▶ EngineEngine Manufacturer FPT FPT Engine Model Not Published Not Published Engine Type Turbocharged 6-cylinder diesel, 12 valves 4-cylinder diesel, electronic high-pressure common rail No. of Cylinders 6 4 Displacement 411 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 125 hp 105 hp PTO Power 105 hp 91 hp Engine Emissions Constraints Tier 3 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Mechanical injection Electronic high-pressure common rail Alternator 120 A 120 A ▶ HydraulicsPump Type Fixed displacement pump Not Published Implement Flow 22 gpm 17.2 gpm (22.2 gpm optional) Steering Flow 9 gpm 10 gpm (11.4 gpm optional) Total Hydraulic Flow 31 gpm 27.2 gpm (17.2 + 10, computed) Overall Hydraulic Pump Flow 31 gpm 27.2 gpm (17.2 + 10, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 2 No. of Optional Remote Valves 4 3 ▶ Fluid CapacityFuel Tank Capacity 62 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity 14.8 qt Not Published Transmission / Hydraulic System Capacity 65.5 qt Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/1000 (two individual shafts) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 7,200 lb 6,393 lb Lift Control Type Not Published Electronic draft control (EDC) with rear fender switch ▶ Transmission & DrivetrainTransmission Type Not Published Not Published No. of Speeds 8F/8R (16F/8R optional) 12F/12R (20F/20R or 24F/24R optional) Max Travel Speed (Forward) 18.4 mph Not Published Max Travel Speed (Reverse) 19.0 mph Not Published Clutch Not Published Wet disc, electro-hydraulic power shuttle Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability Mechanical seat (standard); air suspension seat (optional) Heated air suspension seat with 15-degree swivel (optional) Front Axle Type Not Published MFD (four-wheel drive) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch Not Published 164 in (16.9R-34 rear tires) Overall Width Not Published 75 in (minimum) Wheelbase 105 in (2WD); 104 in (MFD) 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 103 in (16.9R-34 rear tires) ▶ WeightTractor Weight (Base) 9,061 lb (2WD ROPS); 9,700 lb (MFD ROPS); 9,766 lb (2WD cab); 10,406 lb (MFD cab) 9,370 lb (cab, MFD, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available R1 Agricultural - Front Not Published 14.9R24 R1 Agricultural - Rear 18.4-34 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Lock & Go automatic quick coupling loader mount with Multi-Coupler hydraulic connection Quick-Latch loader mounting with Quick-Attach faceplate Loader Model L755 L735 (NSL or MSL); L745 (NSL or MSL) Loader Lift Height Not Published L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) Loader Lift Capacity (Full Height) Not Published L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) Loader Breakout Force Not Published L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
