▶ EngineEngine Manufacturer Daedong Yanmar Engine Model 3C100LWH-U2 3TNM74F Engine Type Diesel 3 cylinder, water-cooled diesel, natural aspiration No. of Cylinders 3 3 Displacement 61.5 in³ 60.6 in³ Rated Engine Speed 3200 rpm 3200 rpm Engine Power (Gross) 21 hp 21.5 hp PTO Power 16.3 hp 15.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Water-cooled Air Cleaner Not Published Single dry element Fuel System Not Published Indirect injection Alternator Not Published 40 A, 12 V ▶ HydraulicsPump Type Not Published Single gear pump with flow divider Implement Flow Not Published 4.17 gpm Steering Flow Not Published 2.11 gpm Total Hydraulic Flow 7.2 gpm 6.3 gpm Overall Hydraulic Pump Flow 7.2 gpm 6.97 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves None (rear hydraulics optional) Not Published No. of Optional Remote Valves 1 pair 1 ▶ Fluid CapacityFuel Tank Capacity 6.7 gal 6.6 gal Coolant Capacity Not Published 3.7 qt Crankcase Capacity Not Published 2.1 qt Transmission / Hydraulic System Capacity Not Published 3.6 gal Front Axle Fluid Capacity Not Published 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard: 2200 rpm Optional, 2,500 rpm Category, 3-Point Hitch Category 1 Limited Category 1 (limited) Hitch Lift Capacity Not Published 1,100 lb Hitch Lift Capacity (at 24”) 700 lb 679 lb Lift Control Type Hydraulic Position Control System Position control ▶ Transmission & DrivetrainTransmission Type 2-Range HST Hydrostatic (HST) No. of Speeds Infinite forward and reverse (2-range) 2 range Max Travel Speed (Forward) 11.1 mph 7.8 mph Max Travel Speed (Reverse) 7.6 mph Not Published Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Rear differential lock (standard) Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Sub-compact tractor, 4WD Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet multi-disc Wet disc Seat Suspension & Adjustability Adjustable seat (standard) Standard adjustable seat Front Axle Type Four-wheel drive (standard) Selectable 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 99.3 in 94.2 in Overall Width 45.7 in 44.5 in Wheelbase 55.1 in 53.1 in Ground Clearance 6.3 in 8.3 in Min. Turn Radius without Brakes 100.0 in (with brake applied) 86.6 in Height to Top of ROPS 87.6 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1521 lb 1,433 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 18x8.5-10 16x7.50-9 R1 Agricultural - Rear 26x12.00-12 24x12.00-12 R3 Turf - Front Not Published 18x8.5-10 R3 Turf - Rear Not Published 26x12.00-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12.00-12 26x12.00-12 ▶ Loader & AttachmentsQuick Attach Loader System Standard quick attach mounting system Quick attach front loader Loader Model FL6 BBL100 Loader Lift Height 71.9 in 78.5 in Loader Lift Capacity (Full Height) 608 lb 617 lb Loader Breakout Force 1554 lb 1,253 lbf ▶ WarrantyWarranty Length & Coverage 24 months or 1500 hours (whichever occurs first) on all components; powertrain and engine components 48 months (unlimited hours) for consumer purchasers, 36 months or 2000 hours for commercial purchasers Engine and powertrain: 84 months or 2,000 hours; other tractor parts: 24 months or 1,000 hours; loader and backhoe: 24 months from shipment, 12 months from sale, or 500 hours
