▶ EngineEngine Manufacturer TYM TYM Engine Model A1700N4-BUTC_4 A1700N6-BUTR_3 Engine Type Vertical, 4-stroke, water-cooled diesel Vertical, 4-stroke, water-cooled diesel No. of Cylinders 3 3 Displacement 104.7 in³ 104.7 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 35 hp 24.5 hp PTO Power 29.5 hp 19.1 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Water-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Not Published Not Published Alternator 50 A, 12 V 50 A, 12 V ▶ HydraulicsPump Type Not Published Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev) Implement Flow 8.2 gpm 7.5 gpm Steering Flow 4.4 gpm 4 gpm Total Hydraulic Flow 12.6 gpm 11.5 gpm Overall Hydraulic Pump Flow 12.6 gpm 11.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Up to 2 2 ▶ Fluid CapacityFuel Tank Capacity 7.13 gal 7.13 gal Coolant Capacity 1.32 gal 1.32 gal Crankcase Capacity 1.14 gal 1.14 gal Transmission / Hydraulic System Capacity 9.77 gal Manual: 8.98 gal; HST: 9.77 gal Front Axle Fluid Capacity 1.69 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 533 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category 1 Category 1 Hitch Lift Capacity 3,306.9 lb 3,306.9 lb Hitch Lift Capacity (at 24”) 2,425 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST), 3-range Hydrostatic (HST) No. of Speeds 3 range (HST) 3 range (A/B/C) Max Travel Speed (Forward) 18.21 mph Not Published Max Travel Speed (Reverse) 18.21 mph Not Published Clutch None (HST) None (HST) Differential Lock & Limited Slip Options Rear differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Heavy-duty steel frame with cast iron axles Steering Electro-hydraulic power steering Fully hydraulic power steering Brakes Wet, multi-disc Wet multi-disc Seat Suspension & Adjustability Heated leather seat (cab) Not Published Front Axle Type Selectable 4WD Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 134.88 in 134.88 in Overall Width 56.3 in 56.7 in Wheelbase 65.7 in 65.7 in Ground Clearance 13.19 in 15 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published 96.85 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 85.9 in Not Published ▶ WeightTractor Weight (Base) 3,551 lb 2,969.6 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 ag 7-16 / 11.2-24 (standard); R4 industrial 28x8.50-15 / 43x16.00-20 R1 Agricultural (8.0-16 / 12.4-24 standard), R4 Industrial (25x8.50-14 / 15-19.5) R1 Agricultural - Front 7-16 8.0-16 R1 Agricultural - Rear 11.2-24 12.4-24 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 28x8.50-15 25x8.50-14 R4 Industrial - Rear 43x16.00-20 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System SSQA Quick attach front loader Loader Model BBL400 BBL400 Loader Lift Height 104 in 104 in Loader Lift Capacity (Full Height) 2,200 lb 2,200 lb Loader Breakout Force 3,660 lb 3,660 lbf ▶ WarrantyWarranty Length & Coverage Engine and powertrain 72 months or 2,000 hours; other tractor parts 24 months or 1,000 hours Engine and powertrain: 72 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours ▶ ITC Company AccessoriesAccessories that fit
