tractors 4035: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4025 or the Bad Boy Tractors 4035?

The Bad Boy Tractors 4035 leads on engine hp at 35 hp hp, compared to 25 hp hp for the Bad Boy Tractors 4025.

Which has more PTO horsepower, the Bad Boy Tractors 4025 or the Bad Boy Tractors 4035?

The Bad Boy Tractors 4035 leads on pto hp at 29.5 hp hp, compared to 19.1 hp hp for the Bad Boy Tractors 4025.

Which is heavier, the Bad Boy Tractors 4025 or the Bad Boy Tractors 4035?

The Bad Boy Tractors 4035 leads on weight at 3,164 lb lb, compared to 2,970 lb lb for the Bad Boy Tractors 4025.

Which has more loader lift capacity, the Bad Boy Tractors 4025 or the Bad Boy Tractors 4035?

They are effectively tied: both machines are rated at 2,200 lb lb for loader lift.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4025 or the Bad Boy Tractors 4035?

They are effectively tied: both machines are rated at 2,425 lb lb for 3-pt lift (24 in).
