Bad Boy Tractors 4035 vs Bad Boy Tractors 4035 Cab

Across 9 measurable specs, this matchup is a dead heat: 1 categories to the Bad Boy Tractors 4035, 1 to the Bad Boy Tractors 4035 Cab, 7 tied. Machine pages: Bad Boy Tractors 4035 and Bad Boy Tractors 4035 Cab.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4035	Bad Boy Tractors4035 Cab

▶Engine
Engine Manufacturer	TYM	TYM
Engine Model	A1700N4-BUTR_4	A1700N4-BUTC_4
Engine Type	Vertical, 4-stroke, water-cooled diesel	Vertical, water-cooled 4-cycle diesel
No. of Cylinders	3	3
Displacement	104.5 in³	104.5 in³
Rated Engine Speed	2600 rpm	2600 rpm
Engine Power (Gross)	35 hp	35 hp
PTO Power	29.5 hp	29.5 hp
Engine Emissions Constraints	EPA Final Tier4	Not Published
Cooling System Type	Water-cooled	Water-cooled
Air Cleaner	Not Published	Not Published
Fuel System	Not Published	Not Published
Alternator	50 A, 12 V	50 A, 12 V
▶Hydraulics
Pump Type	Not Published	Not Published
Implement Flow	8.2 gpm	8.2 gpm
Steering Flow	4.4 gpm	4.4 gpm
Total Hydraulic Flow	12.6 gpm	12.6 gpm
Overall Hydraulic Pump Flow	12.6 gpm	12.6 gpm
Hydraulic System Type	Open center	Open center
Rear Remote Hydraulic Flow	Not Published	Not Published
No. of Standard Remote Valves	Not Published	Not Published
No. of Optional Remote Valves	Up to 2	Up to 2
▶Fluid Capacity
Fuel Tank Capacity	7.13 gal	7.13 gal
Coolant Capacity	1.32 gal	1.32 gal
Crankcase Capacity	1.14 gal	1.14 gal
Transmission / Hydraulic System Capacity	9.77 gal	9.77 gal
Front Axle Fluid Capacity	1.69 gal	1.69 gal
▶PTO & Hitch
PTO Type	Independent	Independent
PTO Rear	540 rpm	540 rpm
Mid-PTO Availability	Not Published	Not Published
Category, 3-Point Hitch	Category I	Category I
Hitch Lift Capacity	3,307 lb	3,307 lb
Hitch Lift Capacity (at 24”)	2,425 lb	2,425 lb
Lift Control Type	Position control	Position control
▶Transmission & Drivetrain
Transmission Type	Hydrostatic (HST), 3-range	Hydrostatic (HST), 3-range
No. of Speeds	3 range (HST)	3 range (HST)
Max Travel Speed (Forward)	19.08 mph	18.21 mph
Max Travel Speed (Reverse)	19.08 mph	18.21 mph
Clutch	None (HST)	None (HST)
Differential Lock & Limited Slip Options	Rear differential lock	Rear differential lock
▶Chassis, Steering & Controls
Frame Type	Not Published	Not Published
Steering	Hydrostatic power steering	Electro-hydraulic power steering
Brakes	Wet, multi-disc	Wet, multi-disc
Seat Suspension & Adjustability	Not Published	Heated leather seat (cab)
Front Axle Type	Selectable 4WD	Selectable 4WD
Front Axle Rating	Not Published	Not Published
Drawbar Capacity	Not Published	Not Published
▶Dimensions & Maneuverability
Overall Width	56.7 in	55.6 in
Wheelbase	65.7 in	65.7 in
Ground Clearance	13.1 in	13.19 in
Min. Turn Radius without Brakes	Not Published	Not Published
Height to Top of ROPS	96.85 in	Not Published
Height to Top of ROPS (folded)	Not Published	Not Published
Height to Top of Cab Model	Not Published	85.9 in
Overall Length	134.88 in	134.88 in
▶Weight
Tractor Weight (Base)	3,164 lb	3,551 lb
Weight with ROPS and Loader	Not Published	Not Published
Weight with Cab and Loader	Not Published	Not Published
▶Tire Options
Tire Size & Options	R1 ag 8.0-16 / 12.4-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20	R1 ag 7-16 / 11.2-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20
R1 Agricultural - Front	8.0-16	7-16
R1 Agricultural - Rear	12.4-24	11.2-24
R3 Turf - Front	Not Published	Not Published
R3 Turf - Rear	Not Published	Not Published
R4 Industrial - Front	28x8.50-15	28x8.50-15
R4 Industrial - Rear	43x16.00-20	43x16.00-20
▶Loader & Attachments
Quick Attach Loader System	SSQA	SSQA
Loader Model	BBL400	BBL400
Loader Lift Height	104 in	104 in
Loader Lift Capacity (Full Height)	2,200 lb (at pivot pin)	2,200 lb (at pivot pin)
Loader Breakout Force	3,660 lb	3,660 lb
▶Warranty
Warranty Length & Coverage	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours	Basic 24 months or 1,000 hours; powertrain 72 months or 2,000 hours
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00 Branson / TYM 15 Series Fuel Tank Cover $250.00

Find a Bad Boy dealer near you→

Bad Boy Tractors 4035 vs Bad Boy Tractors 4035 Cab: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4035 or the Bad Boy Tractors 4035 Cab?

They are effectively tied: both machines are rated at 35 hp hp for engine hp.

Which has more PTO horsepower, the Bad Boy Tractors 4035 or the Bad Boy Tractors 4035 Cab?

They are effectively tied: both machines are rated at 29.5 hp hp for pto hp.

Which is heavier, the Bad Boy Tractors 4035 or the Bad Boy Tractors 4035 Cab?

The Bad Boy Tractors 4035 Cab leads on weight at 3,551 lb lb, compared to 3,164 lb lb for the Bad Boy Tractors 4035.

Which has more loader lift capacity, the Bad Boy Tractors 4035 or the Bad Boy Tractors 4035 Cab?

They are effectively tied: both machines are rated at 2,200 lb lb for loader lift.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4035 or the Bad Boy Tractors 4035 Cab?

They are effectively tied: both machines are rated at 2,425 lb lb for 3-pt lift (24 in).
